Amalfi Armchair
Assembly Instructions - Please keep for future reference
Dimensions
Width - 72.0cm
Depth - 58.0cm
Height - 104.0cm
Important - Read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456400800
1425361
Issue 1 -19/11/13
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Argos Amalfi Armchair 1425361
Summary of Contents for Argos Amalfi Armchair 1425361
- Page 1 Amalfi Armchair Assembly Instructions - Please keep for future reference 1425361 Dimensions Width - 72.0cm Depth - 58.0cm Height - 104.0cm Important - Read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456400800 Issue 1 -19/11/13...
- Page 2 Safety and Care Advice Important - Read these instructions fully before starting assembly • Make sure you have enough space to • Dispose of all packaging carefully and • Check you have all the components and layout the parts before starting. responsibly.
- Page 3 Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. M6 x 14mm Bolt x 4 M6 x 16mm Bolt x 4 M6 x 35mm Bolt x 4 d6.5 x D13 x 1.0 Washer x 8 d6.5 x D10 x 1.6 Washer x 8 M6 Bolt Cap x 4...
- Page 4 Assembly Instructions Step 1 Place the support to the left arm and the right arm by using bolts ( washers ( ) . Keep the bolts loose. Note: The labels marked “L” and “R” on arms ( ) should coincide with Step 2 to ensure proper assembly.
- Page 5 Assembly Instructions Step 3 Place the seat assembly the left arm and the right by using bolts ( ) , washers ( Keep the bolts loose. Step 4 Turn the chair to its upright . At the back of the chair, fasten the seat assembly to the arms ( by using bolts...
- Page 6 ( Assembly is completed. If you need help or have damaged or missing parts, call the Customer Helpline: 08456400800 Retailer: Argos Address: 489-499 Avebury Boulevard Saxon Gate West, Central Milton Keynes Bucks, MK9, 2NW...
