Playcore BigToys EC-610 Installation Instructions

Water table

Advertisement

EC-610
Installation Instructions
DET. QTY. PART#
A
401111
1
B
G150_
1
D420_
1
C
800805
4
D
G030_
4
E
G032_
4
F
804353
8
G
817401
4
Water Table
Water Table
DESCRIPTION
2' Water Table Tube
Water Table Basin
Connector, Water Table
Bolt Hex 3/8-16 x 8-1/2" Grd 2 NC Pltd
Do-Nut Base (No Boss) 10mm
Do-Nut Cap 10mm
Nut Hex 3/8-16 2-Way Locknut NC PLTD
Washer 3/8" USS Pltd
ICON (NOT TO SCALE)
1 2
/
Copyright © BigToys
i610E
032912
CMS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BigToys EC-610 and is the answer not in the manual?

Questions and answers

Summary of Contents for Playcore BigToys EC-610

  • Page 1 Water Table EC-610 Installation Instructions DET. QTY. PART# DESCRIPTION ICON (NOT TO SCALE) 401111 2' Water Table Tube G150_ Water Table Basin D420_ Connector, Water Table 800805 Bolt Hex 3/8-16 x 8-1/2" Grd 2 NC Pltd G030_ Do-Nut Base (No Boss) 10mm G032_ Do-Nut Cap 10mm 804353...
  • Page 2 1. Refer to your structure design for location of Water Table. 2. Dig footing holes as shown (See Standard Footings in "Typical Concrete Footings".) 3. Drill holes in bottom flange of Tube (A) . 4. Attach Footing Bolts (C) using hardware (D)(E)(F)(G).
