- Page 1 VISUAL INSTRUCTION ULTRAPROBE 10,000SD Recording Sound WAV Files...
- Page 2 10,000SD Recording WAV Files Ultraprobe 10,000SD – Recording WAV File: How To Guide NOTE: UE DMS Software and Spectralyzer Software available for download at www.UESystems.com Selecting Record WAV Proper Recording Parameters Recording WAV Files Saving WAV Files Reviewing WAV Files...
-
Page 3: Function Bar
10,000SD Recording WAV Files The Ultraprobe 10,000SD Comes Standard with Recording Capabilities. To Record Sound WAV Files, First Select Record WAV from the Function Bar, Located at the Bottom of the Main Display. Clicking the Sensitivity Dial Until the Function Bar is Flashing, Then Spin Dial Until Record WAV is Shown, Then Press ENTER. - Page 4 10,000SD Recording WAV Files To Ensure Proper Recording Parameters, The Intensity Meter Must Be Between Two (2) to Four (4) Bars. This Will Avoid Distortion of the Recording and “Clipping” of the Data Within the Software. SAFETY : THE WRIST STRAP SHOULD BE WORN AT ALL TIMES...
- Page 5 Recording WAV Files When Inspectors are Ready to Record, Enter into the Recording WAV Menu. PRESS HOLD Sensitivity Dial Begin Recording. The Ultraprobe 10,000SD Has a Maximum Recording Time of Two (2) Minutes. When Finished Recording, Simply Release the Sensitivity Dial. If Record WAV is Selected by Mistake, Press ENTER to Exit.
- Page 6 10,000SD Recording WAV Files When Active, the Ultraprobe 10,000SD Indicates a Recording is in Progress. This will Remain Within the Display While the Sensitivity Dial is Pressed. Once the Dial Is Released, Permanent Saving Options are Available. A Timed Option is Also Available from Five (5) to Thirty (30) Seconds Via Setup Menu #7 –...
- Page 7 10,000SD Recording WAV Files Once Recording is Completed, Release the Sensitivity Dial. The Ultraprobe 10,000SD Offers a Playback Option. By Pressing the ENTER Button, Inspectors Can Immediately Listen to the Recording to Ensure Quality. Once Played Back, or if No Playback is Necessary, Simply Press the Sensitivity Dial to Continue.
- Page 8 10,000SD Recording WAV Files Once Recording is Completed, Saving WAV Files is Simplified with Two (2) Options. Pressing the ENTER Button to Permanently Save the File Or Press the Sensitivity Dial to Exit the Record WAV Menu Without Saving the File. SAFETY : THE WRIST STRAP SHOULD BE WORN AT ALL TIMES...
- Page 9 10,000SD Recording WAV Files Once the ENTER Button is Pressed, Two (2) Confirmation Displays Will Populate. The First Will Be the Store Record Confirmed, Signifying That All Text Data Has Been Stored to the Preselected Record. SAFETY : THE WRIST STRAP SHOULD BE WORN AT ALL TIMES...
- Page 10 10,000SD Recording WAV Files Once Permanently Saved, the Ultraprobe 10,000SD Prompts a Confirmation Screen to Alert Inspectors the WAV File has Been Saved and Stored to That Specific Record Number. Once the WAV File has Been Saved Properly, The Unit...
