Summary of Contents for Rice Lake BenchMark MS
- Page 1 BenchMark MS, SS, HE ® Medium-to High-Capacity Bench Scales Technical Manual June 5, 2020 PN 200154 Rev A...
- Page 2 All information contained within this publication is, to the best of our knowledge, complete and accurate at the time of publication. Rice Lake Weighing Systems reserves the right to make changes to the technology, features, specifications and design of the equipment without notice.
-
Page 3: Table Of Contents
BenchMark MS, BenchMark SS and BenchMark HE........ - Page 4 BenchMark MS, SS, HE Series Rice Lake continually offers web-based video training on a growing selection of product-related topics at no cost. Visit www.ricelake.com/webinars www.RiceLake.com Visit our website...
-
Page 5: Introduction
Introduction Introduction This manual provides an overview of technical information for the BenchMark MS, SS and HE medium-to high-capacity bench scales. Manuals and additional resources are available from the Rice Lake Weighing Systems website at www.ricelake.com Warranty information can be found on the website at www.ricelake.com/warranties... -
Page 6: Overview
Overview The BenchMark MS is constructed with a mild steel frame with stainless steel top cover. The BenchMark SS and HE are constructed with a stainless steel frame and top cover. The BenchMark MS and SS contain IP66 aluminum single point load cells. -
Page 7: Installation
Immediately after unpacking, visually inspect the scale to ensure that the unit is undamaged. The shipping carton should contain the bench scale and this manual. If the bench scale was damaged in shipment, notify Rice Lake Weighing Systems and the shipper immediately. -
Page 8: Benchmark Ss
BenchMark MS, SS, HE Series 2.3.2 BenchMark SS Color Code Function Color Code Function Green + Excitation Green + Excitation Black - Excitation Black - Excitation + Signal + Signal White - Signal White - Signal Blue + Sense Blue... -
Page 9: Replacement Parts
Installation Replacement Parts See the following information for replacement parts details: 2.6.1 BenchMark MS 12'' x 12'' and 12'' x 18'' Models Top View of 12" Scale Series with cover removed to show location of rubber pads Section AA (Enlarged) Figure 2-1. -
Page 10: Benchmark 12'' X 18'' Models, Ss And He
BenchMark MS, SS, HE Series 2.6.2 BenchMark 12'' x 18'' Models, SS and HE Figure 2-2. 12'' x 18'' Stainless Steel Parts Illustration BenchMark SS 12'' x 18'' Item No. Part No. Description Qty. Item No. Part No. Description Qty. -
Page 11: Benchmark Ms, Ss And He, 18'' X 18'' Models
Installation 2.6.3 BenchMark MS, SS and HE, 18'' x 18'' Models Item 19 is for BenchMark HE 24'' x 24'' (Table 2-21 on page 11) only Figure 2-3. 18'' x 18'', 18'' x 24'' and 24'' x 24'' Models Parts Illustration BenchMark MS 18'' x 18'' Item No. - Page 12 BenchMark MS, SS, HE Series BenchMark SS 18'' x 18'' Item No. Part No. Description Qty. Item No. Part No. Description Qty. 15409 Clamp, Cable, No. 8 Hole 19141 Foot, 3/8-16 x 78 15418 Rubber Grommet, 3/16 x 1/2 od...
-
Page 13: Benchmark Ms, Ss And He, 18'' X 24'' Models
Installation 2.6.4 BenchMark MS, SS and HE, 18'' x 24'' Models BenchMark MS 18'' x 24'' Item No. Part No. Description Qty. Item No. Part No. Description Qty. 15418 Rubber Grommet, 3/16 x 1/2 od 19141 Foot, 3/8-16 x 78... -
Page 14: Benchmark Ms, Ss And He, 24'' X 24'' Models
Nut, Lock, 1/4-20 NC, Hex, SST 15409 Clamp, Cable, No. 8 Hole Table 2-18. BenchMark HE 18'' x 24'' Parts List 2.6.5 BenchMark MS, SS and HE, 24'' x 24'' Models BenchMark MS 24'' x 24'' Item No. Part No. Description Qty. - Page 15 Washer, Plain STD No. 8 SST 15409 Clamp, Cable, No. 8 Hole 15149 Washer, Plain, STD 1/4 SST 14635 Nut, Lock, 1/4-20 NC, Hex, MS Table 2-21. BenchMark HE 24'' x 24'' Parts List © Rice Lake Weighing Systems ● All Rights Reserved...
-
Page 16: Appendix
BenchMark MS, SS, HE Series Appendix This section provides additional information about the BenchMark MS, SS and HE medium-to high-capacity bench scales.. Options Optional ball transfer, roller conveyor tops and custom height columns for attaching indicators to the scale are available. -
Page 17: Dimensions
Appendix Dimensions For BenchMark MS, SS and HE bench scale dimensions see the following information: Figure 3-1. BenchMark Dimensions 3.3.1 BenchMark MS, BenchMark SS and BenchMark HE Figure 3-1 Table 3-2 dimension references. For load cell approvals, see Section 4.0 on page... -
Page 18: Load Cell Replacement
BenchMark MS, SS, HE Series Load Cell Replacement See the following procedure to replace load cells: 1. Unplug AC power from indicator and disconnect load cell cable from indicator. 2. Lift off the top cover. 3. Remove two load cell screws. -
Page 19: Limited Warranty
Appendix Limited Warranty Rice Lake Weighing Systems (RLWS) warrants that all RLWS equipment and systems properly installed by a Distributor or Original Equipment Manufacturer (OEM) will operate per written specifications as confirmed by the Distributor/OEM and accepted by RLWS. All systems and components are warranted against defects in materials and workmanship for two years for the BenchMark MS and BenchMark SS and three years for the BenchMark HE. -
Page 20: Specifications
BenchMark MS, SS, HE Series Specifications Certifications and Approvals Load Cell BenchMark MS IP66 aluminum, environmentally sealed NTEP BenchMark SS IP66 aluminum, environmentally sealed CoC 95-072 BenchMark HE IP69K stainless steel, hermetically sealed Accuracy Class III; 5000 d Available Sizes... - Page 22 Specifications subject to change without notice. Rice Lake Weighing Systems is an ISO 9001 registered company. 230 W. Coleman St. • Rice Lake, WI 54868 • USA U.S. 800-472-6703 • Canada/Mexico 800-321-6703 • International 715-234-9171 • Europe +31 (0)26 472 1319 June 5, 2020 www.ricelake.com...
