- Page 1 IEVO-M micro™ Fingerprint Reader IEVO-M ievo® micro™ Fingerprint Reader Installation Manual...
-
Page 2: Table Of Contents
IEVO-M micro™ Fingerprint Reader 1] CONTENTS TITLE PAGE 2] Package Contents 3] Technical Features 4] Introduction Standards Help & Support 5] Installation Guidance Power Reader Head Cabling Wiegand Cabling Network 6] Control Board Connections 7] Door Wiring Example 8] Surface Mount Installation 9] Flush Mount Installation Installation Complete 10] Product Disposal... -
Page 3: Package Contents
IEVO-M micro™ Fingerprint Reader 2] PACKAGE CONTENTS Phoenix 5m CAT6 Reader Connector Back plate cable Head (CTF-03008) 3] TECHNICAL FEATURES Description Data Connection Shielded (S-FTP) Cat5e/6 cable Voltage Current Draw 400mA Communication RS-422 (1Mbit/s) Controller ievo Control Board Operating Temperature 0~60ºC Power Indicator IP Rating... -
Page 4: Introduction
Government agency established by the Communications Act of 1934 which regulates all interstate communications. HELP & SUPPORT If at any point during installation you need help, please contact the Technical Support Team: Telephone (UK): +44 (0) 1628 531300 Email: support.ievo@cdvi.co.uk Website: www.ievoreader.com/Support... -
Page 5: Installation Guidance
IEVO-M micro™ Fingerprint Reader 5] INSTALLATION GUIDANCE The micro™ reader is suitable for internal use only. The micro reader can be either flush or surface mounted. Ensure you use the correct fixings and plugs for the type of wall for which you are fixing the reader. Incorrect usage can result in the Micro reader being unsecure. -
Page 6: Reader Head Cabling
IEVO-M micro™ Fingerprint Reader READER HEAD CABLING Each micro reader uses a bespoke PoE (Power over Ethernet) connection to the ievo Control Board, carrying both power and data. Therefore, you must use a high-quality shielded Ethernet cable to prevent power and data loss. Each reader comes provided with a 5m CAT6 SFTP (braid-shielded cable, foil-shielded pairs) Ethernet cable. -
Page 7: Control Board Connections
IEVO-M micro™ Fingerprint Reader 6] CONTROL BOARD CONNECTIONS... -
Page 8: Door Wiring Example
IEVO-M micro™ Fingerprint Reader 7] DOOR WIRING EXAMPLE ACU Power Supply Unit Network Access Switch Control Unit Lock Power Ethernet Reader Cable Wiegand Cable Ground Connection... -
Page 9: Surface Mount Installation
IEVO-M micro™ Fingerprint Reader 8] SURFACE MOUNT INSTALLATION STEP 1: Use the wall plate to mark out the size of the hole required for the Micro reader cable. Alternatively, you can push out the plastic notch at the top of the wall plate and feed the ethernet cable through the hole so that it can be hidden within conduit above the reader. -
Page 10: Flush Mount Installation
IEVO-M micro™ Fingerprint Reader STEP 4: STEP 5: Tilt the micro reader head back and clip Push the Micro reader firmly until the the top security clip onto the backplate, security clips click into place. once attached, push the rest of reader onto the back plate. -
Page 11: Installation Complete
2 screws provided. INSTALLATION COMPLETE Please move onto the applicable software manual for your system. You can download all our manuals and installation guides from: www.cdvi.co.uk/cat/ievo-biometric-solutions... -
Page 12: Product Disposal
IEVO-M micro™ Fingerprint Reader 10] PRODUCT DISPOSAL When the product reaches the end of its useful life, it must not be disposed of in normal waste. The product must be disposed of at an authorised recycling plant. The ievo Control Board contains a Lithium metal primary coin cell battery (location highlighted below) and should be removed by a competent engineer prior to disposal. - Page 13 IEVO-M micro™ Fingerprint Reader Notes ..................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
- Page 14 +39 (0) 321 90 573 - www.cdvi.it CDVI MAROC +212 (0) 5 22 48 09 40 www.cdvi.ma CDVI NORDICS [SWEDEN - DENMARK - NORWAY - FINLAND] +46 (0) 31 760 19 30 www.cdvi.se CDVI UK [UNITED KINGDOM - IRELAND] +44 (0) 1628 531300 www.cdvi.co.uk...
