Technical Publication
Installation Guidelines - - HELIAX
Fiber/Copper Cables: HTC1006 │HTC606 │ HFA412 │DFJ
Related Support and Learning Opportunities Offered by the CommScope Infrastructure Academy
The insights and expertise contained in this manual represent just one small part of Andrew Solutions
global learning initiative. Few industries are evolving as quickly as wireless communications. Every
technological innovation impacts what happens in the field. Our customers look to the CommScope
Infrastructure Academy to make sure their technicians and installers are well trained, well-prepared,
and well-educated to take advantage of opportunities as they evolve.
Field Engineering Services (FES)
Support services, such as our Field Engineering Services (FES) Group gives Andrew Solutions' customers
access to technical support where and when it is needed the most - in the field. The FES team is
staffed by an expert team of technicians who, in turn, are supported by some of the brightest and
most experienced product line managers. With all of this knowledge and support the FES offers our
customers access to hands-on, specialized training classes.
Section 1: General Specifications .................................................................................................02
Section 4: Breakout Procedure / LC Connection Considerations ........................................................07
Section 5: All-in-One Cleaner / Inspecting ..............................................................................................08
Section 6: OVP Gland Identification / OVP Wiring ................................................................................09
Section 7: Excess Cable Management ..................................................................................................13
Section 8: Maintenance Check list / Fiber Troubleshooting ................................................................14
For more information, Contact Customer Service Center
United States and Mexico 1-800-255-1479 or 1-888-235-5732
International: +1-779-435-8579
For the most current, up-to-date information on all our products and product information please visit
our eCatalog section at www.commscope.com/andrew.
Visit www.commscope.com/andrew for complete specifications on all the products listed
FiberFeed
®
®
Trunk Cables .......................................................................................06
®
®
Solutions
®
Jumpers ...........................................................04
®
Bulletin # 7682214 Rev. B
1
Advertisement
Related Manuals for CommScope HELIAX FiberFeed HTC1006 Series
Summary of Contents for CommScope HELIAX FiberFeed HTC1006 Series
-
Page 1: Table Of Contents
Few industries are evolving as quickly as wireless communications. Every technological innovation impacts what happens in the field. Our customers look to the CommScope Infrastructure Academy to make sure their technicians and installers are well trained, well-prepared, and well-educated to take advantage of opportunities as they evolve. -
Page 2: Section 1: General Specifications
5.7 in 5.1 in Tensile Load, long term, maximum 90 lbf 90 lbf 90 lbf Tensile Load, short term, maximum 300 lbf 300 lbf 300 lbf Visit www.commscope.com/andrew for complete specifications on all the products listed Bulletin # 7682214 Rev. B... - Page 3 180 lbf 180 lbf Tensile Load, short term, maximum 607 lbf 607 lbf WARNING: CommScope Hybrid FiberFeed cables require the use of approved installation accessories. ® Visit www.commscope.com/andrew for complete specifications on all the products listed Bulletin # 7682214 Rev. B...
-
Page 4: Section 2: Cable Construction / Heliax ® Fiberfeed ® Jumpers
Minimum cable bend radii can be found in this document or on-line. • Standard lengths available are 3-6-15 foot for top tails and 3-6-15-20 foot for bottom tails. • All jumpers are individually serialized, for immediate access to test results visit www.commscope.com/webtrak/ • Power connector is supplied with the RRU •... - Page 5 Weather boot END 1 (RRU) END 2 (Junction box) DFJ-4S010 fiber tails, 4 Fibers LC Duplex Connectors Weather boot END 1 (BBU) END 2 (Junction box) Visit www.commscope.com/andrew for complete specifications on all the products listed Bulletin # 7682214 Rev. B...
-
Page 6: Section 3: Heliax ® Fiberfeed ® Trunk Cables
Location grip before applying tension to the line. Reminder: Plan grip location by measuring distance (D) from Fiber Enclosure Box to tower support member. Visit www.commscope.com/andrew for complete specifications on all the products listed Bulletin # 7682214 Rev. B... -
Page 7: Section 4: Breakout Procedure / Lc Connection Considerations
Do not try to clean the adapter with cleaning stick if a connector is mounted in one side. Discard cleaning sticks after each use. Adapter Brush Visit www.commscope.com/andrew for complete specifications on all the products listed Bulletin # 7682214 Rev. B... -
Page 8: Section 5: All-In-One Cleaner / Inspecting
Abrasive particles (i.e. rock dust) can cause permanent damage to the interface. If interface is scratched it cannot be repaired, it would need to be replaced. Visit www.commscope.com/andrew for complete specifications on all the products listed Bulletin # 7682214 Rev. B... -
Page 9: Section 6: Ovp Gland Identification / Ovp Wiring
HFT606 Sector Trunk holes for HFA412 Jumper M40 gland with 3 holes M40 Gland for 1-1/2 Conduit Fitting DFJ-4S Fiber only Jumpers HFT606 Sector Trunk Visit www.commscope.com/andrew for complete specifications on all the products listed Bulletin # 7682214 Rev. B... - Page 10 Install jumpers left to right to allow for future expansion Drawing shown with Qty 1: HFT606-24S37 series trunk and Qty 3: HFA412-4S-39 series jumpers Visit www.commscope.com/andrew for complete specifications on all the products listed Bulletin # 7682214 Rev. B...
- Page 11 M63 gland insert with 1-1/4 " or 1" NPT 1-1/4 Conduit Fitting 9 holes for DFJ-4S Fiber gland insert with Jumpers 3 holes for DFJ-4S Fiber Jumpers Visit www.commscope.com/andrew for complete specifications on all the products listed Bulletin # 7682214 Rev. B...
- Page 12 Install jumpers left to right to allow for future expansion Drawing shown with Qty 1: HFT606-24S37 series trunk and Qty 3: HFA412-4S-39 series jumpers Visit www.commscope.com/andrew for complete specifications on all the products listed Bulletin # 7682214 Rev. B...
-
Page 13: Section 7: Excess Cable Management
Scan to view video NOTE: Remember to slide identifier labels down the power conductors before trimming the cable Click here to it’s final length for video Visit www.commscope.com/andrew for complete specifications on all the products listed Bulletin # 7682214 Rev. B... -
Page 14: Section 8: Maintenance Check List / Fiber Troubleshooting
Hinweis: CommScope lehnt jede Haftung oder Verantwortung für Schäden ab, die aufgrund unsachgemäßer Installation, Überprüfung, Wartung oder Demontage auftreten. Atenção: A CommScope abdica do direito de toda responsabilidade pelos resultados de práticas inadequadas e sem segurança de instalação, inspeção, manutenção ou remoção.
