Figure 2-3. Jumper Locations and Pin Numbers
IOP Mode Select (J1)
1
2
3
Recovery Mode (pins 1-2)
Normal Mode (pins 2-3)
PCI Bus Speed (J4)
1
Force 33 MHz (pins 1-2)
2
Auto-negotiate 33 or 66 MHz (pins 2-3)
3
