ibaPADU-C-8AI
Connection technology signal
inputs
Operational and ambient conditions
Operational temperature range
Storage temperature range
Transport temperature range
Humidity class acc. to DIN 40040 F, no condensation
Protection class acc. to DIN EN
60529
Permits/standards
Dimensions and weight
Dimensions (Width x Height x
Depth)
Weight
(incl. packaging and manual)
Manual
36-pin multi-pin connector, plug with clamping
technique, enclosed
Cable inflexible/flexible (0.2 mm to 1.5 mm)
Flexible with cable end sleeve without plastic
sleeve (0.25 mm to 1.5 mm)
Flexible with cable end sleeve with plastic sleeve
(0.25 mm to 0.75 mm)
32 °F to 122 °F (0 °C to +50 °C)
-4 °F to 140 °F (-20 °C to +60 °C)
-4 °F to 140 °F (-20 °C to +60 °C)
IP20
CE, EMC (DIN IEC 61326-1: 2006-10)
FCC part 15 class A
1.61 in x 7.40 in x 5.28 in
(41 mm x 188 mm x 134 mm)
Approx. 2.43 lbs (1.1 kg)
