INSTALLATION AND USER MANUAL
EN
AQUAPURA THERMOBOX
Compatible with aerothermal heat pump range:
Aquapura 6 – Inverter R 3-8
Aquapura 12 – Inverter R 8-12
Aquapura 16 – Inverter R 5-18
Aquapura 16 T– Inverter R 5-18
Aquapura 14HT – Inverter P 6-16
Revision: 02
Version: 2
Date: 23/06/2023
160L | 200L | 270L
Advertisement
Related Manuals for Energie Aquapura 6
Summary of Contents for Energie Aquapura 6
- Page 1 INSTALLATION AND USER MANUAL AQUAPURA THERMOBOX 160L | 200L | 270L Compatible with aerothermal heat pump range: Aquapura 6 – Inverter R 3-8 Aquapura 12 – Inverter R 8-12 Aquapura 16 – Inverter R 5-18 Aquapura 16 T– Inverter R 5-18 Aquapura 14HT –...
- Page 2 Index Index 2 Safety Information ............. 4 Info .................. 6 Introduction ..............6 THERMOBOX Features ............6 Nomenclature and Dimensions ..........7 Installation dimensions (connections) – 160L ..........8 Installation dimensions (connections) – 200L / 270L ........8 Hydraulic Installation Scheme ..........9 Hydraulic Installation ............
- Page 3 Electrical connections between the heat pump and the Thermobox controlled by the display (160L model) ......25 Electrical connections between the heat pump and the Thermobox controlled by the display (200L and 270L model) ... 26 Electrical connections between the Heat Pump and Thermobox controlled by digital inputs (160L model) ........
-
Page 4: Safety Information
Installation and User Manual THERMOBOX Safety Information In order to protect the physical integrity of the operator, as well as the equipment, it is essential that all safety information noted in this manual is taken into account. The hydraulic and electrical connections must comply with the regulations in force at the place of installation. - Page 5 Installation and User Manual THERMOBOX DANGER Installation Description The equipment must be installed by qualified technicians. Improper installation can cause water leakage, electric shock or fire. Make sure that the THERMOBOX ground connection is properly connected. A bad connection can cause electric shock.
- Page 6 Installation and User Manual THERMOBOX Info This manual accompanies all equipment and contains important instructions that must be followed during installation. Introduction Dear Client, We are grateful for the preference you have given us, congratulating you for the purchase of a first- rate product and great innovation.
- Page 7 Installation and User Manual THERMOBOX Nomenclature and Dimensions 160L 200L e 270L Symbols 160L 200L 270L 1450 mm 1900 mm 2200 mm Ø580 mm 600 mm 600 mm 600 mm 600 mm...
- Page 8 Installation and User Manual THERMOBOX Installation dimensions (connections) – 160L Installation dimensions (connections) – 200L / 270L...
- Page 9 Installation and User Manual THERMOBOX Hydraulic Installation Scheme...
-
Page 10: Hydraulic Installation
Installation and User Manual THERMOBOX Hydraulic Installation INLET from the outdoor unit – 1”M OUTLET to outdoor unit -1”M RETURN from central heating&cooling – 1”M OUTLET to central heating&cooling – 1”M DHW Outlet – 3/4"M Cold water Inlet – 3/4”M Ball Valve Central heating&cooling safety valve (3 bar) DHW safety valve (6 bar) - Page 11 Installation and User Manual THERMOBOX Exterior Unit Connections 1- INLET from the exterior unit – 1”M 2- OUTLET to outdoor unit -1”M...
- Page 12 Installation and User Manual THERMOBOX Central Heating & Cooling Connections 3- RETURN from central heating&cooling – 1”M 4- Outlet to central heating&cooling – 1”M RADIANT FLOOR RADIATORES FAN-CONVECTORS...
-
Page 13: Cold Water
Installation and User Manual THERMOBOX DHW Connections 5- DHW Outlet – 3/4"M 6- Cold water Inlet – 3/4”M COLD WATER DOMESTIC HOT WATER DOMESTIC HOT WATER... - Page 14 Installation and User Manual THERMOBOX Recirculation 6- Cold water Inlet – 3/4”M RECIRCULATION...
- Page 15 Installation and User Manual THERMOBOX Filling the Hydraulic Circuit Ball Valve The valve must be opened for the filling of the hydraulic circuit (DHW circuit and central heating&cooling). Before putting the heat pump into operation, check that the hydraulic circuit is full and properly purged. If these two requirements are met, the valve must be closed.
- Page 16 Installation and User Manual THERMOBOX Disassembly for Maintenance / Installation (160L) An important aspect to consider is the most appropriate procedure for dismantling the equipment that may be necessary in the act of maintenance and/or installation. In the 160L model,to access the interior of the equipment, the fixing screws markedon the front of the equipment should be removed to allow unilateral opening of the helmet.
- Page 17 Installation and User Manual THERMOBOX Unscrew the two top screws that secure the upper part of the front cover to the top of the equipment's side “walls”. 3. Remove the front cover from the equipment. 4. Extract the 4 screws (2 top and 2 front) that fix the upper part to the equipment structure. 5.
-
Page 18: Technical Data
Installation and User Manual THERMOBOX Technical Data INTERIOR UNIT THERMOBOX THERMOBOX THERMOBOX 200 AquaPura 6 ● ● Compatible AquaPura 12 ● ● ● Outdoor Units AquaPura 16 ● ● AquaPura 14HT ● ● Operating modes Heating / Cooling / DHW... - Page 19 Installation and User Manual THERMOBOX EXTERIOR UNIT AQUAPURA 6 AQUAPURA 12 (INVERTER R 3 - 8) (INVERTER R 8-12) Power supply 208-240V~/50-60Hz 208-240V~/50-60Hz Heating 6,47 / 8,25 8,25 / 12,52 (Nom./Max) Power supplied Cooling 5,12 / 6,10 7,01 / 11,31 (Nom./Max)
- Page 20 Installation and User Manual THERMOBOX AQUAPURA 16 | 16T AQUAPURA 14HT (INVERTER R 5-18) (INVERTER P 6-16) Power supply 208-240V~/50-60Hz | 3N~/ 400V/ 50-60Hz 208-240V~/50-60Hz Heating 15,36 / 18,51 11,85 / 15,75 (Nom./Max) Power supplied Cooling (Nom./Max) 13,92 / 16,23 7,85 / 11,61 Heating (Nominal) 3,21...
-
Page 21: Installation
Installation and User Manual THERMOBOX Installation Installation location Before starting any installation procedure, check that the base of the place where the equipment will be placed is perfectly level. Look for a place with an even, safe and resistant floor considering the weight of the machine. - Page 22 Installation and User Manual THERMOBOX 12. Aquapura Thermobox (activate back-up electrical heater to DHW) The AQUAPURA THERMOBOX has an immersion electrical heater of 1500W integrated in the DHW water heater. The electrical heater is activated manually in case of any non-conformity in the equipment. To activate the resistance, connect the plug on top of the THERMOBOX to the socket (230V~).
- Page 23 Installation and User Manual THERMOBOX Wiring Scheme (160L model)
- Page 24 Installation and User Manual THERMOBOX Wiring Scheme (200L and 270L model)
- Page 25 Installation and User Manual THERMOBOX Electrical connections between the heat pump and the Thermobox controlled by the display (160L model) The Heat Pump operating modes are changed/executed via the display. This way we disable all digital inputs. In this type of configuration, it is assumed that there is no room thermostat to control the room temperature. In this sense, the Heat Pump is controlled by the return temperature.
- Page 26 Installation and User Manual THERMOBOX Electrical connections between the heat pump and the Thermobox controlled by the display (200L and 270L model) The Heat Pump operating modes are changed/executed via the display. This way we disable all digital inputs. In this type of configuration, it is assumed that there is no room thermostat to control the room temperature. In this sense, the Heat Pump is controlled by the return temperature.
- Page 27 Installation and User Manual THERMOBOX Electrical connections between the Heat Pump and Thermobox controlled by digital inputs (160L model) The operation modes of the Heat Pump are changed/executed through commands given in the digital inputs, thus, we make useless the possibility of changing the operating modes through the display.
- Page 28 Installation and User Manual THERMOBOX Electrical connections between the Heat Pump and Thermobox controlled by digital inputs (200L and 270L model) The operation modes of the Heat Pump are changed/executed through commands given in the digital inputs, thus, we make useless the possibility of changing the operating modes through the display. In this type of configuration, the existence of a room thermostat for temperature control and selection of operating modes is assumed.
- Page 29 Installation and User Manual THERMOBOX 19. Enable Digital Inputs HP WARNING: Do not connect (220/240V~) to the terminals of the digital inputs Remote On/Off, Remote Heat/Coll, DHW On/Off and Heat/Cool On/Off otherwise it may cause irreversible damage to the controller and loss of warranty.
- Page 30 Installation and User Manual THERMOBOX WARNING: Use cable protected with steel mesh in the connections of the digital inputs, this way we protect the digital inputs against noise coming from the compressor. Failure to use this type of cable can generate abnormal behavior in the operation of the equipment. The mesh must not be connected to the equipment's earth, but to the “GND”...
- Page 31 If detect something in the manual that is not clear or if you have any questions about the operation and maintenance of the equipment, which is not covered in this manual, please contact us.
