Playcore BigToys MBT-410 Manual

ITEM
1
2
3
4
5
6
7
Items listed below Hardware Complete line are included with Hardware Complete Number
Warning: During Installation, Hardware And Small Parts Are Choking Hazards For Young Children. Store
Unused Parts Appropriately Until Assembly Is Completed. Once Assembly Is Completed, Remove Any
Unused Parts From The Play Environment And Dispose/Save Them In A Secure Location. Any bolt end
protruding more than two full threads beyond the face of the nut causes risk of clothing entanglement.
Note: Peen Tee-Nuts and Flatwashers to match radius of pipe after assembly is complete.
Note: Loctite (supplied by others) should be used on any non-patch hardware.

INSTALLATION INSTRUCTIONS:

1. Dig footing holes as shown in Elevation and Plan Views.
2. Attach Playpod to Center Pole using 3/8" x 1 1/2" Cap Screws. See Detail A.
3. Attach Wobbly Discs to pole using 1/4" x 2 1/2" Spanner Head Screw and Dowel Nut. See Detail B.
4. Attach Finials and Finial Spacer to top of Center Pole Assembly using 3/8" x 3/4" B.H.C.S., 3/8" Flatwashers, #8 x 3/4" Wood
Screws, and 3/8" Coupler Nut. See Detail C
5. Attach Hub/Spindle Assembly to Center Pole Assembly using 3/8" x 1 1/4" B.H.C.S. See Detail D.
6. Insert Anchor Rod into Footing Pipe. Place footing Pipe into footing hole. Confirm that the Footing Pipe is plumb before filling
hole with concrete. Allow Concrete to cure at least 48 hours before use. Temporary bracing may be required until concrete cures.
7. Attach Synchro Spinner Assembly to Footing Pipe using 1/2" x 1" B.H.C.S. AND 1/2" Lockwasher. See Detail E.
8. Attach Warning Label and Age Appropriate Label on the outside of Footing Pipe as high as possible.
Note: Areas must be clean and dry before attaching Labels.
Issued/Revised: 3/7/14
1-866-814-8697
MBT-410 SYNCHRO SPINNER
DESCRIPTION
CENTER POLE
PLAYPOD W/1.38" HOLE
545 HUB / SPINDLE ASSY, SYNCHRO
48" FOOTING PIPE
FINIAL 1
WOBBLY DISC
HARDWARE COMPLETE
FINIAL SPACER 1
1/2" LOCKWASHER
1/2" x 1 1/4" B.H.C.S.
CAP SCREW, RED.HD 3/8 x 1-1/2 SOC FLT HD SS
3/8" COUPLER NUT
3/8" x 3/4" B.H.C.S.
3/8" FLAT WASHER
DOWEL NUT, 1/4-20
SCREW, 1/4 X 2-1/2" SS - SPANNER HEAD
#8 x 3/4" WOOD SCREW
CAP SCREW, 3/8 x 1-1/4 SOC FLT HD SS
ANCHOR ROD
DECAL PACKAGE, 5-12 YEARS
Unless Otherwise Specified, All Units of Measure are Each
Promptly cut-off flush, file smooth, and treat to prevent corrosion.

Parts List

QTY PART NUMBER
1 G887P
1 G441
1 EGA201
1 G433GS
2 401585
2 401586
1 404660
1 401588
3 817342
3 811062
3 2441
1 804811
2 811052
2 817410
2 1598
2 0431
4 815517
5 2442
1 402121
1 E402
bigtoys.com
SHEET 1 OF 5
