- Page 1 TROPIC JUNIOR WITH CARTRIDGE FILTER INSTALLATION INSRUCTIONS (please read carefully and keep for future reference) Page 1 1/24 2017/04 - Indice de révision : A - Code : 37411...
-
Page 2: Table Of Contents
1. PRODUCT OVERVIEW ......................3 2. TROPIC JUNIOR TECHNICAL DATA ...................3 3. IMPORTANT: SAFETY......................3 4. PREPARATION ........................4 TROPIC JUNIOR packaging and storage................4 4.1.1 Package no. 1 (box) .....................4 4.1.2 Package No. 2 (pallet) ....................4 Tropic junior - list of parts......................5 4.2.1 Package no. -
Page 3: Product Overview
PRODUCT OVERVIEW TROPIC JUNIOR is designed for private use only, and more specifically, for young children to swim and splash around. The pool is comprised of a wooden structure, with wooden edging, waterproofed by a plasticised PVC liner, 0.5mm thick. It is also equipped with a space saving filtration system that sits into a corner of the pool. TROPIC JUNIOR pools are not designed to be dismantled at the end of the pool season. -
Page 4: Preparation
If you want to add an additional means of access to your TROPIC JUNIOR pool (steps, ladder), choose one that can be «locked»(to prevent access while the pools is not use), failing this move the means of access away from the pool Only use the original filtration system, never try to adapt any other filtration system to your TROPIC JUNIOR pool. -
Page 5: Tropic Junior - List Of Parts
Before beginning assembly, check that all the TROPIC JUNIOR pool components are present. Once assembly has begun, it should be completed as quickly as possible to avoid any deformation of the parts. TROPIC JUNIOR - list of parts 4.2.1 Package no. 1 (box) TORX head cuntersunk Round head roofing nail Qty:... - Page 6 Qty: Qty: Filter hood SKimmer lid Qty: Qty: Skimmer guide Skimmer grate Qty: Qty: Suction cup Polystyrene wedge 4.2.2 Package no. 2 (pallet) Qty: Wall slat 2203x 68x28 mm, female Qty: Wall slat 2203x 77x28 mm, male Qty: Wall slat 2203x137x28 mm female Qty: Wall slat 2203x 145x28 mm, male/female Qty:...
- Page 7 Qty: Corner cleat, class III pine, 620mm, Junior Qty: Pine finishing trim 625x17x44 mm Qty: Vertical reinforcement, pine, 625x86x28 mm Qty: PVC Hung, 1988 mm 7/24 2017/04 - Indice de révision : A - Code : 37411...
-
Page 8: Information Prior To Assembly
Information prior to assembly Number of people required for assembly: 2 people Estimated time required for assembly: 4 hours Tools required to build the structure and accessories : Wooden or rubber mallet Wood drill bit 4 mm Crosshead bit Torx bit POZI Z2 T-20 - T-25 - T-30 Tools required to prepare the ground if the pool will be installed on natural ground:... -
Page 9: Selection Of The Installation Site
Selection of the installation site The installation site should be selected with regard to the following: • TROPIC JUNIOR should be visible from the living areas in the home; • If TROPIC JUNIOR is installed on natural ground, make sure that the site is not infested by termites or other wood eating insects;... -
Page 10: Montage
MONTAGE Building the wooden structure ×2 ×2 ×4 ×12 Make sure that the four corners are square. Use the 12 countersunk screws, 5x60 (101), to assemble the base. ×4 ×16 Screw a metallic reinforcing plate onto each of the four corners. 10/24 2017/04 - Indice de révision : A - Code : 37411... - Page 11 ×8 ×16 Position the vertical braces (208) opposite the holes drilled in the slats (201 and 203). Make sure that the bottom planks (204) and vertical braces (208) are square, then screw them in place. The braces have a specific orientation: Interior of the Exterior of the pool...
- Page 12 ×8 ×2 ×2 ×40 Make sure that the vertical braces (208) and bottom planks (204) are square. Braces must be perfectly vertical. Check that all the slats are correctly interlocked along their entire length and that they are perfectly horizontal. After carefully carrying out these checks, working fro the inside of the pool, screw the slats onto the braces.
- Page 13 ×4 ×1 Using a brush, paint the ends of the planks in each of the four corners with wood stabiliser to prevent cracking and deformation over time. This product appears white when applied but turns colourless when dry. It takes 2 to 3 hours to dry. Apply a second coat if temperatures are high or if the product dries too quickly.
-
Page 14: Fitting The Liner And The Underlay
×4 ×20 Place the PVC liner locking track (209) against the top slat of each of the four walls as shown opposite, and fasten in position using 5 screws (103). The locking tracks are used to fit TROPIC JUNIOR’s waterproofing membrane. Fitting the liner and the underlay ×1 ×4... -
Page 15: Assembling The Filter
IMPORTANT: • Do not slide the liner along the locking track to reposition it, this could tear the liner. Pull it out on the track and reinsert it in the correct position. • Flatten the liner against the floor of the pool and push it into the horizontal and vertical corners to smooth out creases as much as possible. - Page 16 ×1 Fix the filtration cartridge (303) in place inside the filter body by twisting one quarter turn. Fasten the filter Insert the suction cups into the ×1 support guide (304) 2 openings on the bottom of the ×2 to the filter base support guide.
-
Page 17: Installing The Pine Coping
Lower the filter into the water, lean it over slightly to evacuate any air trapped in the filter body, then position it in one corner of the TROPIC JUNIOR pool, clipping it onto each side of a corner block (213). Push the suction pads against the liner to hold the filter in place. -
Page 18: Filtration And Water Treatment
FILTRATION AND WATER TREATMENT Once your pool has been filled with water, the water will tend to become dirty and the water quality will deteriorate because of pollution introduced by bathers (bodily secretions, but also twigs, grass, earth, sand, etc. stuck to their feet or their skin), as well as contaminants deposited by the wind (leaves, petals, pollen), and insects. -
Page 19: Replacing The Pump Motor
Replacing the pump motor • Disconnect the power supply to the filter. • Unhook the filter, taking care not to damage the liner. To do this, insert a screw driver into the recesses in the filter support guide (304) on either side of the corner. Lift the liner Hung track (209) very slightly and pull on the filter support guide to unclip it. -
Page 20: Guarantees
TROPIC JUNIOR pools may be covered with a winter cover. Add an algaecide to the pool to limit the growth of algae. At the beginning of the next pool season, empty the water out of the pool and clean the liner thoroughly before refilling the pool. If the pool is installed in a region that experiences freezing conditions over winter, steps must be taken to prevent ice from exerting pressure on the wooden structure: •... -
Page 21: Filtration Group: 1 Year
Filtration group: 1 year The cartridge is considered a «wear part» and is not covered in the scope of this guarantee. The motor is guaranteed, subject to the conditions that the pump was not allowed to run dry, and that the filter cartridge was cleaned in accordance with instructions. - Page 22 SUSTAINABLE FORESTRY Storage. If you do not intend to assemble your pool Procopi is committed to using wood from sustainable managed immediately, you should store it without opening it in a forests. As a guarantee, we have had our products certified by a...
- Page 23 For the wood. For further information, please refer to Procopi’s guarantees same reason, imperfections on the interior surface of the pool (knots, concerning the types of wood and their treatment.
- Page 24 QUALITY CERTIFICATE CHAIN OF CUSTODY Company PROCOPI 35650 LE RHEU FRANCE Chain of Custody no. FCBA/12-01382 The chain of custody of the company designated hereinover complies with the PEFC* stipulations in effect. This certificate was issued in accordance with the PEFC...
