- Page 1 Benchmark HD Series ® Heavy Duty Bench Scale Installation Manual January 6, 2020 PN 93631 Rev A...
- Page 2 All information contained within this publication is, to the best of our knowledge, complete and accurate at the time of publication. Rice Lake Weighing Systems reserves the right to make changes to the technology, features, specifications and design of the equipment without notice.
-
Page 3: Table Of Contents
Benchmark Series Limited Warranty..............8 Technical training seminars are available through Rice Lake Weighing Systems. - Page 4 Benchmark HD Series Rice Lake continually offers web-based video training on a growing selection Rice Lake continually offers web-based video training on a growing selection of product-related topics at no cost. Visit www.ricelake.com/webinars of product-related topics at no cost. Visit www.ricelake.com/webinars www.RiceLake.com...
-
Page 5: Introduction
Do not operate or work on this equipment unless this manual has been read and all instructions are understood. Failure to follow the instructions or heed the warnings could result in injury or death. Contact any Rice Lake Weighing Systems dealer for replacement manuals. -
Page 6: Benchmark Hd Specifications
Benchmark HD Series Benchmark HD Specifications Load Cell, NTEP Certified IP67 Aluminum, environmentally sealed Output Impedance 350 Maximum Overload 200% Overload Protection Five-point independently adjusted Cable Length 10' (3 m) Compensated Temperature Range 14°F – 104°F (-10°C – 40°C) Dimensions and Capacities... -
Page 7: Installation
Immediately after unpacking, visually inspect the Benchmark HD to ensure that the unit is undamaged. The shipping carton should contain the bench scale and this manual. If the scale was damaged in shipment, notify Rice Lake Weighing Systems and the shipper immediately. -
Page 8: Replacement Parts
Benchmark HD Series Replacement Parts Figure 2-2. Benchmark HD Assembly Drawing Breakout www.RiceLake.com Visit our website... - Page 9 Hex Jam Nut, 3/8 - 16NC 74585 Bench Scale Foot 15051 Set Screw, 1/2 - 20NF x 3/4 15410 Bubble Level 52342 Label Roll Table 2-2. Benchmark HD Assembly Replacement Parts © Rice Lake Weighing Systems ● All Rights Reserved...
-
Page 10: Maintenance
Benchmark HD Series Maintenance This section provides additional information about the Benchmark HD. Troubleshooting Symptom Probable Cause Remedy No display Power disconnected Connect power Cable cut or disconnected Repair cable Signal leads incorrectly wired at indicator Connect according to indicator manual... -
Page 11: Load Cell Replacement
20. Back screw off slightly so it is not touching the top frame. 21. Repeat for each corner. 22. Replace the top cover and re-level the scale if necessary. © Rice Lake Weighing Systems ● All Rights Reserved... -
Page 12: Benchmark Series Limited Warranty
Benchmark HD Series Benchmark Series Limited Warranty Rice Lake Weighing Systems (RLWS) warrants that all RLWS equipment and systems properly installed by a Distributor or Original Equipment Manufacturer (OEM) will operate per written specifications as confirmed by the Distributor/OEM and accepted by RLWS. - Page 14 Specifications subject to change without notice. Rice Lake Weighing Systems is an ISO 9001 registered company. 230 W. Coleman St. • Rice Lake, WI 54868 • USA U.S. 800-472-6703 • Canada/Mexico 800-321-6703 • International 715-234-9171 • Europe +31 (0)26 472 1319...
