Display elements
Colored light emitting diodes (LEDs) at the device indicate the operational state.
Operational state
State
off
Lights up green
Flashes green
Lights up
orange
Flashes orange
Lights up red
Flashes red
All LEDs light up
red
All LEDs flash
orange
All LEDs are off
Ethernet status
State
Off
Lights up
Flashes
5.3
Control elements
The device is operated via the S11 key.
Action
Press key for a long time
Press key for a short time
Press key for a long time when the DC
power supply or the USB is plugged in
Manual
L1 (Application)
L2 (Battery)
-
Battery is not be-
ing charged or is
full
Waiting for trigger
Battery is being
signal
charged
Data is being re-
-
corded
Device is ready
-
(access via USB
is possible)
-
-
-
Battery is almost
empty
Error status
-
Boot process
Update is being loaded
Not in operation, no power supply
Green (speed)
10 Mbit/s
100 Mbit/s
-
Issue 1.11
L3 (DC input)
Not plugged
Plugged
-
-
-
-
-
Yellow (connection/data traffic)
No connection
Link OK
Data traffic
Description
Switching on or switching off the device
Starting or stopping the measurement recording
Reboots the device
L4 (USB)
Not plugged
Plugged
-
-
-
-
-
