ENERGIE
AIR WATER HEAT PUMP
INVERTER UNIT
Model:
Aquapura 12 – Inverter R 8-12
Aquapura 16 – Inverter R 5-18
Aquapura 16 T– Inverter R 5-18
Installation and Instruction Manual
Revision: 3
Date: 06/11/20
EN 60335-1;
EN 60335-2-40.
EN
EN: 14825
EN: 14511

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Aquapura 12 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Energie Aquapura 12

  • Page 1 ENERGIE AIR WATER HEAT PUMP INVERTER UNIT Model: Aquapura 12 – Inverter R 8-12 Aquapura 16 – Inverter R 5-18 Aquapura 16 T– Inverter R 5-18 Installation and Instruction Manual Revision: 3 EN 60335-1; EN: 14825 Date: 06/11/20 EN: 14511...
  • Page 2 Start or operate the unit and check that the parameters are within the normal operating range. MODELS: AQUAPURA 12 – INVERTER R 8 – 12 AQUAPURA 16 – INVERTER R 5 – 18 AQUAPURA 16T – INVERTER R 5 – 18...
  • Page 3: Table Of Contents

    Installation ..............15 15.1 Location of the unit ..............15 15.2 Condensate lines ..............15 15.3 Water loop connection ............16 15.4 Water filter................17 15.5 Pressure drops (water filter) ..........17 15.6 Heating water quality ............17 ENERGIE Page | i...
  • Page 4 Central heating/ cooling ............41 21.2 Central heating/ cooling with buffer tank ....... 42 21.3 Central heating/ cooling with buffer tank + DHW ....42 21.4 Central heating/ cooling + DHW ..........43 21.5 DHW ..................43 ENERGIE Page | 2...
  • Page 5 Electrical connections inverter 8-12 ........44 22.2 Electrical connections inverter 5-18 ........46 22.3 Electrical connections inverter R 8-12 and inverter R 5-18 ... 47 Appendix 5 – Warranty ..........50 Appendix 6 – Warranty Registration Card ..... 52 ENERGIE Page | 3...
  • Page 6: Safety Information (Cautions And Warnings)

    ATTENTION Icon Notes Meaning Prohibition. What is prohibited will be nearby this icon Compulsory implement. The listed action need to be taken. ATTENTION (include WARNING) Please pay attention to what is indicated. ENERGIE Page | 4...
  • Page 7 Improper movement or repair on the unit will lead Entrust to water leakage, electrical shock, injury or fire. It is prohibited to repair the unit by the user himself, otherwise electrical shock or fire may occur. Prohibit ENERGIE Page | 5...
  • Page 8: Indications

    Do not use any cleaning agents containing sand, soda, acid or chloride as these may damage the surface. Prohibition Indications This manual came with all the equipment and contains important instructions that should be followed during installation. ENERGIE Page | 6...
  • Page 9: Introduction

    Do the installation in accordance with the standards and requirements given by the manufacturer; • Do the initial startup of the equipment and check all control points: • Explain to the user how to do the installation and how to use the equipment; ENERGIE Page | 7...
  • Page 10: Propose Of The Heat Pump

    The heat pump unit use special designed heat exchanger to enhance whole efficiency. • Large working range This series of heat pump is designed to work under different working conditions as low as -15 degrees for heating. ENERGIE Page | 8...
  • Page 11: Principle Of Operation

    So it can work with the floor heating pipe, the fan coil or the radiator, and replace the boiler directly. In addition, the inverter heat pump can be used to provide hot water for sanitary use, like kitchen, shower, etc. ENERGIE Page | 9...
  • Page 12: Transport

    Carefully inspect the all components of the equipment receive, to make sure that the equipment has not been damaged during transport. Verify that all parts ordered were received as specified and if the type, size and voltage of the unit are correct. ENERGIE Page | 10...
  • Page 13: Dimensions

    11. Dimensions Aquapura 12 (Inverter R 8-12) A- Water outlet 1’’ Water inlet 1’’ C- Electrical connections Aquapura 16T (Inverter R 5-18) and Aquapura 16 (Inverter R 5-18) Water outlet 1 1/4’’ Water inlet 1 1/4’’ C- Electrical connections ENERGIE...
  • Page 14: Overview

    12. Overview Aquapura 12 (inverter R 8 - 12) DISPLAY – Control Interface Maximum distance between display and outdoor unit 100m. Water outlet 1” Water inlet 1” Air outlet (horizontal) Aquapura 16 (Inverter R5-18) and Aquapura 16 T (inverter R5 - 18) DISPLAY –...
  • Page 15: Performance

    13. Performance 13.1 Heating Capacity (*) 13.2 Electrical Power (*) 13.3 Coefficient of performance (*) (*) W ater temperature 30/35ºC. ENERGIE Page | 13...
  • Page 16: Specifications Data

    14. Specifications data AQUAPURA 12 AQUAPURA 16 AQUAPURA 16T (INVERTER R 8-12) (INVERTER R 5-18) (INVERTER R 5-18) Main power 1~/ 230V/ 50Hz 3N~/ 400V/ 50Hz Heating 8,25 / 12,52 15,36 / 18,51 (Nom./Max) Heating capacity Cooling 7,01 / 11,31 13,92 / 16,23 (Nom./Max)
  • Page 17: Installation

    Large amounts of condensation water, as well as melt water from defrosting cycle can be produced. Provide good drainage at the installation area and make sure water cannot run out onto paths or the like during periods that ice ENERGIE Page | 15...
  • Page 18: Water Loop Connection

    Drainage and air vent need not to be insulated, in order to maintain. ATTENTION The hydraulic connection should be installed according to the local legal laws and regulations as well as the qualified professional. ENERGIE Page | 16...
  • Page 19: Water Filter

    Effects of non-compliance Danger of corrosion in boiler parts PH - Wert and heating system - Increased lime deposits Degree of hardness < 14dH - Reduced lifetime of boiler Chloride content < 150mg/l Corrosion of alloyed materials ENERGIE Page | 17...
  • Page 20: Glycol (%)

    15.8 Temperature probes (temperature vs KΩ) NTC 5KΩ e NTC 10KΩ NTC 5K NTC 10K NTC 50KΩ Temperatura [ C] Temperatura [ C] ENERGIE Page | 18...
  • Page 21: Electrical Connections

    WARNING: The electrical installation must be performed in accordance with local regulations and by a qualified professional. Electrical connections inverter R 8-12 Electrical connections Inverter R 5-18 and Inverter R 5-18 (trif.) Example: • A - Power supply (230V ~ / 50Hz); ENERGIE Page | 19...
  • Page 22: Electrical Wiring

    * The above wire sizes are selected at the maximum current of the unit according to the European Standard considering a cable length of 10 meters. NOTE: Follow local codes and regulations when selecting field wires, circuit breakers and earth leakage breakers. ENERGIE Page | 20...
  • Page 23: Room Thermostat Installation

    • behind or near the doors. • near to the windows. WARNING: The room thermostat contact must be free of tension. Connecting a tension on this contact will cause destruction of the controller. ENERGIE Page | 21...
  • Page 24: Gui (Graphical User Interface.)

    The front panel contains the display and keyboard, which, when pressed allow to perform all of the controller programming operations. Power on interface Starting up interface Remark: the wire controller can display the temperature unit as "℉" or "℃" according to the unit model you bought. ENERGIE Page | 22...
  • Page 25: Key Functions

    (heating/cooling) mode The machine is in AQS mode when this icon is shown Water tank temperature icon, the machine is Water in hot water mode when this icon is shown; temperature otherwise,this icon is not shown ENERGIE Page | 23...
  • Page 26: Keyboard Unlock

    In starting up interface ( on/off key is in red status), press on/off key can shut down the machine. 16.5 Mode switch In the main interface, there are five modes can be selected after tapping the mode key. ENERGIE Page | 24...
  • Page 27: Setting Of Target Temperature

    Tapping ②, the target temp of hot water can be set by pop-up keyboard; Tapping ③, the target temp of cooling mode can be set by pop-up keyboard. When the target temp is being set, pop-up keyboard is shown as following: ENERGIE Page | 25...
  • Page 28: Timmer Setting

    Tapping this key can save you action and Enter key ④ back to the main interface. 16.7 Timmer setting Click the timer setting key to enter the timer setting and the interface display is as follows: ENERGIE Page | 26...
  • Page 29: Setup Interface

    Factory key value of the variables read by the controller (eg pressure, temperature, etc.) Time Set time Silent mode Activate and set period in silent mode Temperatur Evolution of inlet and outlet temperature e curves over time ENERGIE Page | 27...
  • Page 30: Heat Pump Status

    ⑤: Click the up and down key to set the minute; ⑥: Click the key to cancel the setting; ⑦: Click the key to determine the setting, and the system will be automatically calibrated if it is incorrect. ENERGIE Page | 28...
  • Page 31: Manually Set Of Electric Heating

    In the heating mode press the key ① to turn on and the key ② to turn off the electric heating NOTE: Electrical kit is not provided with equipment. 16.12 Silent mode Key function number Turn on silent mode Set period in silent mode ENERGIE Page | 29...
  • Page 32: Fault Interface

    ②: Fault name ③: Occurrence time of the fault, day, month and year hour: second (s) ④: Click this key to clear all fault records (the password to clear the error list is the current day) ENERGIE Page | 30...
  • Page 33: Compensation Vs Ambient Temperature

    Heating mode setpoint user ON compensation in low outdoor temperatures OFF compensation at low outdoor temperatures Setpoint max. heating mode Setpoint max. heating mode at low outdoor temperatures. Setpoint max. heating mode at high outdoor temperatures. ENERGIE Page | 31...
  • Page 34 ON compensation in low outdoor temperatures OFF compensation at low outdoor temperatures Maximum compensation setpoint at low temperatures. ON DHW compensation for high outdoor temperatures OFF compensation in DHW for high outdoor temperatures DHW compensation setpoint for high ambient temperatures. ENERGIE Page | 32...
  • Page 35: Error Code

    Communicat ion failure Check the wire connection Communication Fault between wire controller and between remote wire controller mainboard and main board Speed control module and Check the communication Communication Fault(Fan ) E081 main board communication connection fail ENERGIE Page | 33...
  • Page 36 DC bus voltage<Dc bus Check the input voltage over-voltage protection DC Bus Underload measurement value The input voltage is low, Check the input voltage causing the input current AC Input Underload measurement is low ENERGIE Page | 34...
  • Page 37 Activation Ban Alarm Check the V15V input voltage The V15V is overload or LP 15V Underload Fault in range 13.5v~16.5v or not undervoltage Check and adjust the current IGBT Power Device The IGBT is overheat measurement Overheat Fault ENERGIE Page | 35...
  • Page 38: Main Board Interface

    18.1 Main board interface ENERGIE Page | 36...
  • Page 39 AI/DI03 System 1 coil temperature AI/DI02 Water output temperature AI/DI01 Water intput temperature 5V output +12V 12V output Electronic expansion valve 1 in system 1 Centralized control port Electronic expansion valve of EVI in system 1 ENERGIE Page | 37...
  • Page 40: Troubleshooting And Additional Information

    Water pump is running with high 2) Air in the installation 2) Purge the hydraulic circuit. noise or without water 3) Valves closed 3) Open the valves 4) Dirty or clogged 4) Clean the filter water filter ENERGIE Page | 38...
  • Page 41 Low water flow protection system; discharge the air in water loop. failure on flow switch replace the flow switch. ENERGIE Page | 39...
  • Page 42: Appendix 1 - Glossary

    Central heating (radiators, floor heating Expansion vessel or fan coils) Filter Hot water outlet (DHW) Valve (non-return) Buffer tank Water tank (DHW) Circulating pump 3 way valve Room thermostat Automatic air vent DHW thermostat Pressure reducing valve Thermostatic valve ENERGIE Page | 40...
  • Page 43: Appendix 2 - Hydraulic Schemes

    Normally, for heating the water is kept at 35 degrees for floor heating, 45 degrees for fan coil, 50 degrees for radiator, or other temperature at customer request. For cooling, the water can be cold down to 12 degrees for fan coil. ENERGIE Page | 41...
  • Page 44: Central Heating/ Cooling With Buffer Tank

    IMPORTANT: The control of the circulating pump “P1” must be carried out separately. 21.3 Central heating/ cooling with buffer tank + DHW IMPORTANT: The heat pump automatically manages the three way valve. The control of the circulating pump “P1” must be carried out separately. ENERGIE Page | 42...
  • Page 45: Central Heating/ Cooling + Dhw

    21.4 Central heating/ cooling + DHW IMPORTANT: The auxiliary control unit automatically manages the heat pump and the three-way valve depending on the temperature in the DHW tank and the ambient thermostat. 21.5 ENERGIE Page | 43...
  • Page 46: Appendix 4 - Wiring Diagrams

    ON/OFF” are inactive by default, giving priority to settings made through the console. To enable digital inputs, you must do the following steps: Press key to access the heat pump settings. Press 4 “Factory”; Enter the password 066; Change the setting from “master” to “slave”. ENERGIE Page | 44...
  • Page 47 0V) • 28/29 – DHW circulation pump output (DHW function activates 230Vac output voltage); • 30/31 – DHW tank temperature probe input (probe provided in installation kit); • 32/33 – Communication terminals via RS 485. ENERGIE Page | 45...
  • Page 48: Electrical Connections Inverter 5-18

    ON/OFF” are inactive by default, giving priority to settings made through the console. To enable digital inputs, you must do the following steps: 1. Press key to access the heat pump settings. Press 4 “Factory”; Enter the password 066; Change the setting from “master” to “slave”. ENERGIE Page | 46...
  • Page 49: Electrical Connections Inverter R 8-12 And Inverter R 5-18

    28/29 – Communication terminals via RS 485. 22.3 Electrical connections inverter R 8-12 and inverter R 5-18 WARNING: Do not connect (220/240V~) to the terminals mentioned bellow, as this may cause irreversible damage to the controller and loss of warranty. ENERGIE Page | 47...
  • Page 50 To change the configuration, click on the text “Wire controller” and a second window will automatically appear. In the second window, click on the text “1-Enable”, the configuration of the digital inputs will be automatically assumed. ENERGIE Page | 48...
  • Page 51 • 17/18 - Output for 3-way DHW valve (DHW function activates output voltage is 0V) • 19/20 - Output for DHW circulating pump (DHW function activates 230Vac output voltage); • 21/21 and 22/23 - command for support resistance (Imax = 1amp); ENERGIE Page | 49...
  • Page 52: Appendix 5 - Warranty

    Hot water tanks have been operating in water with the following indexes: o Active chlorine > 0.2 ppm; o Chlorides > 50 mg/l (Inox); o Hardness > 200 mg/l; o Conductibility > 600 μS/cm (20 ºC); ENERGIE Page | 50...
  • Page 53 Technical assistance costs even within the warranty period shall be supported by the customer (Km and assistance time). In cases where there is no justifiable breakdown and subsequent need for technical assistance, the client will pay for lost technical assistance time. ENERGIE Page | 51...
  • Page 54: Appendix 6 - Warranty Registration Card

    Please sing below and return to our Technical Dep. Via fax +351 252600239, email energie@energie.pt or post to the address above. Signature:____________________________________________________________________ Date: _______________________________________________________________________ ENERGIE est, lda Zona Industrial de Laúndos, Lote 48 4570-311 Laúndos – Povoa de Varzim – PORTUGAL ENERGIE Page | 52...
  • Page 55 Voltage of Supply: ____________________________ (measure this at unit) Current draw: ________________________________ (measure this at unit) Water flow temp: ______________________________ (from controller) Water return temp: _____________________________ (from controller) Please: include photo of unit, hot water cylinder, buffer tank, etc ENERGIE Page | 53...
  • Page 56 ENERGIE EST Address: Zona Industrial de Laúndos, Lote 48, 4570-311 Laúndos - Póvoa de Varzim, PORTUGAL General e-mail: energie@energie.pt...
