- Page 1 Core Health & Fitness Inspiration Back Extension OWNER’S MANUAL...
-
Page 2: Table Of Contents
TABLE OF CONTENTS PRODUCT SPOTLIGHT ............................. 2 IMPORTANT SAFETY INSTRUCTIONS ............................. 3 IMPORTANT LABEL LOCATIONS ............................. 5 OPERATIONS ............................. 6 ASSEMBLY ............................. 7 TOOLS ..................7 ..................8 PROCEDURE MAINTENANCE ............................. 9 SUPPORT & SERVICE ............................13 Page 1... -
Page 3: Product Spotlight
PRODUCT SPOTLIGHT IPBE3 Inspiration Back Extension Overall Weight Stack Weight Width Length Height User Weight 560 lb (255 kg) 200 lb (91 kg) 51” (130 cm) 50” (127 cm) 64” (163 cm) 0-350 lbs (0-158 kgs) Page 2... -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING! Before using this product, it is essential to read the ENTIRE Owner’s Manual and ALL installation instructions. The Owner’s Manual describes equipment setup and instructs members on how to use correctly and safely. Read all warnings posted on the machine. Health related injuries may result from incorrect or excessive use of exercise equipment. - Page 5 Always replace any cable at first sign of wear. Routinely inspect all cable couplers that join movement arms to the cables and replace at the first sign of wear. (consult Nautilus if uncertain or if you have questions regarding wear). 8. Use only replacement components supplied by Nautilus®.
-
Page 6: Important Label Locations
IMPORTANT LABEL LOCATIONS This page shows examples of the Nautilus® Leverage Strength® warning labels and communication stickers placed on the equipment as part of the manufacturing process. It is critical that owners maintain the integrity and placement of these stickers. If you find any stickers missing or damaged each sample indicated includes its corresponding part number so that replacements may be ordered. -
Page 7: Operations
OPERATIONS Page 6... -
Page 8: Assembly
ASSEMBLY TOOLS Description 731-1640-XX WELDMENT, FOOT SUPPORT, IPBE 731-0355 WASHER,PLAIN,M8,REGULAR 731-0365 NUT,M8 X 1.25,NYLOC JAM 731-0398 SCREW,M10X1.5,20MM,BHC,HK,CS,NP 731-0363 M10 - 1.5 THREAD HEX LOCKNUT 731-0367 WASHER,PLAIN,M10 N02-9345 SCREW M10 X 1.5 X 140 SHC HK AS, ZP Required Tools: • Ratchet Wrench •... -
Page 9: Procedure
PROCEDURE 1. Use a ratchet wrench with a 5mm allen socket and a 13mm open-ended wrench to secure the foot support (731-1640-XX) to the frame using two (2) pieces each of the M8 x 70mm button head cap screw (731-0398) and M8 nylock nut (731-0365), and four (4) pieces of the M8 flat washer (731-0355). -
Page 10: Maintenance
Cleaning Keeping your Nautilus® Inspiration Strength® units clean is an important component of preventative maintenance and the overall aesthetics of your product. While your clients will appreciate clean equipment free of sweat, dirt and other contaminants proper care and cleaning will extend the life of your product and reduce premature aging and wear. - Page 11 Inspection Visual inspection of your Nautilus® Inspiration Strength® units will insure a safe environment for your clients and alert you to any issues that may require maintenance prior to equipment failure. Proper, timely visual inspection is a critical component to the long term care of your product.
- Page 12 With durable, high performance components, this equipment is designed for heavy usage with minimal maintenance required. To keep it in top condition, perform regular daily, weekly and monthly preventive maintenance routines out- lined below. The safety and integrity of this machine can only be maintained when the equipment is regularly examined for damage and wear and repaired.
- Page 13 WARNING: Replace all worn cables immediately. The following conditions indicate some types of wear. Torn or Cracked Cable Sheath that exposes cable Stretched Cable Sheath Kink in the Cable Lubrication Proper cleaning lubrication of guide rods will insure that each machine operates at its highest potential and that your clients continue to enjoy a smooth efficient motion while exercising.
-
Page 14: Support & Service
SUPPORT & SERVICE CORE Get world class support for all brands with our new support portal, Core Connect. Get help with your general inquiries, warranty registration, preventative maintenance, service requests and parts orders. You can CONNECT also make seamless service requests, get real time updates, manage your assets and intuitively order parts for all brands direct from the site. - Page 15 THIS PAGE INTENTIONALLY LEFT BLANK Page 14...
- Page 16 © 2019 CORE HEALTH & FITNESS, LLC PART NUMBER 19-7976, REV C...
