Chapter 5
2.3.2 Calibration inside the control system
The advantages of calibrating inside the control system are:
Direct calibration without the need for an additional computer or RS485 adapter.
•
No need to learn how to use additional software.
•
If it is necessary to replace the sensor, a replacement Hydronix sensor can be
•
connected and valid results obtained immediately without connecting the sensor to
a PC to update the material calibration.
Calibrations can be switched automatically when materials change
•
• Calibrations can be easily transferred between sensors..
46 Hydro-Probe XT User Guide HD0538 Rev: 1.6.0
Unscaled

Figure 36: Calibration inside the control system

Sensor Integration and Calibration
Unscaled converted to moisture
True
moisture
