CORE HEALTH & FITNESS
INSPIRATION MULTISTATIONS
OWNER'S
MANUAL
CONTACT SUPPORT NOW

Advertisement

loading
Need help?

Need help?

Do you have a question about the INSPIRATION and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Nautilus INSPIRATION

Summary of Contents for Nautilus INSPIRATION

  • Page 1 CORE HEALTH & FITNESS INSPIRATION MULTISTATIONS OWNER'S MANUAL CONTACT SUPPORT NOW...
  • Page 2 TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS ........................3 IMPORTANT LABEL LOCATIONS ........................5 ASSEMBLY ........................7 Multistation Weight Tower ..............7 Cable Cross / Hi-Low ..............9 Low Row ..............21 Triceps Press ..............27 Lat Pull Down ..............33 Mid Row ..............39 REPLACEMENT PARTS ........................46 731-7725-XX - Boom With Pull Up Bars ............
  • Page 3 IMPORTANT SAFETY INSTRUCTIONS WARNING! Before using this product, it is essential to read the ENTIRE Owner’s Manual and ALL installation instructions. The Owner’s Manual describes equipment operation and instructs members on how to use correctly and safely. Read all warnings posted on the machine. Health related injuries may result from incorrect or excessive use of exercise equipment.
  • Page 4 Nautilus equipment. 6. This machine is not intended to be used by children. It is not intended to be used by persons with reduced physical, sensory, or mental capabilities or lack of experience and knowledge,...
  • Page 5 IMPORTANT LABEL LOCATIONS This page shows the location of the warning labels and communication stickers placed on the equipment as part of the manufacturing process. It is critical that owners maintain the integrity and placement of these stickers. If you find any stickers missing or damaged the replacement numbers are shown on the support site and following pages.
  • Page 6 731-8048 731-7311 731-0517 STICKER,WARNING,2ND STICKER, NAUTILUS STICKER, WARNING, BOLT DOWN BUTTON 731-4439 731-8118 731-7348 STICKER,ADD ON, MULTI STA- STICKER,INSTRUCTIONS,TROLLEY PLACARD,CABLE CROSS, NAU TION 731-7350 731-7351 731-7349 PLACARD,LOW ROW, NAU PLACARD,TRICEPS PRESS, NAU PLACARD,LAT PULL, NAU 731-7723-02 731-7723-01 731-0512 STICKER, WARNING, ATTACH-...
  • Page 7 ASSEMBLY Please note that if two stations located next to each other use the same mounting position on the weight tower, the bracket mounts (731-3221-XX) are not used. Required Tools: • Ratchet Wrench • 5mm Allen Key • 13mm Socket •...
  • Page 8 731-3185 731-3186 Use a #2 phillips screwdriver to remove the two (2) screws (731-3186) securing the tower cap (731-3185) to the frame. Notice: After installing the last station to the weight tower, this cap will need to be installed. Fig. 4 Page 8...
  • Page 9 Cable Cross / Hi-Low 731-0363 731-0367 Use a ratchet wrench with a 16mm socket and 16mm open-ended wrench to secure 731-0367 the post mount weldment (731-3157-XX) to the weight 110-3802 tower using two (2) 110-3802, 110-3802 731-0367 two (2) 731-5516, eight (8) 731-0363 731-0367, and four (4) 731- 0363.
  • Page 10 3. Use a 5mm allen key to loosen the screws in the guide rod collars (140-3821), the guide rods should drop down into the frame. If they don’t pull downwards until they do. Notice: After installing the weight stack and setting the guide rods and caps back 140-3821 into place, these screws are...
  • Page 11 731-3142 5. Starting from the bottom of the weight stack (731-3642), carefully slide each weight plate down onto the guide rods. Notice: After installing the weight stack and setting the guide rods and caps back into START place, the guide rod collar screws are REQUIRED to be torqued to 11.5 Ft-Lbs (15 Nm) using a torque wrench with a 5mm allen...
  • Page 12 731-0363 731-0367 7. Use a ratchet wrench with a 16mm socket and 16mm open- ended wrench to secure the upper support weldment (731- 3188-XX) to the weight tower using three (3) 110-3814, three (3) 731-0363, and six (6) 731-0367) - DO NOT FULLY TIGHTEN.
  • Page 13 731-1878 731-7520 10. With the trolley assembly (731- 8075 + 731-8027) installed 731-8075 onto the guide tube (731-1878), install the guide tube onto the 731-8027 post mount and upper support weldments. 731-7521 Fig. 13 731-3161 11. Use an 8mm allen key to secure the guide tube to the upper support weldment using one 731-1878...
  • Page 14 731-7521 12. Use a 6mm allen key to secure the guide tube to the post mount weldment using two (2) 731-2448, then slide the lower bumper (731- 7521) down into position. 731-1878 731-3157-XX 731-2448 Fig. 15 110-3883 13. Use a ratchet wrench with a 731-0367 16mm socket and 16mm open- ended wrench to install the pulley...
  • Page 15 731-8119 Pulley 2 14. Route the cable (731-8119) over the top of Pulley 1, then under Pulley 2. Pulley 1 Fig. 17 Pulley 4 Pulley 3 15. Route the cable over the top of Pulley 3 and Pulley 4. 731-8119 Fig.
  • Page 16 731-8119 Pulley 5 16. Route the cable under Pulley 5 from the front to the back of the pulley. Fig. 19 Pulley 6 17. Route the cable over Pulley 6 from the front to the back of the pulley. 731-8119 Fig.
  • Page 17 18. Route the cable under Pulley 7 and Pulley 8. Pulley 8 Pulley 7 731-8119 Fig. 21 731-0365 19. Use a 13mm open-ended wrench to secure the end of the cable 731-0922 to the trolley handle (731-8027) using one (1) 731-0922 and one (1) 731-0365.
  • Page 18 731-0363 20. Use a 6mm allen key and a 16mm 731-0367 open-ended wrench to secure the left ballet bar (731-3199) and 731-3174 ballet bar mount (731-3174) to the weight tower using two (2) 731-3223 and 731-0363, and four 731-0367. 21. Repeat for the right side ballet bar (731-3194).
  • Page 19 731-0363 731-3188-XX 731-0367 731-3128-XX 24. Use a ratchet wrench with a 16mm socket and a 16mm open- ended wrench to attach one end of the chin up bar (731-3128-XX) and the bracket connector (731- 3126-XX) to the upper support weldment using eight (8) 731- 731-3126-XX 5516 and 731-0363, and sixteen (16) 731-0367.
  • Page 20 26. Use a 4mm allen key to attach 731-7348 the Hi-Low/Cable Cross placard weldment (731-3164-XX) to the 731-1194 weight tower frame using three (3) 731-1194. Ensure that the placard (731-7348) and add on decal (731-4439) are properly 731-3164-XX positioned on the placard weldment.
  • Page 21 Low Row 1. Remove the backing from the 731-5439 double stick tape located on the underside of the weight stack stop (731-5439), then install the stop onto the weight stack tower between the guide rods. Fig. 29 2. Use a 5mm allen key to loosen the screws in the guide rod collars (140-3821), the guide rods should drop down into the frame.
  • Page 22 731-5210 3. Gently pull the guide rods forward (731-3193) then remove the guide rod caps (731-5210). 731-3193 Fig. 31 731-3641 4. Starting from the bottom of the weight stack (731-3641), carefully slide each weight plate down onto the guide rods. START Notice: After installing the weight stack and setting the...
  • Page 23 5. Use a ratchet wrench with a 731-0363 16mm socket and 16mm open- ended wrench to secure the 731-3632-XX upper support weldment (731- 3632-XX) and bracket connector (731-3178-XX) to the weight tower using two (2) 731-5516, two (2) 731-0363, and four (4) 731-0367 - DO NOT FULLY TIGHTEN.
  • Page 24 8. Set the seat frame (731-3622- 731-3622-XX XX) into place against the weight tower. Fig. 35 731-0363 9. Use a ratchet wrench with a 731-3221-XX 16mm socket and 16mm open- ended wrench to secure the 731-0367 right side of the seat frame to the weight tower using one (1) 110-3783 bracket mount (731-3221-XX),...
  • Page 25 731-3646 731-0731 731-3209 731-2016 10. Route the cable (731-3346) under 731-4183 the pivot pulley (731-0731) and up towards the upper support weldment. Fig. 37 731-0731 11. Route the cable over the top of the upper support weldment pulley (731-0731) and down through the frame.
  • Page 26 731-3646 12. Thread the cable lock nut (731- 731-2527 2527) onto the end of the cable, then use a 10mm open-ended 731-3169 wrench to screw the cable end into the cable mount (731-4597). 731-4597 13. Use a 16mm open-ended wrench to tighten the cable lock nut to secure the cable into the cable mount.
  • Page 27 Triceps Press 731-5439 1. Remove the backing from the double stick tape located on the underside of the weight stack stop (731-5439), then install the stop onto the weight stack tower between the guide rods. Fig. 41 2. Use a 5mm allen key to loosen the screws in the guide rod collars (140-3821), the guide rods should drop down into the frame.
  • Page 28 731-5210 3. Gently pull the guide rods forward (731-3193) then remove the guide rod caps (731-5210). 731-3193 Fig. 43 731-3204 4. Starting from the bottom of the weight stack (731-3204), carefully slide each weight plate down onto the guide rods. Notice: After installing the weight stack and setting the START...
  • Page 29 731-7525-XX 5. Set upper weldment (731-7525- XX) into place against the weight tower. Fig. 45 731-0363 6. Use a ratchet wrench with a 731-0367 16mm socket and 16mm open- 731-7525-XX ended wrench to secure the upper support weldment (731- 7525-XX) and bracket connector (731-3178-XX) to the weight tower using two (2) 731-5516, two (2) 731-0363, and four (4)
  • Page 30 731-0363 7. Use a ratchet wrench with a 16mm socket and 16mm open- ended wrench to secure the upper support weldment (731- 3188-XX) to the weight tower using three (3) 110-3814, three (3) 731-0363, and six (6) 731-0367) - DO NOT FULLY TIGHTEN. 731-7525-XX 8.
  • Page 31 731-3212 10. Thread the cable lock nut (731- 731-5058 5058) onto the end of the cable, then use a 10mm open-ended wrench to screw the cable end 731-3169 into the cable mount (731-4597). 11. Use a 16mm open-ended wrench 731-4597 to tighten the cable lock nut to secure the cable into the cable mount.
  • Page 32 731-0363 731-0367 110-3783 13. Use a ratchet wrench with a 16mm socket and 16mm open- 731-3221-XX ended wrench to secure the right side of the back pad weldment 731-3203-XX to the weight tower using one (1) bracket mount (731-3221-XX), two (2) 110-3783 and 731-0363, and four (4) 731-0367.
  • Page 33 Lat Pull Down 1. Remove the backing from the double stick tape located on the underside of the weight stack stop (731-5439), then install the stop onto the weight stack tower between the guide rods. 731-5439 Fig. 53 2. Use a 5mm allen key to loosen the screws in the guide rod collars (140-3821), the guide rods should drop down into the frame.
  • Page 34 731-5210 3. Gently pull the guide rods forward (731-3193) then remove the guide rod caps (731-5210). 731-3193 Fig. 55 731-3641 4. Starting from the bottom of the weight stack (731-3641), carefully slide each weight plate down onto the guide rods. Notice: After installing the weight stack and setting the START...
  • Page 35 731-3648-XX 5. Set the seat weldment (731-3648- XX) into place against the weight tower frame. Fig. 57 110-3783 731-0363 6. Use a ratchet wrench with a 731-0367 16mm socket and 16mm open- ended wrench to secure the right 731-3648-XX side of the back pad weldment to the weight tower using one (1) 731-3221-XX bracket mount (731-3221-XX),...
  • Page 36 731-7525-XX 7. Set upper weldment (731-7525- XX) into place against the weight tower. Fig. 59 731-0363 731-0367 731-7525-XX 731-3178-XX 8. Use a ratchet wrench with a 16mm socket and 16mm open- ended wrench to secure the upper support weldment (731- 7525-XX) and bracket connector (731-3178-XX) to the weight tower using two (2) 731-5516,...
  • Page 37 731-0363 9. Use a ratchet wrench with a 16mm socket and 16mm open- ended wrench to secure the upper support weldment (731- 3188-XX) to the weight tower using three (3) 110-3814, three (3) 731-0363, and six (6) 731-0367) - DO NOT FULLY TIGHTEN. 10.
  • Page 38 731-4187 12. Thread the cable lock nut (731- 731-5058 5058) onto the end of the cable, then use a 10mm open-ended 731-3169 wrench to screw the cable end 731-4597 into the cable mount (731-4597). 13. Use a 16mm open-ended wrench to tighten the cable lock nut to secure the cable into the cable mount.
  • Page 39 Mid Row The Mid Row retrofit station (731-9542-XXXXX) can ONLY be used in place of a Low Row (731-7723-XXXX) or a Lat Pull (731-7726-XX) station due to weight stack compatibility. If installing the Mid Row retrofit station, please skip to Page 41 Step 5 after removing a Low Row or Lat Pull station.
  • Page 40 3. Gently pull the guide rods forward (731-3193) then remove the guide 731-5210 rod caps (731-5210). 731-3193 Fig. 67 731-3641 4. Starting from the bottom of the weight stack (731-3641), carefully slide each weight plate down onto the guide rods. Notice: After installing the weight stack and setting the guide rods and caps back into...
  • Page 41 731-0363 5. Use a ratchet wrench with a 731-0367 731-3632-XX 16mm socket and 16mm open- ended wrench to secure the upper support weldment (731- 3632-XX) and bracket connector (731-3178-XX) to the weight tower using two (2) 731-5516, two (2) 731-0363, and four (4) 731-0367 - DO NOT FULLY TIGHTEN.
  • Page 42 110-3783 731-9467-XX 731-3221-XX 731-0367 731-0363 8. Use a ratchet wrench with a 16mm socket and 16mm open- ended wrench to secure the right side of the Mid Row body weldment to the weight tower using two (2) bracket mounts (731-3221-XX), four (4) 110-3783 and 731-0363, and eight (8) 731- 0367.
  • Page 43 731-2068 731-0355 731-2072 10. Use a 5mm allen key and a ratchet wrench with a 13mm socket to secure the left and right upper foot plates (731-2072) to the body weldment using four (4) 731-2068 and 731-0365, and eight (8) 731-0355. 731-0365 731-2072 Fig.
  • Page 44 731-0731 731-9476 731-3209 12. Route the cable (731-9476) under the pivot pulley (731-0731) and 731-2016 up towards the upper support weldment. 731-4183 Fig. 75 13. Route the cable over the top 731-3632-XX 731-0731 of the upper support weldment pulley (731-0731) and down through the frame.
  • Page 45 731-9476 731-2527 14. Thread the cable lock nut (731- 731-3169 3169) onto the end of the cable, then use a 10mm open-ended 731-4597 wrench to screw the cable end into the cable mount (731-4597). 15. Use a 16mm open-ended wrench to tighten the cable lock nut to secure the cable into the cable mount.
  • Page 46 REPLACEMENT PARTS Replacement parts for this unit are available through SUPPORT & SERVICE. Parts listed are shown on the following pages and interactive drawings available on Core Connect. Listed parts may change, please check Core Connect for latest versions and other SKU’s covered by this manual: 731-7725-XX - Boom With Pull Up Bars ......
  • Page 47 SCREW,M10x1.5,75mm,HHC,HE,AS,12.9,ZC 731-2580 SCREW, M10X65MM, HSHCS 731-7223-01 STICKER,WARNING,ATTACHMENT,LH 731-2640-XX WELD, FOOT, FREEDOM RACK, RH 731-7223-02 STICKER,WARNING,ATTACHMENT,RH 731-2647 FOOT,LONG,LEVERAGE 731-7311 STICKER,NAUTILUS,DECO,45MMX191MM 731-2850 STICKER,ADJ,1-8,LEV 731-7348 PLACARD,CABLE CROSS, NAU 731-2855 CAP END 60MM TUBE 731-7349 PLACARD,LOW ROW, NAU 731-3126-XX BRACKET, CONNECTOR 731-7350 PLACARD,TRICEPS PRESS, NAU...
  • Page 48 731-7725-XX - Boom With Pull Up Bars CROSS BEAM 731-0363 731-0367 731-1906 731-1785 731-1904-KT 731-0397 731-1905 731-7725-XX 731-3126-XX 731-5516 Fig. 79 731-7725-XX - Boom With Pull Up Bars Page 48...
  • Page 49 UPPER TOWER AND PULLEYS 731-0165 731-0367 110-3817 731-0363 731-0731-KT 731-3161 731-7520 731-5210 731-8119-KT 731-3193 731-1878 Fig. 80 731-7725-XX - Boom With Pull Up Bars Page 49...
  • Page 50 MID TOWER AND HANDLES 731-3193 731-1878 731-3896 731-3883 731-8118 731-8027-KT 731-1194 731-8119-KT 731-7348 731-2028 731-3164-XX 731-3177 731-5183 731-0366 731-3223 731-4439 731-7223-01 731-8117 731-0363 731-7223-02 731-0367 731-2016 731-8075 731-3175 731-0363 731-8048 731-0360 731-0367 731-2855 731-0365 Fig. 81 731-7725-XX - Boom With Pull Up Bars Page 50...
  • Page 51 731-7726-XX - Cable Cross Station LOWER TOWER AND PULLEYS 731-7311 731-0381 731-1932 731-4189 731-3163-XX 731-0365 731-0111 731-1878 731-3193 140-3821 731-7521 731-3170 731-0367 731-0363 110-3802 731-0127 731-2580 731-0355 731-2647 110-3880 731-0517 731-0731-KT 731-0165 731-3157-XX 731-5516 731-0367 731-2446 110-3817 731-2447 Fig. 82 731-7726-XX - Cable Cross Station Page 51...
  • Page 52 WEIGHT STACK 731-0731-KT 110-3817 731-3158 110-3880 731-0127 731-0367 731-0355 731-1448 731-0110 731-0363 731-0512 731-3147 731-1852 731-3143-KT 731-3144 731-3169 731-4584 731-0105 731-0100 731-1423-KT 050-2212 731-7501 731-4436 Fig. 83 731-7726-XX - Cable Cross Station Page 52...
  • Page 53 UPPER WELDMENT 731-0731-KT 731-4585 731-0225 110-3782 731-0363 731-0209 110-3814 731-3178-XX 731-4187 731-0367 731-3209 731-5516 731-2016 731-2440 731-4176 Fig. 84 731-7726-XX - Cable Cross Station Page 53...
  • Page 54 PIVOT PULLEY ASSEMBLY 731-0287 731-0363 731-0034 731-0365 731-1943 731-4428 731-1939 731-4430 731-0130 731-4586 731-0367 731-0127 110-3819 731-0731-KT 731-4420 731-0355 110-3880 Fig. 85 731-7726-XX - Cable Cross Station Page 54...
  • Page 55 731-7724-XXXX - Lat Pull Station THIGH WELDMENT 731-0359 731-0355 27-0277 731-0173-00XX 731-2850 731-0169 731-3653-XX-KT 731-2080 731-2079 Fig. 86 731-7724-XXXX - Lat Pull Station Page 55...
  • Page 56 SEAT WELDMENT AND PLACARD 731-3648-XX 110-3783 731-0367 731-8042-KT 731-0225 731-0638 731-0637 731-0225 731-5330 731-0635-00XX 731-0652 731-3221-XX 731-0562 731-0363 731-9264 731-7351 731-3164-XX 731-0209 731-3652 731-1194 731-2647 731-0379 Fig. 87 731-7724-XXXX - Lat Pull Station Page 56...
  • Page 57 WEIGHT STACK 731-3169 731-4597 731-0110 731-0382 731-4438 731-3642 731-0512 731-4584 731-4437 731-1423-KT 050-2212 731-0100 731-7501 731-0713 Fig. 88 731-7724-XXXX - Lat Pull Station Page 57...
  • Page 58 731-7723-XXXX - Low Row Station UPPER WELDMENT AND PLACARD 731-3632-XX 731-1914 731-0363 731-1194 731-7349 731-0367 731-3164-XX 110-3814 731-0209 110-3817 731-0731 731-4439 731-3646-KT 731-3178 731-0367 731-5516 Fig. 89 731-7723-XXXX - Low Row Station Page 58...
  • Page 59 LOWER PULLEY 731-4428 731-0367 731-1943 731-0130 731-4430 731-1939 110-3817 110-3880 731-0355 731-4433 731-0731 731-0363 731-0165 731-0365 731-0127 Fig. 90 731-7723-XXXX - Low Row Station Page 59...
  • Page 60 UPPER FRAME 731-3646-KT 731-3209 731-2440 731-3636 731-0355 731-0365 731-2016 731-4183 731-0374 110-3783 731-3221-XX 731-0367 731-3637 731-0363 731-2155-KT 731-2356 731-1535-KT 731-1536 Fig. 91 731-7723-XXXX - Low Row Station Page 60...
  • Page 61 LOWER FRAME AND PADS 731-2068 731-0355 731-2073 731-2072 731-1618 731-2074 731-1392-00XX 731-0365 731-1617 731-2580 731-0379 731-1620 731-0367 731-0363 731-2640-XX 731-2647 Fig. 92 731-7723-XXXX - Low Row Station Page 61...
  • Page 62 WEIGHT STACK 731-3169 731-2527 731-4597 731-0110 731-3642 731-0512 731-4438 731-4437 731-4584 731-0100 731-1423-KT 050-2212 731-7501 731-0713 Fig. 93 731-7723-XXXX - Low Row Station Page 62...
  • Page 63 731-7722-XXXX - Triceps Press Station UPPER WELDMENT 731-0731-KT 731-4585 731-0363 731-0367 731-3212 110-3821 731-2016 110-3814 731-3178-XX 731-3209 731-4180 731-5516 Fig. 94 731-7722-XXXX - Triceps Press Station Page 63...
  • Page 64 PIVOT PULLEY ASSEMBLY 731-0287 731-0034 731-1943 731-1939 731-0130 731-4430 731-0225 731-4428 731-0355 731-0365 731-0209 110-3880 731-0367 110-3819 731-0363 731-0127 731-0731-KT 731-4586 Fig. 95 731-7722-XXXX - Triceps Press Station Page 64...
  • Page 65 BACK WELDMENT AND PAD 731-0379 731-7350 731-3221-XX 731-3203-XX 731-0363 731-3164-XX 731-4439 731-0367 731-1194 110-3783 731-2153 731-0209 731-0635-00XX Fig. 96 731-7722-XXXX - Triceps Press Station Page 65...
  • Page 66 WEIGHT STACK 731-3169 731-3212 731-5058 731-0382 731-4597 731-0110 731-0512 731-4438 731-4435 731-3205-KT 731-4584 050-2212 731-0100 731-1423-KT 731-7501 Fig. 97 731-7722-XXXX - Triceps Press Station Page 66...
  • Page 67 731-7721-XX - Hi-Low Station UPPER PULLEYS 731-3187 731-3188-XX 731-0731 731-3161 731-7520 731-0165 731-0367 110-3883 731-8119 731-1878 731-0363 110-3814 731-3178 731-0367 731-5516 Fig. 98 731-7721-XX - Hi-Low Station Page 67...
  • Page 68 ADD-ONS 731-8118 731-3896 731-7348 731-3883 731-3164-XX 731-4439 731-1194 731-3174 731-0363 731-2855 731-3194 731-0367 731-3199 731-3223 Fig. 99 731-7721-XX - Hi-Low Station Page 68...
  • Page 69 HANDLE AND PULLEY 731-0365 731-1878 731-8027-KT 731-2028 731-0360 731-5183 731-0366 731-7223-01 731-8075 731-7223-02 731-0367 731-0365 731-0363 731-8117 731-2016 731-2440 731-8048 Fig. 100 731-7721-XX - Hi-Low Station Page 69...
  • Page 70 WEIGHT STACK 731-0731 110-3883 731-3158 731-0367 731-1448 110-3880 731-3147 731-0355 731-0363 731-0512 731-0127 731-1852 731-3143 731-0110 731-3144 731-0100 731-3169 731-4584 731-4436 731-0105 731-1423-KT 050-2212 731-7501 Fig. 101 731-7721-XX - Hi-Low Station Page 70...
  • Page 71 LOWER PULLEYS 110-3802 731-1878 731-0367 731-7521 731-0165 731-8119 731-0367 731-0363 110-3883 731-0365 731-2446 731-0127 731-3157-XX 731-0731 731-2447 731-0128 110-3880 Fig. 102 731-7721-XX - Hi-Low Station Page 71...
  • Page 72 731-7720-XX - Multistation Tower TOWER TOP 731-3185 731-3186 731-5210 731-3193 731-7311 731-0801 Fig. 103 731-7720-XX - Multistation Tower Page 72...
  • Page 73 TOWER BOTTOM 731-0801 731-3193 731-0111 140-3821 731-0517 731-2580 731-0367 731-2640-XX 731-0363 731-2647 731-3187 731-5439 Fig. 104 731-7720-XX - Multistation Tower Page 73...
  • Page 74 TOWER BOTTOM 731-9564-KT Fig. 105 731-7720-XX - Multistation Tower Page 74...
  • Page 75 731-9475-XXXX - Mid Row Station CABLE AND HANDLE 731-9476 731-2440 731-3209 731-2016 731-4183 Fig. 106 731-9475-XXXX - Mid Row Station Page 75...
  • Page 76 FOOT PLATES AND PADS 731-3637 731-2068 731-0355 731-0365 731-2356 731-3636 731-2072 731-2073 731-2074 Fig. 107 731-9475-XXXX - Mid Row Station Page 76...
  • Page 77 FRAME AND PLACARD 731-1194 731-9480 731-3164-XX 731-0363 731-4439 731-0367 731-3221-XX 110-3783 731-2647 Fig. 108 731-9475-XXXX - Mid Row Station Page 77...
  • Page 78 PIVOT PULLEY 731-4428 731-0367 731-1943 731-0130 731-1939 110-3817 731-0367 731-0165 110-3922 731-0355 731-0731-KT 731-4433-XX-KT 731-8832 731-0365 731-4430 731-0363 Fig. 109 731-9475-XXXX - Mid Row Station Page 78...
  • Page 79 SEAT WELDMENT 731-1535-KT 731-0374 731-1536-KT 731-1392-00XX 731-1617 731-9470-XX 300-0155 731-2155-KT 731-1618 730-1123 110-3783 731-1620 731-3221-XX 731-2640-XX 731-0367 731-0379 731-0363 731-2647 Fig. 110 731-9475-XXXX - Mid Row Station Page 79...
  • Page 80 UPPER WELDMENT 731-3632-XX 731-0209 731-3186 110-3814 731-1914 731-0363 731-0128 731-0367 110-3817 731-3178-XX 731-0367 731-5516 Fig. 111 731-9475-XXXX - Mid Row Station Page 80...
  • Page 81 WEIGHT STACK 731-3169 731-0512 731-4597 731-4438 731-0382 731-4437 731-0110 731-0100 731-3642 731-0713 731-4584 731-1423-KT 050-2212 731-7501 Fig. 112 731-9475-XXXX - Mid Row Station Page 81...
  • Page 82 MAINTENANCE TOOLS Working on this product will require basic and/or sometimes specialty tools based on the type of service that will be performed at any time. To assist, we recommend having the tools listed available when performing maintenance. Tool Metric Allen Key Set Screwdriver Set, Phillips Metric Open-Ended Wrench Set Screwdriver Set, Flat...
  • Page 83 Inspection Visual inspection of your units will insure a safe environment for your clients and alert you to any issues that may require maintenance prior to equipment failure. Proper, timely visual inspection is a critical component to the long term care of your product. •...
  • Page 84 MAINTENANCE SCHEDULE With durable, high performance components, this equipment is designed for heavy usage with minimal maintenance required. To keep it in top condition, perform regular daily, weekly and monthly preventive maintenance routines outlined below. The safety and integrity of this machine can only be maintained when the equipment is regularly examined for damage and wear and repaired.
  • Page 85 WARNING: Replace all worn cables immediately. The following conditions indicate some types of wear. Fig. 113 Torn or Cracked Cable Sheath that exposes cable Fig. 114 Stretched Cable Sheath Fig. 115 Kink in the Cable Lubrication Proper cleaning lubrication of guide rods will insure that each machine operates at its highest potential and that your clients continue to enjoy a smooth efficient motion while exercising.
  • Page 86 SUPPORT & SERVICE CORE CONNECT Core Connect is your portal to all things service! Whether you need to order parts or register your warranty, Core Connect is the most effective way to get what you need fast and keep your facility operating smoothly. OFFERS 24-HOUR SELF SERVICE ACCESS TO: •...
  • Page 87 PART NUMBER 637-8936, REV C All rights reserved. Star Trac, the Star Trac logo and StairMaster are registered trademarks of Core Health & Fitness, LLC. Schwinn and Nautilus are registered trademarks of Nautilus Inc. used under license to Core Health & Fitness LLC. Throwdown is a registered trademark of Throwdown Industries, LLC.
