Hill-Rom FreeStand Instruction Manual

FreeStand is a freestanding lift system that is intended
for use where there is need for lifting in a specific loca-
tion, e.g., near a bed or in a hygiene room, etc.
Freestanding systems are a good alternative if you
need the features of a fixed-installation overhead lift
system but do not wish to install permanent fixtures
in the walls or ceiling, or if the need for lifting is only
temporary.
With its simple and safe structural design, the Free-
Stand lift system is ideal for home-care and other care
settings.
Since FreeStand requires no wall or ceiling fixtures,
it enables great flexibility of placement in the room.
In this document, the person being transferred is referred to as the patient and the person helping them is
referred to as the caregiver.
Caution triangles are used to warn of situations that demand extra care and attention.
IMPORTANT!
Read the instructions for both the patient lift and the lifting accessories before use.
Lifting and transferring a patient always involves a degree of risk. A complete understanding of the contents of
instructions is essential, and only trained personnel should use the equipment.
When in doubt, contact Liko.
Product Description
The width of the FreeStand rail system depends on
the choice of lift rail length. The lift rail (H100) is avai-
lable in 7 different lengths: from 2.0 m (79 inch.) up
to 3.2 m (126 inch.).
For a complete lift system, FreeStand is combined
with lift rail H100, a lift unit, parking set and other
accessories.
With the FreeStand lift system, Liko's stationary lifts
Multirall or Likorall are used.
FreeStand complies with EN ISO 10535 according to
the requirements of directives for medical- technical
products, MDD 93/42/EEC.
FreeStand
Instruction Guide
English
7EN131101 Rev.3
2015-11-02
