Chapter 2
3 Installing the Sensor
There are three mounting accessories available from Hydronix.
Standard mounting sleeve (part no 0025)
3.1
The Hydro-Probe XT can also be mounted vertically using the Standard Mounting Sleeve,
however Hydronix would recommend using the Flanged Mounting Sleeve, see Figure 15
218mm
Extension mounting sleeve (part no 0026)
3.2
For installation in larger bins.
A
A – Sensor is secured to the inner sleeve by 6 hex screws (use Locktite or similar) on screw threads
B – Outer sleeve welded to bin
22 Hydro-Probe XT User Guide HD0538 Rev: 1.6.0
<338mm
Figure 13: The standard mounting sleeve (part no 0025)
<583mm
440mm
Figure 14: The extension mounting sleeve (part no 0026)
50mm
170mm
B
50mm
305mm
Bin Wall
Mechanical Installation
