- Page 1 Version 1 UE UCA586 ULTRASONIC CONDITION ANALYZER Instruction Manual...
-
Page 2: Table Of Contents
Mechanical Monitoring Concepts ....................... 4 Cavitation ............................4 Monitoring: flow/no flow and leakage ....................4 Solid Flow: Powders, Metal Filings, Etc....................4 UE UCA586 INSTALLATION & OPERATION ....................5 POWER REQUIREMENTS ........................5 SENSITIVITY CONTROL ......................... 5 THRESHOLD CONTROL ......................... 5 VOLTAGE AND CURRENT OUTPUTS ..................... -
Page 3: Overview
Version 1 OVERVIEW The UE UCA586 is an Ultrasonic Detection unit that is targeted for continuous monitoring. The unit offers an overall dynamic range of roughly 100 decibels, and is configured for structure borne ultrasonic detection. ULTRASOUND TECHNOLOGY The Ultrasound Technology utilized by this system is generally referred to as “Airborne Ultrasound”. -
Page 4: Mechanical Monitoring Concepts
Version 1 Mechanical Monitoring Concepts There are ultrasonic components in practically all forms of friction. As an example, if one were to rub the sensor probe with a finger, an ultrasonic signal will be generated. Although there might be some audible components to this friction, the sensor will only sense the ultrasonic components which, in this example, will be considered a gross signal that is also amplified. -
Page 5: Ue Uca586 Installation & Operation
UE UCA586 INSTALLATION & OPERATION POWER REQUIREMENTS The UE UCA586 requires a 24 Volt, DC power source @ 200 milliamperes total. The power connections are to be made to the I/O cable. Refer to the Pin Out/Description Diagram for the connections. -
Page 6: Decreases Of Ultrasound Levels
Brown Power Supply Voltage Input. 20 to 30 VDC, nominal 24VDC @200 mA maximum. PANEL INDICATORS: FUNCTION Blue UCA586 Powered Up & Ok to Monitor LED ON = Alarm Condition PANEL Adjustments: Sensitivity Adjust Threshold Adjust The Sensitivity and Threshold adjustments are internal and are located behind the black Button Head... - Page 7 Version 1 3.6875" TYP. 3.3125 " 2.50" 3.625" TYP. (4) HOLES .1875" DIA HEIGHT = 1.90"...
-
Page 8: Specifications
Version 1 Specifications Frequency Range: 25-50 kHz Outputs: 4-20 mA DC Linear Output Transfer Function: dB/mA DC Scale: 1 mA DC = 2.5 dB input Level Dynamic Measurement Range: 40 dB (set anywhere along the 100 dB input range) 0-10 DC V Linear Output Transfer Function: dB/VDC Scale: 1 VDC = 4 dB input level Dynamic Measurement Range: 40 dB(set anywhere along the 100 dB input range) - Page 9 ALPINE C O M P O N E N T S Postal Address Alpine Components Ltd Innovation Centre, Highfield Drive Churchfields St. Leonards-on-Sea TN38 9UH United Kingdom Telephone 01424 858118 Website Address www.alpine-components.co.uk "Alpine Components" is the abbreviated trading name for "Alpine Components Limited" The company has been trading since 1991 and was incorporated on 13/11/2006 in the United Kingdom Company Registration Number: 05996485 VAT Number: GB583598190...
