Hardware features
The SLX9740-40C-AC-F switch router includes:
•
40 100GE/40GE QSFP28 ports
•
RJ45 out-of-band 10/100/1000BASE-T management Ethernet port.
•
RJ45 serial console port used to connect a terminal and perform local management.
•
USB port for access to external storage.
•
Two 1600 W AC power supplies
•
Six replaceble fan modules
The SLX9740-80C-AC-F switch router includes:
•
80 100GE/40GE QSFP28 ports
•
RJ45 out-of-band 10/100/1000BASE-T management Ethernet port.
•
RJ45 serial console port used to connect a terminal and perform local management.
•
USB port for access to external storage.
•
Four 1600 W AC power supplies
•
Four replaceble fan modules
Figure 1: SLX9740-40C Front Panel
1 = LEDs
2 = 100GE/40GE QSFP28 ports
3 = Management port
Figure 2: SLX9740-40C Rear Panel
1 = Power supplies
14 ExtremeRouting SLX 9740 Hardware Installation Guide
4 = USB port
5 = Console port
2 = Fan modules
