Summary of Contents for Magnetrol ECHOTEL 910
- Page 1 ECHOTEL ® nstallation and Operating Manual Ultrasonic Level Switch ®...
- Page 2 Magnetrol. Check the nameplate model number to be sure it agrees with the packing slip and purchase order. Check and record the serial number for future refer- ence when ordering parts.
- Page 3 WIRING Sensor plugs (may be reversed) AW2395 Low level failsafe High level failsafe NOTE: With NO power, NO Contacts are Open. NC Contacts are Closed. L1 L2/N NO CM NC NO CM NC + TB1 – DPDT contact contact RELAY Shield to green grounding screw 240/120 V AC Cable gland...
-
Page 4: Electronics Specifications
SPECIFICATIONS PERFORMANCE Description Specification Response time 0,5 s typical Repeatability ± 2 mm (0.078") Ambient Temperature -40 °C up to +70 °C (-40 °F up to +160 °F) Humidity 0-99 %, non-condensing Electromagnetic Compatibility Meets CE requirements (EN 61326: 1997 + A1 + A2) ELECTRONICS SPECIFICATIONS Description Specification... -
Page 5: Model Identification
MODEL IDENTIFICATION A complete measuring system consists of: 1. One code for ECHOTEL series 910 electronics and transducer ® 2. Optional: code for thread-on mounting flanges, consult factory for other sizes or materials BASIC MODEL NUMBER 9 1 0 Echotel 910, ultrasonic level switch with relay ®... -
Page 6: Replacement Parts
Optional transducer mounting flanges Thread-on mounting flanges can only be used in combination with 3/4" NPT process connection transducer. Part No. ANSI B16.5 flanges Carbon steel 316/316L SST 1" 150 lbs RF 004-5867-041 004-5867-043 1 1/2" 150 lbs RF 004-5867-021 004-5867-001 2"... -
Page 7: Dimensions In Mm (Inches)
DIMENSIONS IN mm (inches) dual entry: 87 (3.43) single entry: 76 (3.00) 87 (3.43) cable entry (both sides) cable entry (4.49) (4.49) 44 (1.73) 44 (1.73) ATEX Weatherproof 25 (1.00) 58 (2.28) 45 (1.77) Actuation Actuation length Actuation length length Ø... -
Page 8: Service Policy
SERVICE POLICY Owners of Magnetrol products may request the return of a control; or, any part of a control for complete rebuilding or replacement. They will be rebuilt or replaced promptly. Magnetrol International will repair or replace the control, at no cost to the purchaser, (or owner) other than transportation cost if: a.
