Transceivers and Cables

Supported transceivers and cables
Time and items required
Precautions specific to transceivers and cables
Cleaning the fiber-optic connectors
Managing cables
Installing a QSFP28 transceiver
Replacing a QSFP28 transceiver
Breakout cables
Verifying transceiver operation

Supported transceivers and cables

SLX 9740 switch routers require QSFP28 optics for 100GbE connectivity, and 40GbE-to-10GbE
breakouts for 10GbE connectivity.
For current information about transceivers and cables that is supported by this device, refer to Extreme
Ethernet Optics Family Datasheet on
b2f0-3d039ae2f604/data-center-ethernet-optics-data-sheet
ExtremeRouting SLX 9740 Release Notes .

Time and items required

The installation or replacement procedure for one transceiver takes less than 5 minutes. Ensure that the
following items are available:
•
Required number of compatible power cables
•
Required number of supported Extreme-branded transceivers
•
Required number of compatible fiber-optic cables
•
Optical transceiver extraction tool (for 10 Gbps transceiver only)
on page 57
on page 58
on page 62
https://cloud.kapostcontent.net/pub/a070d154-d6f1-400b-
Note
Most Extreme devices come with a transceiver extraction tool and holster. The extraction
tool is designed to remove transceivers from modules where the space is limited.
ExtremeRouting SLX 9740 Hardware Installation Guide
on page 57
on page 58
on page 58
on page 59
on page 61
on page 62
and to the current SLX-OS20.2.1 for
