The Kingspan
End Cap
Option 1: Short Duct or Plenum
Adhesive # 212
Cut End Cap at 45 Degrees.
Assembly with Adhesive or Tiger Clips
Fix End Cap to duct end
Apply tape around End Cap
Silicone
# 231G
Seal with silicone inside duct and End Cap
System
Option 2: Long Duct > 40"
Cut End Cap at 45 degrees
Apply sealant around
internal perimeter
Silicone # 231G
TClip # 364
Fix End Cap to duct end
Tiger Clips Max spacing: 10"
Apply UL tape around End-Cap
25
