8 WAYPoINt & DAtABASE
The GEOPILOT uses three types of Waypoints:
Jeppesen Waypoints are contained in the Compact Flash and include Airport, VOR, NDB and
Intersection Waypoints. Each of these Waypoints is displayed on the Moving Map by an icon. These
Waypoints can be searched in the Database Menu and identified on the Moving Map with Quick
Info or Full Info. Each of these Waypoints can be used in a Flight Plan, for the Nearest Search or
GoTo functions. When used in a Flight Plan, details regarding the Waypoint are displayed in the
Destination box during flight (when DEST is chosen for display in the Data Window, see Par. 3.5.).
Our Jeppesen library is updated every 8 days. Please contact your local C-MAP office for update
orders and pricing.
User-Defined Waypoints (also called User Waypoints) are created by the user. The user can
create unique 8 character names and choose from 16 icons for each waypoint. Waypoints can be
created and edited both on the Moving Map and in the User Waypoint Database page. Like the
Jeppesen Waypoints, they can be used in a Flight Plan, for the Nearest Search or GoTo functions.
The GEOPILOT can store up to 1,000 User-Defined Waypoints within the internal memory. The
internal waypoint memory capacity is shared with Flight Plan waypoints; i.e. if you have 10 flight
plans with 10 waypoints stored in the unit memory, there is room for 900 User Waypoints.
temporary Waypoints are created only on the Moving Map and are associated with a particular
Flight Plan. They are named in the format WPT001, WPT00 etc. Temporary Waypoints can be
used at the beginning, middle or end of Flight Plans. They can be used as the destination of a
Direct-To Flight Plan, but cannot be accessed in the Nearest function.
8.1 USEr WAYPoINtS – MovING MAP
8.1.1 Creating User Waypoints – Moving Map
From the Moving Map the User Waypoint is a saved cursor position. To create a User Waypoint at
the cursor position:
> 'ENTER' + "ADD WAYPOINT" + 'ENT'
A name is automatically assigned in the format "USRxxx", where "xxx" is a sequential number. You
may use the default display name, LAT/LON and symbol or edit them.
Note
When editing the waypoint, select the "picture" icon to associate the waypoint with the Waypoint Alarm (See Sec
14.3.3).
8.1.2 Saving Present Position – Moving Map Methods
To automatically save your present GPS position as a User Waypoint:
>'ENT' 1 sec.
A name is automatically assigned in the format "USRxxx", where "xxx" is a sequential number. The
default icon is an X. You may use the default display name, LAT/LON and symbol or edit them.
8.1.3 Editing User Waypoints – Moving Map Methods
You can edit the User Waypoint information from the default. From the Moving Map screen:
> Place the cursor over the Waypoint + 'ENT' + "EDIT WAYPOINT" + 'ENT'
48
