7. MOUNTING YOUR MAGIC ARM ON SLIDERPLUS
1/4" Mounting
Hole
1. You can mount any camera head or arm to your SliderPLUS with 1/4" mounting screw.
A detailed video explaining mounting process can be found at:
http://edel.kr/sld5
8. INCLINED MOTION
1
To get inclined shots,
1. Place your SliderPLUS onto 3/8"-16 mounting screw of your tripod head.
2. Attach your
3. You should attach your Slide Module to incline side of the SliderPLUS.
4.
5. Place your camera to
!
!
1
FlexTILT Head or any camera head onto your SliderPLUS.
You should tighten the slide tension of the Slide Module to get inclined motion.
FlexTILT Head or any camera head.
If you are not able to slide manually after inclined operation, try loosening the tension.
Make as small adjustments as possible.
Please make sure that your tripod legs are opened widely enough to prevent falls and
balance issues.
A detailed video explaining inclined motion can be found at:
http://edel.kr/sld5
5
3
2
4
