Procopi Proswell Tropic OCTO Installation Instructions Manual

Hide thumbs

Table Of Contents

Quick Links

To be read carefully and kept for future reference

The english version of these installation instructions is available for download from procopi.com.

Please Note, you must use your Procopi ID and password to log-in in order to view our technical documentation.

PROCOPI

Les Landes d'Apigné

B.P.45328

35650 LE RHEU Cedex

FRANCE

OCTO / OCTO + / HEXA

Installation instructions

Notice Tropic Octo, Octo+, Hexa - 02/2016

GB - Indice de révision : I - Code : 97112223

Table of Contents

Need help?

Do you have a question about the Proswell Tropic OCTO and is the answer not in the manual?

Questions and answers

Summary of Contents for Procopi Proswell Tropic OCTO

Page 1 To be read carefully and kept for future reference The english version of these installation instructions is available for download from procopi.com. Please Note, you must use your Procopi ID and password to log-in in order to view our technical documentation. PROCOPI Les Landes d’Apigné...
Page 2 For the same reason, imperfections properties of the wood. For further information, please on the interior surface of the pool (knots, cracks, flashes) refer to Procopi’s guarantees concerning the types of are entirely acceptable. wood and their treatment.
Page 3: Table Of Contents
» » NOTICE DE MONTAGE / OCTO / OCTO + / HEXA NOTICE DE MONTAGE / OCTO / OCTO + / HEXA TABLE OF CONTENTS > > Foreword ................p-4 Storage & time required for assembly .........p-4 Siting and preparation of the ground for Octo, Octo + and Hexa pools ........p.5-6 Assembly of the OCTO &...
Page 4: Foreword
» INSTALLATION INSTRUCTIONS / OCTO / OCTO + / HEXA FOREWORD > > Congratulations on acquiring your pool. We have taken great care with the design and manufacture of your pool to provide you with a top quality product. The wood used to make the various elements (interlocking walls, coping, ladder, etc.) was carefully selected. Outdoors, these wooden elements are subject to constant weathering: contact with the ground, temperature variations, exposure to sunlight, rain and frost, insect attack, etc.
Page 5 » INSTALLATION INSTRUCTIONS / OCTO / OCTO + / HEXA SITING & PREPARATION OF THE GROUND FOR OCTO, > > OCTO + AND HEXA POOLS This is the most important step in the procedure as the pool site will determine the service life of your pool. There are some rules that must be respected.
Page 6 » INSTALLATION INSTRUCTIONS / OCTO / OCTO + / HEXA OCTO + POOLS > > (RELEVENT TO ABOVE-GROUND INSTALLATIONS ONLY. RECOMMENDATIONS AND INFORMATION CONCERNING PARTIALLY IN-GROUND OR FULLY IN-GROUND INSTALLATIONS ARE PROVIDED AT THE END OF THIS DOCUMENT).*** Trace out site of the pool and clear the ground of plants, grass and other miscellaneous objects. Next, level and smooth the surface using a spade, rake and a pickaxe (if necessary).
Page 7: Assembly Of The Octo & Hexa Pool Structure
» INSTALLATION INSTRUCTIONS / OCTO / OCTO + / HEXA ASSEMBLY OF THE OCTO & HEXA POOL STRUCTURE > > - Before you begin, familiarise yourself with the nomenclature enclosed in the “Waterproofing” kit and the Model exploded view (at the end of this notice) that corresponds to your pool.
Page 8 » INSTALLATION INSTRUCTIONS / OCTO / OCTO + / HEXA Mount a decorative profile (type H) on the end of each wall using nails (3.1x75mm) inserted through evenly spaced holes pre-drilled along the axis of the profile. 75 cm 75 cm There is 1 wooden bracket per side (except the side Mount 2 wooden brackets on the wall holding the holding the skimmer).
Page 9 » INSTALLATION INSTRUCTIONS / OCTO / OCTO + / HEXA Ø5 x 80mm At this point, fit the skimmer into the bottom skimmer slat The wooden brackets will support the coping that will (type D) before fitting the type E slat. be mounted after the pool is filled.
Page 10 » INSTALLATION INSTRUCTIONS / OCTO / OCTO + / HEXA Each side of the pool is fitted with one track 1.18 m long and another track trimmed to fit, see the table below. Trim 8 tracks according to the table below. Before making the cuts, check that the total length of the track is equal to the length of the wall less 10 cm.
Page 11: Assembly Of The Octo + Pool Structure
» INSTALLATION INSTRUCTIONS / OCTO / OCTO + / HEXA ASSEMBLY OF THE OCTO + POOL STRUCTURE > > The pool structure is mounted in two stages: - Stage 1, excavation of the site and installation of the cradles designed to reinforce the lateral walls. A cradle comprises a cross beam, vertical posts and metallic plates to be bolted together.
Page 12 » INSTALLATION INSTRUCTIONS / OCTO / OCTO + / HEXA ASSEMBLY OF THE OCTO + POOL STRUCTURE (contd.) > > Recommendations and advice: - Before beginning assembly, identify the various slat types with reference to the exploded view at the end of this document.
Page 13 » INSTALLATION INSTRUCTIONS / OCTO / OCTO + / HEXA ASSEMBLY OF THE OCTO + POOL STRUCTURE (contd.) > > At this point, fit the skimmer into the machined slat (F). Slot the top skimmer slat (G) over slat F and continue around the pool, fitting 2 type H slats, 1 type l slat and 4 type J half-slats into position as shown.
Page 14 » INSTALLATION INSTRUCTIONS / OCTO / OCTO + / HEXA Mount a decorative profile (type H) on the end of each wall using nails (3.1x75mm) inserted through evenly spaced holes pre-drilled along the axis of the profile. ASSEMBLY OF THE OCTO + POOL STRUCTURE (contd.) >...
Page 15 » INSTALLATION INSTRUCTIONS / OCTO / OCTO + / HEXA MOUNTING THE LINER LOCKING TRACK & FITTING THE UNDERLAY > > IMPORTANT ! Check that the structure is correctly assembled before mounting the liner locking track. To do this: - use a spirit level to check that the structure is horizontal around the entire periphery.
Page 16 » INSTALLATION INSTRUCTIONS / OCTO / OCTO + / HEXA POOL FITTING GASKETS > > From the pool side, insert return fitting throughwall flange Before fitting the liner, glue one of the 2 rectangular (pool fitting pack) into the opening in the machined slats. self-adhesive gaskets (pool fitting skin pack) around the Fix it in position using countersunk self-tapping 3x25 screws.
Page 17 » INSTALLATION INSTRUCTIONS / OCTO / OCTO + / HEXA FITTING THE LINER (contd.) > > Once the liner has been hung and is correctly positioned, fill the pool with 2 cm of water. Push any creases towards the walls smoothing out the liner as much as possible. Take care to ensure that the floor is as smooth as possible.
Page 18 » INSTALLATION INSTRUCTIONS / OCTO / OCTO + / HEXA Glue the second skimmer gasket to the interior surface of the skimmer flange. (The interior surface has sharp edges while the exterior surface has rounded edge). Locate the 4 corner holes of the skimmer mouth and mark them with a pen. Position the flange such that its corner holes are aligned with the points marked in pen.
Page 19 » INSTALLATION INSTRUCTIONS / OCTO / OCTO + / HEXA ASSEMBLING AND COMMISSIONING THE FILTER GROUP > > Before you continue to fill the pool, assemble the filtration group. Refer to the sand filter installation instructions below and the pump operating instructions. Study the filtration system diagram and the table below that lists the main components and the composition of the various packs.
Page 20 » » INSTALLATION INSTRUCTIONS / OCTO / OCTO + / HEXA NOTICE DE MONTAGE / OCTO / OCTO + / HEXA proswell.fr...
Page 21 » NOTICE DE MONTAGE / OCTO / OCTO + / HEXA FILTER ASSEMBLY > > Check that the drain plug and its o-ring are in position. Place the collector plate in the base of the filter tank. Check that it is level. Hand tighten only Put the protective cap on the top of the collector tube Engage the diffuser in filter lid and rotate it anti-clock-...
Page 22 » INSTALLATION INSTRUCTIONS / OCTO / OCTO + / HEXA FILTER ASSEMBLY (CONT.) > > Screw the holding ring into position to keep the lid in Check that the upper, inner part of the tank is clean. position. Remove the protective cap from the collector tube. To facilitate fitting of the lid, grease the interior of the Hand tighten by a quarter turn.
Page 23 » INSTALLATION INSTRUCTIONS / OCTO / OCTO + / HEXA PUMP FILTER & MANIFOLD MODULE > > Pump Return Waste Skimmer Assemble the pump on its base and join this assembly to the filter base. Orient the assembly to facilitate subsequent connection of the semi-rigid pipes leading to the pool.
Page 24 » INSTALLATION INSTRUCTIONS / OCTO / OCTO + / HEXA PLUMBING > > suction return Connect the rigid descending pipes to the filtration group as shown above. The roll of tubing provided in the Filtration kit is sized for a standard installation, that is to say, with the filter group located 3.5 m from the pool (minimum distance between the pump and the pool according to the French electrical safety standard C15-100 if the filtration group is not installed in a locked plant room).
Page 25: Assembly Of The Filter
» INSTALLATION INSTRUCTIONS / OCTO / OCTO + / HEXA COMMISSIONING & OPERATING THE FILTER SYSTEM > > COMMISSIONING AND OPERATING RECOMMENDATIONS WARNING: Carry out a back wash and rinse before using the filter for the first time to clean the filter and remove any excess sand and debris (see the paragraph Filter and Valve operation).
Page 26 » INSTALLATION INSTRUCTIONS / OCTO / OCTO + / HEXA COMMISSIONING & OPERATING THE FILTER SYSTEM > > LENGTH OF THE FILTRATION CYCLE: The length of the filtration cycle depends on the theoretical time taken for all the water in the pool to pass through the filter.
Page 27 » INSTALLATION INSTRUCTIONS / OCTO / OCTO + / HEXA FITTING THE COPING > > Note the distribution of the various modules constituting the coping on the drawing. Arrange them on the coping support brackets. Make sure that the elements are correctly and evenly positioned around the entire periphery of the pool.
Page 28 » INSTALLATION INSTRUCTIONS / OCTO / OCTO + / HEXA Study the illustration above. Mount the brackets (identi- cal to the connecting brackets) as shown using screws (bag M). Next, fasten the latches into position (use the items from bag N) to ensure effective locking. ASSEMBLING AND INSTALLING THE STAINLESS STEEL LADDER >...
Page 29 » INSTALLATION INSTRUCTIONS / OCTO / OCTO + / HEXA ASSEMBLING AND POSITIONING THE WOODEN LADDER (contd) > > The wooden ladder is fitted with two lever latches that lock it into position. The lever sections are fitted to the ladder supports and the hooks are mounted under the coping (these parts are enclosed in bag K).
Page 30 » INSTALLATION INSTRUCTIONS / OCTO / OCTO + / HEXA MAINTENANCE AND USE > > Wood is a living material that responds to changes in temperature and humidity; cracks and splits may appear; this is natural and in no way impacts the service life of our products. The wooden components of this pool are subjected to a Class IV autoclave treatment that complies with standards in effect, they present no danger to people or animals that may come into direct contact with the wood.
Page 31 » INSTALLATION INSTRUCTIONS / OCTO / OCTO + / HEXA MAINTENANCE & USE (contd) > > ACCESSORIES Electrical equipment such as underwater lights that require an electrical supply must be fitted and wired in according to the standards in effect. We recommend that you take great care in this matter and that you call on the services of qualified specialists.
Page 32: Safety
» INSTALLATION INSTRUCTIONS / OCTO / OCTO + / HEXA SAFETY > > DO NOT PLAY WITH SAFETY ! ! ! In this fun environment you need to watch your children! You alone are responsible for their safety ! Children should be closely supervised at all times.
Page 33: Guarantees
- Folds that remain despite following all the instructions regarding fitting of the liner should be reported immediately to your Procopi agent. The appearance of yellow stains or discolouration along the water line.
Page 34 » INSTALLATION INSTRUCTIONS / OCTO / OCTO + / HEXA GUARANTEE (contd) > > ARTICLE Subject and scope of the Term of the guarantee as of Conditions governing acceptance of a claim guarantee the date of purchase POOL Leaktightness and durability 10 years FITTINGS of the pool fittings...
Page 35 » INSTALLATION INSTRUCTIONS / OCTO / OCTO + / HEXA EXPLODED VIEW OF THE OCTO POOL WOODEN STRUCTURE > > SEMI-FEMALE MALE/ FEMALE FEMALE MALE PROFILE PROFILE PROFILE PROFILE proswell.fr...
Page 36 » INSTALLATION INSTRUCTIONS / OCTO / OCTO + / HEXA EXPLODED VIEW OF THE OCTO+ POOL WOODEN STRUCTURE > > PROFIL DEMI -FEMELLE proswell.fr...
Page 37 » INSTALLATION INSTRUCTIONS / OCTO / OCTO + / HEXA EXPLODED VIEW OF THE HEXA 410 > > PVC liner locking track SEMI-FEMALE MALE/ FEMALE FEMALE MALE PROFILE PROFILE PROFILE PROFILE proswell.fr...
Page 38 » INSTALLATION INSTRUCTIONS / OCTO / OCTO + / HEXA NOTES > > proswell.fr...
Page 39 » INSTALLATION INSTRUCTIONS / OCTO / OCTO + / HEXA NOTES > > proswell.fr...
Page 40: Installation Instructions
» INSTALLATION INSTRUCTIONS / OCTO / OCTO + / HEXA QUALITY CERTIFICATE CHAIN OF CUSTODY Company PROCOPI 35650 LE RHEU FRANCE Chain of Custody no. FCBA/12-01382 The chain of custody of the company designated hereinover complies with the PEFC* stipulations in effect.

This manual is also suitable for:

Proswell tropic octo+Proswell tropic hexa
