Playcore BigToys Junior Synchro Install Sheets

ITEM
1 CENTER POLE
2 PLAYPOD W/1.38" HOLE
3 48" FOOTING PIPE
4
HUB/SPINDLE ASSY
5 FINIAL 1
HARDWARE COMPLETE
6 PLAYPOD TO HUB ADAPTER
7
FINIAL SPACER 1
ANCHOR ROD
1/2" LOCKWASHER
1/2" x 1 1/4" B.H.C.S.
3/8" x 2" FLAT HEAD SOCKET CAP SCREW
3/8" x 1 1/2" FLAT HEAD SOCKET CAP SCREW
5/8" FLAT WASHER
BOLT, HEX 5/8-11 x 1 GRD 2 PLTD
3/8" FLAT WASHER
3/8" x 3/4" B.H.C.S.
3/8" COUPLER NUT
#8 x 3/4" WOOD SCREW
LABEL PACKAGE, 2-5 YEARS
Items listed below Hardware Complete line are included with Hardware Complete Number
Warning: During Installation, Hardware And Small Parts Are Choking Hazards For Young Children. Store
Unused Parts Appropriately Until Assembly Is Completed. Once Assembly Is Completed, Remove Any
Unused Parts From The Play Environment And Dispose/Save Them In A Secure Location. Any bolt end
protruding more than two full threads beyond the face of the nut causes risk of clothing entanglement.
Note: Peen Tee-Nuts and Flatwashers to match radius of pipe after assembly is complete.
Note: Loctite (supplied by others) should be used on any non-patch hardware.

INSTALLATION INSTRUCTIONS:

1. Dig footing holes as shown in Elevation and Plan Views.
2. Attach Finials and Finial Spacer to top of Center Pole Assembly using 3/8" x 3/4" B.H.C.S., 3/8" Flatwashers, #8 x 3/4" Wood
Screws, and 3/8" Coupler Nut. See Detail A.
2. Attach Playpod to Center Pole using 3/8" x 1 1/2" Flat Head Cap Screws, 5/8" x 1" Hex Bolt, 5/8" Flatwasher and Hub Adapter.
See Detail B.
3. Attach Hub/Spindle Assembly to Center Pole Assembly using 3/8" x 1 1/4" B.H.C.S. See Detail C.
6. Insert Anchor Rod into Footing Pipe. Place footing Pipe into footing hole. Confirm that the Footing Pipe is plumb before filling
hole with concrete. Allow Concrete to cure at least 48 hours before use. Temporary bracing may be required until concrete cures.
7. Attach Synchro Spinner Assembly to Footing Pipe using 1/2" x 1 1/4" B.H.C.S. AND 1/2" Lockwasher. See Detail D.
8. Attach Warning Label and Age Appropriate Label on the outside of Footing Pipe as high as possible.
Note: Areas must be clean and dry before attaching Labels.
Issued/Revised: 4/14/15
1-866-814-8697
MEC-130 SYNCHRO JR.
DESCRIPTION
Unless Otherwise Specified, All Units of Measure are Each
Promptly cut-off flush, file smooth, and treat to prevent corrosion.

Parts List

QTY
1
1
1
1
2
1
1
1
1
3
3
1
5
1
1
2
2
1
4
1
PART NUMBER
2435
G441
G433GS
404655
401585
404659
402139
401588
402121
817342
811062
811444
811442
817468
801301
817410
811052
804811
815517
E402E
SHEET 1 OF 4
