- Page 1 ECHOTEL ® AS-I ® NTERFACE Installation and Operating Manual Ultrasonic Contact Level Switch 7xxx 6xxx 5xxx 4xxx 3xxx 2xxx 1xxx ®...
- Page 2 Report any concealed damage to the carrier within 24 hours. Check the contents of the car- ton/crates against the packing slip and report any discrep- ancies to Magnetrol. Check the nameplate model number Nameplate: (Model number/approvals as per inserted separate sheet) to - part number be sure it agrees with the packing slip and purchase order.
-
Page 3: User Interface
WIRING Echotel ® 960 electronics M12 x 1 AS-i bus quick disconnect male connector or cable gland Plugged entry Standard unshielded Up to 31 units (slaves) / 62 units (in the 2-wire cable extended addressing mode) on one net- work HAZARDOUS AREA SAFE AREA Important: In extended addressing mode, the A or B channel select must be programmed as well. -
Page 4: Maintenance
MAINTENANCE Manual Testing Level Test: Pressing the “Level Test” pushbutton, will manually test the AS-i output. The level test forces the D2 output and corresponding LED’s from “1” (wet gap) to “0” (dry gap) data bits or vice versa. The time delay setting is not active during testing. Fault Test Pressing the “Fault Test”... -
Page 5: Replacement Parts
REPLACEMENT PARTS Replacing electronics/transducer Echotel electronics can be removed in the field under process conditions. Follow below steps to exchange electronics/trans- ducer: Note: Adjust set up of the replacing electronics following the settings of the old electronics (see configuration section) 1. -
Page 6: Model Identification
3. M12 x 1, AS-i quick disconnect male connector part n° for 960 electronics: 037-7916-001 1. Code for Echotel 960 electronics BASIC MODEL NUMBER 9 6 0 Echotel 960 electronics with AS-i bus communication INPUT POWER 5 8 A 2-wire loop powered with current shift output... - Page 7 MODEL IDENTIFICATION 2. Code for Echotel 961 transducer BASIC MODEL NUMBER 9 M 1 Echotel 961 transducer with single setpoint TRANSDUCER MATERIALS (use only metal transducers for hazardous area) Œ 316/316 L (1.4401/1.4404) stainless steel Hastelloy C (2.4819) Monel (2.4360) CPVC Kynar (PVDF) 316/316L (1.4401/1.4404) with 0,5 µm (Ra 20) hygienic finish...
-
Page 8: Dimensions In Mm (Inches)
DIMENSIONS IN mm (inches) 113 (4.43) without window 113 (4.43) without window 123 (4.85) with window 123 (4.85) with window 46 (1.8) Typical 60 (2.35) Typical Actuation length Actuation length for BSP (G1) for NPT connection connection Actuation length 6 (0.25) 6 (0.25) Ø... -
Page 9: Specification
SPECIFICATIONS Physical/Functional specifications Description Specification Input Voltage 21 - 31 V DC (2-wire) Power Consumption < 1 Watt D2 = “1” with a wet gap / “0” with a dry gap Signal Output D3 = “1” during malfunction / “0” during normal operation LED’s for process alarm status, malfunction (error of transducer, electronics or elec- Indication trical noise interference) and wet/dry status of transducer... -
Page 10: Pressure / Temperature Ratings
PRESSURE / TEMPERATURE RATINGS Kynar Transducer Ratings CPVC Transducer Ratings Range with 3/4" NPT Range with 150# flange Range with PN16 flange Process temperature (°C) Process temperature (°C) Metal Transducer Ratings ≤ 5 cm transducer 138 bar > 5 cm transducer 103 bar 83 bar Œ... -
Page 12: Service Policy
SERVICE POLICY Owners of Magnetrol products may request the return of a control; or, any part of a control for complete rebuilding or replacement. They will be rebuilt or replaced promptly. Magnetrol International will repair or replace the control, at no cost to the purchaser, (or owner) other than transportation cost if: a.
