- Page 1 VISUAL INSTRUCTION ULTRAPROBE 10,000SD VALVE INSPECTION...
- Page 2 10,000SD VALVE INSPECTION Ultraprobe 10,000SD Valve Inspection: How To Guide NOTE: UE DMS Software available for download at www.uesystems.com FUNDAMENTALS Ultrasonic Valve Inspection is a Non Intrusive, Real Time Route Based OR Trouble Shooting Tactic in Assessing Valve Operation Being a Critical Tool for Reliability Centered Maintenance.
-
Page 3: Initial Setup
How To Guide NOTE: UE DMS Software available for download at www.uesystems.com INITIAL SETUP Power On the Ultraprobe 10,000SD, Pull and Hold the Instrument Trigger. Keep Trigger Pulled for Instrument to Remain ON. The Unit Will Power On in the Main Display. - Page 4 How To Guide NOTE: UE DMS Software available for download at www.uesystems.com INITIAL SETUP Set Up the Ultraprobe 10,000SD for Valve Inspection, Center the Frequency to 25KHz Using the Sensitivity Dial. “Click” Dial Until “KHZ” is Flashing, Then Spin to the Desired Frequency.
- Page 5 10,000SD VALVE INSPECTION Ultraprobe 10,000SD Valve Inspection: How To Guide NOTE: UE DMS Software available for download at www.uesystems.com INITIAL SETUP Select the Valve Application from the Setup Menu Located in the Function Bar. Press the Sensitivity Dial Until the Setup Menu is Flashing, Then Press ENTER Button.
- Page 6 Stored Within the Plant Created Within the DMS Software and is Available for Upload/Download and Review at Anytime. NOTE: the DMS Software is NOT Required if Using the Ultraprobe 10,000SD as a Troubleshooting Tool ONLY. SAFETY: WRIST STRAP WORN ALL TIMES...
-
Page 7: Inspection Procedure
10,000SD VALVE INSPECTION Ultraprobe 10,000SD Valve Inspection: How To Guide NOTE: UE DMS Software available for download at www.uesystems.com INSPECTION PROCEDURE With the Route Uploaded to the Ultraprobe, and the Frequency Set to 25KHz, Collect Data. Make Contact With the First Test Point Using the... - Page 8 10,000SD VALVE INSPECTION Ultraprobe 10,000SD Valve Inspection: How To Guide NOTE: UE DMS Software available for download at www.uesystems.com A, B, C, D, AND SOMETIMES E METHOD 3 x Pipe Diameter 3 x Pipe Diameter 2 x PD 2 x PD...
- Page 9 10,000SD VALVE INSPECTION Ultraprobe 10,000SD Valve Inspection: How To Guide NOTE: UE DMS Software available for download at www.uesystems.com A, B, C, D, AND SOMETIMES E METHOD A,B,C,D and Sometimes E Method Contains Four Easy Rules For Valve Condition Diagnosis: 1.
- Page 10 10,000SD VALVE INSPECTION Ultraprobe 10,000SD Valve Inspection: How To Guide NOTE: UE DMS Software available for download at www.uesystems.com INSPECTION PROCEDURE When Conducting Valve Inspections, Transitioning Displays is a Critical Component for Organized Data Acquisition and Diagnoses. When VALVE Application...
- Page 11 10,000SD VALVE INSPECTION Ultraprobe 10,000SD Valve Inspection: How To Guide NOTE: UE DMS Software available for download at www.uesystems.com INSPECTION PROCEDURE When Optimizing the Sensitivity for Each Data Point, Arrow Indicators Guide Which Direction to Spin the Dial. A RIGHT Arrow...
