  • Page 1 INELO devices Manual Firmware version: 1.6.0 TachoReaderConfigurator: 1.6.0...
  • Page 2 INELO devices Manual © 2002 - 2020 INELO All rights reserved All rights reserved. No parts of this work may be reproduced in any form or by any means - graphic, electronic, or mechanical, including photocopying, recording, taping, or information storage and retrieval systems - without the written permission of the publisher.

  • Page 3: Table Of Contents

    Table of Contents 1. Introduction ........................5 2. TachoReader Mobile II ........................5 2.1. Installation ................................5 2.2. Configuration ................................6 2.2.1. Recommended confi gura ti on .......................................... 9 2.3. Download from tachograph ................................9 2.4. Download from driver card ................................
  • Page 4 6. Additional information ........................44 6.1. The company ................................44 6.2. Support ................................44 6.3. FAQ ................................45...

  • Page 5: Introduction

    USB interface into other storage medium. During the download TachoReader Mobile II is supplied with power by the tachograph (no extra energy sources needed). The TachoReader Mobile II is a small, user-friendly and handy device.

  • Page 6: Configuration

    TachoReader Mobile II TachoReader Mobile II To install on a computer, simply connect it to the USB port and wait until Windows installs it automatically. ® ® When it detects a new device, Windows automatically installs it as a new mass storage disk.
  • Page 7 - pick all data since last download with TachoReader The information about the previous download are stored in the memory of TachoReader Mobile II. Thus downloads with other devices are not taken into account. We suggest to use this option.
  • Page 8 - check to make the device retrieve data from driver card only when connected to the tachograph (for details, see the section: TachoReader Mobile II -> Download from driver card TachoReader Combo Plus -> Download from driver card inserted in the tachograph...

  • Page 9: Recommended Configuration

    TachoReader Mobile II 2.2.1. Recommended configuration Fig. Recommended configuration. Please make sure that during each data download "Since last download" option is selected. During the first data download, TachoReader automatically downloads the whole range of activities, but not more than from one year ago.

  • Page 10: Download From Driver Card

    The tachograph detects the card. Confirm the checkback "Company lock yes/no". Plug your TachoReader Mobile II into the tachograph interface. Position of the interface within the tachograph - see tachograph manual. The TachoReader Mobile II starts the download automatically (both D flashing green).
  • Page 11 Insert driver card from which data is to be retrieved into a free slot in the tachograph. fter recogni ing the card by the tachograph, connect the TachoReader Mobile II device to the tachograph port. For location of the port in the tachograph refer to the tachograph manual.

  • Page 12: Transferring Data Files Into Pc

    It is easier and more efficient to work with the device when this option is activated. Download data It is also possible to pick only a specified data file from the TachoReader Mobile II. Click " files " and then select the desired file in the list.

  • Page 13: Error Codes

    Kowalski_ an_Mateusz_20130 4432.DDD). The memory of TachoReader Mobile II can contain up to about 2 000 original data files 2.6. Error codes The TachoReader Mobile II announces errors with flashing The error type is identified by a number of red impulses between green signals.
  • Page 14 TachoReader Mobile II 4 x red Memory cluster fault or error. Contact the service of the manufacturer. 5 x red File system other than F Format device memory once again. Use the file system FAT32. Transfer all files onto another data medium before formatting.

  • Page 15: Tachoreader Combo Plus

    TachoReader Combo Plus 3. TachoReader Combo Plus TachoReader Combo Plus device allows to download data directly from a tachograph or a ’ driver s card, without having to connect other devices. What is more, the device makes it possible to store data in its internal memory until the data is transferred to a different data carrier (e.g.

  • Page 16: Operating Elements

    TachoReader Combo Plus DEVICE STORAGE internal memory of B minimum; · 0 000 stores up to 4 readings ( B version) from driver cards; · 10 000 stores up to readings ( B version) from digital tachograph; · OTHER supported by all current tachographs and driver cards; ·...
  • Page 17 TachoReader Combo Plus - driver card reader slot. (Item - Fig. above) Progress bar - indicates the progress of the data download or reading error (see: " rror codes "). (Item ) Main indicator - indicates the reading/writing and events e.g. reading error, starting data download from a driver card or tachograph, etc.

  • Page 18: Operating Modes

    TachoReader Combo Plus 3.3. Operating modes TR Combo Plus works in different modes. They depends on: connection type - whether the device is operates standalone or if it is connected to a · computer / tachograph; placing the driver card in the card reader slot or the tachograph slot; ·...

  • Page 19: Installation

    TachoReader Combo Plus No driver card Driver card download via tachograph Depending on the option: Option checked — error report (driver card should be inserted or the option should   be unchecked) - no data will be downloaded; Option unchecked —...

  • Page 20: Configuration

    TachoReader Combo Plus TachoReader Combo Plus The device The cable MINI-USB. Installation procedure TachoReader Combo Plus Connect the device to USB port via Mini USB cable and wait till Windows has performed the installation automatically. ® TachoReader Combo Plus In device manager you can find the installed as USB Mass Storage Device.
  • Page 21 TachoReader Combo Plus Fig. Configuration window. The options described below can be assigned separately to each of the three buttons on the unit (left-click on the button icon): Overview - basic tachograph data; · Events and faults - download events (e.g. driving without an appropriate card) and faults ·...
  • Page 22 TachoReader Combo Plus The tachograph stores the detailed speed data of the last 24 hours of driving in the memory. Reading this data can significantly extend the time of downloading data from the tachograph. Driver card download via tachograph · Option checked —...

  • Page 23: Configuration Directly In The Device

    TachoReader Combo Plus 3.5.1. Configuration directly in the device To perform configuration directly in the device: Select day range using this button Connect the device to a computer - select: option in the   "device configuration" window (wi cej w temacie: "Configuration ").
  • Page 24 TachoReader Combo Plus Driver card download via tachograph option:   Operations on the vehicle We recommend that you read the operating instructions of the tachograph. Turn the ignition switch to position II (ignition) - until the lights on the dashboard switch on (switching on the tachograph).
  • Page 25 TachoReader Combo Plus selected with the: button (see: "Configuration directly in the device " topic for more). – downloads data from tachograph / driver card, depending on the configuration (see: "Configuration "); The default configuration : download " verview", " vents and faults", Activities ->...

  • Page 26: Download From Driver Card/Workshop Card

    TachoReader Combo Plus nd of data download will be signaled by the device by repeated beeps and flashing on the progress bar. TR Combo Plus Disconnect from the tachograph and remove the company card. The data is saved to a file ( ehicle reg.no.

  • Page 27: Download From Driver Card Inserted In The Tachograph

    TachoReader Combo Plus Fig. TachoReader Combo Plus - inserting a driver card. No special speed data collected from VDO tachographs (a detailed description: "Download special speed data"). nd of data download will be signaled by the device by repeated beeps and flashing on the progress bar.
  • Page 28 TachoReader Combo Plus Option II - Simultaneous downloading data from driver card and the tachograph For any selected configuration of button, choose the type and scope of activities to be downloaded from the tachograph (see: "Configuration " topic for more). If you are not sure what to choose, click on the button: check Driver card download via tachograph...

  • Page 29: Transferring Data Files Into Pc

    TachoReader Combo Plus Tacho RC cable Connect TachoReader Combo Plus device to the tachograph using a Depending on the selected option: Option I - press the button you configured ( · Option II - press the button you configured ( ·...

  • Page 30: Error Codes

    TachoReader Combo Plus Transfer procedure from TachoReader Mobile II into a PC: Connect the TachoReader device to the USB port in your computer. Download data files When you press the appropriate button, select the " " -> " ". Menu in the 4Trans is different than shown here - refer to the 4Trans Help.
  • Page 31 TachoReader Combo Plus The whole line of the progress bar lights up smoothly four times ust before reading the card ow battery, you can download the data. Replace batteries / rechargeable batteries or connect the device to a tachograph or computer.

  • Page 32: Download From Tachograph

    TachoReader Combo Plus Read error Repead reading of the driver card. File system error Check the memory card of the device for file system error (scandisk) - ultimately, format the memory card. 3.10.2. Download from tachograph Possible errors when downloading from a digital tachograph: No data transmission Check if the plug of the Tacho-USB cable is pressed all the way into the socket of the tachograph.

  • Page 33: Battery Change

    TachoReader Combo Plus Insert the driver card into any slot of the tachograph or in the device configuration window Driver card download via tachograph uncheck the:   option (see: "Configuration " topic for more). Repeat reading from tachograph. No response from the tachograph Repeat reading from tachograph.

  • Page 34: Faq

    TachoReader Combo Plus Fig.TachoReader Combo - battery change. 3.12. FAQ Driver card is inserted in TachoReader Combo Plus and the LEDs on the device do not light up In this case re-insert the card into the device, press it so that the device sounds a beep and the first D on the progress bar lights up.
  • Page 35 TachoReader Combo Plus After connecting the TachoReader Combo Plus to the tachograph LEDs on the device do not blink and data from tachograph are not downloaded Switch the tachograph off and on, unplug and re-connect the device to the tachograph. If the problem persists, check the device on another tachograph.

  • Page 36: Tacho Usb Transmission Cable

    TachoReader Combo Plus 4. Tacho USB Transmission cable Plug the transmission cable ("Tacho USB") into USB port for direct data download from tachograph into the TachoScan software on the laptop. The advantage of this solution is the low cost of the device itself (when the user owns already a laptop and TachoScan).
  • Page 37 Tacho USB Transmission cable Plug the transmission cable into the USB port of the PC. Install from a list or The following window pops up (Fig. bellow). Choose the option specific location [Next >] (pos. ) and press the button (pos.
  • Page 38 Tacho USB Transmission cable Fig. The path to the device drivers. In the next window select path drivers cable: [OK] "TachoScan xtras Treiber TachoCable USB" (pos. - Fig. bellow) and press (pos. [Next>] Is the path selected, press (pos. - Fig. above). Fig.

  • Page 39: Configuration

    Tacho USB Transmission cable Fig. Installation completed. fter completing the installation (Fig. above) the hardware update wi ard pops up again (Fig. bellow); Repeat the steps from points Fig. Hardware Update Wizard once again. 4.2. Configuration Configuration depends on your version of TachoScan. Description is available in elp file of the appropriate program.

  • Page 40: Download From Tachograph

    Tacho USB Transmission cable 4.3. Download from tachograph Requirements for a data download from digital tachograph USB transmission cable, · laptop with installed software TachoScan, · company card. · Download procedure – Turn the vehicle key in the position II (ignition) the control lamps on the instrument board flash (tachograph activation).

  • Page 41: Transferring Data Files Into Pc

    Tacho USB Transmission cable Repeat the download, if the software signals a download fault. If the repeated download is not correct, perform a reference download on an another tachograph. If the last download is OK, the first tachograph might be out of order (contact tachograph service station).

  • Page 42: Tachoblue

    TachoBlue 5. TachoBlue TachoBlue is a device that enables data transfer from the digital tachograph to the PC via TachoScan usingi Bluetooth ® technology. Fig. TachoBlue. the first breakthrough solution on the market for wireless data transmission from digital · tachographs replaces a serial cable or USB, uses SPP (Serial Port Profile) protocol ·...

  • Page 43: Configuration

    TachoBlue The device is not supported by Windows ® 2000 and earlier operating systems. Installation steps Connect TachoBlue to an appropriate port in the tachograph, Windows Settings Devices o to and then click Bluetooth other devices Add Bluetooth or other device tab, click &...

  • Page 44: Transferring Data Files Into Pc

    Cable " and is described in the item: "Transferring data files into PC ". 6. Additional information 6.1. The company INELO Polska sp. z o.o. ul. Karpacka 24/U2b 43-300 Bielsko - Biała POLAND e-mail: biuro@inelo.pl tel.: +48 33 496 58 71 fax.: +48 33 496 58 71 (111)
  • Page 45 Additional information INELO Support e-mail: support@inelo.pl tel.: +48 33 496 58 74 6.3. FAQ You plugged the TachoReader Mobile into a USB port and the LED flashed. But the hardware is in fact not detected. Restart the PC. If it does not help, plug the device into another PC. If it does not help, contact the service of the device manufacturer.
  • Page 46 Additional information If the device still does not work then you should contact the manufacturer service After connecting the TachoReader Combo Plus to the tachograph LEDs on the device do not blink and data from tachograph are not downloaded Switch the tachograph off and on, unplug and re-connect the device to the tachograph. If the problem persists, check the device on another tachograph.
