Summary of Contents for TES TES-1358

  • Page 1 Sonómetro Analizador Octavas de Banda, Tipo 1, TES TE-1358E...
  • Page 2 Sound Analyzer Real Time 1/1 & 1/3 Octave band Analysis TES-1358 INSTRUCTION MANUAL FAST 75.2 dB 31.5 [ 1 / 3 OCT ] 01 / 07 / 27 14:26:39 TES ELECTRICAL ELECTRONIC CORP.
  • Page 3: Table Of Contents

    CONTENTS Title Page SAFETY INFORMATION............. 1 GENERAL & FEATURES ............ 2 III. SPECIFICATIONS ............... 2 CONTROLS AND FUNCTIONS .......... 5 4-1 Parts description ................5 4-2 Operation keys ................7 4-3 Measurement screen ..............10 CALIBRATION PROCEDURES ........11 MEASUREMENT PREPARATION ........12 VII.
  • Page 4: Safety Information

    I. SAFETY INFORMATION  Read the following safety information carefully before attempting to operate or service the meter.  Use the meter only as specified in this manual; otherwise, the protection provided by the meter may be impaired.  Environment conditions ...
  • Page 5: General & Features

    II. GENERAL & FEATURES The sound analyzer meter allows digital 1/1-octave and 1/3-octave analysis in real time.  Five measured parameters SPL (Sound Pressure Level), Leq (Equivalent Continuous Sound Pressure Level), L (Sound Exposure Level), Lmax (Maximum Sound Pressure Level), Lmin (Minimum Sound Pressure Level) ...
  • Page 6  Accuracy : ±1.5dB (ref 94dB @1kHz)  Measurement Frequency range : 25Hz – 10KHz  Dynamic range : 100dB (Sound level meter mode) 70dB (Frequency analysis mode)  Measurement range : 30dB – 130dB  Sound Pressure Level range: Sound level meter mode (display range 100dB) : 30 –...
  • Page 7  AC output : 2 Vrms at FS (full scale). output impedance approx. 600Ω.  DC output : 10mV/dB. output impedance approx. 100Ω.  Power : 4 pcs of C size 1.5V (LR14) alkaline batteries. External DC power supply : 6 Vdc, 1A. ...
  • Page 8: Controls And Functions

    IV. CONTROLS AND FUNCTIONS 4-1 Parts description FAST 65.2 dB 31.5 [ 1 / 3 OCT ] 01 / 06 / 19 14:26:39 SOUND ANALYZER 1/1 & 1/3 OCTAVE BAND IEC 651 IEC 804 TYPE 2 IEC 1260 CLASS2 ACCURACY : ¡ Ó 1 .5dB IEC LR14 1.5V X 4 1.
  • Page 9 3. Display The backlit liquid crystal display has a resolution of 160×160 dots. 4. Operation keys 5. Power switch This sliding switch serves to turn the unit on and off. 6. Calibration adjust knob Serves to carry out calibration, using the supplied adjustment screwdriver.
  • Page 10: Operation Keys

    4-2 Operation keys MODE Serves to call up the various processing results on the display. For display items are sound pressure level (L), equivalent continuous sound pressure level (Leq), Sound exposure level (L ), maximum sound pressure level (Lmax), and minimum sound pressure level (Lmin).
  • Page 11 LEVEL Serves to select the sound pressure level ranges on 1/1 and 1/3 octave band frequency analysis mode. (20~90dB, 30~100dB, 40~110dB, 50~120dB and 60~130dB, total 5 ranges) e.) SLM/ 1/1/ 1/3 key This key switches the operation mode between sound level meter (SLM), 1/1-octave frequency analysis (1/1), and 1/3-octave frequency analysis (1/3).
  • Page 12 sound pressure level measurement. k.) PAUSE/CONT key Server to the measurement temporarily pause ( display) or resume (display ). l.) 2nd key Press to shift key to second function. m.) STORE key In manual memory mode, store the measured data into the memory.
  • Page 13: Measurement Screen

    4-3 Measurement screen 1. Sound pressure level measurement screen FAST ] 01 / 07 / 27 14:26:39 2. 1/1-octave analysis screen The staircase shape on the display represents the 1/1-octave analysis result. From left, the bars correspond to 31.5, 63, 125, 250, 500, 1k, 2k, 4k, 8kHz.
  • Page 14: Calibration Procedures

    75.2 dB 31.5 [ 1 / 3 OCT ] 01 / 07/ 27 14:26:39 V. CALIBRATION PROCEDURES Using a standard acoustic calibrator such as the TES-1356. 1. Make the following switch settings. Display : SLM (L Time weighting : FAST 2.
  • Page 15: Measurement Preparation

    VI. MEASUREMENT PREPARATION 1. Battery loading Remove the battery cover on the back and put in four 1.5V C size battery. Note : Take care to observe battery polarity. 2. Battery replacement When the battery voltage drops below the operation voltage. LBATT appears and flashes in the display.
  • Page 16: Sound Pressure Level Measurement

    VIII. SOUND PRESSURE LEVEL MEASUREMENT 8-1 Technical notes 1. The decibel (dB) The range over which the human ear responds to sound pressure (noise) is extremely large ; 20Pa (the threshold of hearing) to 100 Pa (the threshold of pain). The measurement of sound pressure is made manageable by use of the decibel, which is logarithmic.
  • Page 17: Instantaneous Sound Pressure Level Measurement (L A , L C , L P )

    platform, to be evaluated. Another event, such as the next train, which lasts for a different amount of time can be measured in the same way. The two readings can be compared to assess how much total noise the passengers standing at the platform were exposed to by each train.
  • Page 18 FAST FAST 75.2 dB 75.2 dB Hz 31.5 3 1 . 5 [ 1 / 1 OCT ] 01 / 07 / 27 14:26:39 [ 1 / 3 OCT ] 01 / 07/ 27 14:26:39 3. Use the FREQ WGHT key to select the desired L frequency weighting setting.
  • Page 19: L Eq And L E Measurement

    8-3 L and L measurement To perform a measurement, carry out the following steps. 1. Set the power switch to ON and wait until the measurement screen appears. 2. Press the MEAS TIME key, setting the preset measurement time for a fixed time period (know as the integral time), after which measurement automatically stops.
  • Page 20 3. Use the SLM/ 1/1/ 1/3 key to select desired SLM, 1/1 or 1/3 octave band sound pressure level measurement screen. 4. Use the FREQ WGHT key to select the desired L or L frequency weighting setting. 5. Use the TIME CONST key to select the desired FAST or SLOW time constant setting.
  • Page 21: Memory Function

    IX. MEMORY FUNCTION The sound analyzer incorporates a memory that allows manual and automatic storing of measurement data. Stored measurement results can be displayed by pressing the RECALL key. MANU (manual store) Measured instantaneous value data and processing results can be stored manually by the operator.
  • Page 22 5. Press MEMORY key again, exit the memory mode.
  • Page 23: Reading From Memory

    9-2 Reading from memory 1. Press MEMORY key, enter memory mode, display M []. 2. Press RECALL key, display R [] record number and data value. If no data record in memory, Press RECALL key is no active. FAST 75.2 dB 31.5 [ 1 / 1 OCT ] 01 / 07 / 27 14:26:39 3.
  • Page 24: Auto Storing Data In Memory

    9-3 Auto storing data in memory Before auto store data, first need setting record interval period. When in auto store data function, can not view other parameter measurement. 1. Setting record interval period : Record interval period value default value is “0”, can not auto store. Press 2nd key, then press MEMORY key to select the desired setting time, the period time is : 0sec (No record) 1sec3sec...
  • Page 25 6. Press START/STOP key, then auto storing display data to memory. The upper of the screen shown “ S Auto ” and  annunciator. FAST 75.2 dB 31.5 [ 1 / 1 OCT ] 01 / 07 / 27 14:26:39 CAUTION : When in auto store mode, can not change any parameter setting.
  • Page 26: Erase Memory Data

    9-4 Erase memory data 1. When the instrument memory is full, the FULL annunciator appears in the upper right hand corner of the screen. ID No: 00001358 Ver: 0.10 ALL Memory are Erased !! FAST SOUND LEVEL METER 1/1 & 1/3 Octave Band Real-Time Analyzer ] 01 / 07 / 27 14:26:39 Self-Testing..OK!!
