V5
http://edel.kr/sld5
TABLE OF CONTENTS
1.
WHAT'S IN THE BOX & THE BASICS
2.
ATTACHING THE BELTS & TENSION ADJUSTMENT
3.
ATTACHING THE BELTS & TENSION ADJUSTMENT
4.
LEGS & ANGLE ADJUSTMENT
5.
MOUNTING SLIDERPLUS ON TRIPOD
6.
MOUNTING YOUR CAMERA ON SLIDERPLUS
7.
MOUNTING YOUR MAGIC ARM ON SLIDERPLUS
8.
INCLINED MOTION
9.
CLEANING KIT
10.
CAUTIONS AND TIPS
Advertisement
Related Manuals for edelkrone SliderPlus PRO V5
Summary of Contents for edelkrone SliderPlus PRO V5
- Page 1 TABLE OF CONTENTS http://edel.kr/sld5 WHAT’S IN THE BOX & THE BASICS ATTACHING THE BELTS & TENSION ADJUSTMENT ATTACHING THE BELTS & TENSION ADJUSTMENT LEGS & ANGLE ADJUSTMENT MOUNTING SLIDERPLUS ON TRIPOD MOUNTING YOUR CAMERA ON SLIDERPLUS MOUNTING YOUR MAGIC ARM ON SLIDERPLUS INCLINED MOTION CLEANING KIT CAUTIONS AND TIPS...
- Page 2 1. WHAT’S IN THE BOX & THE BASICS 2. ATTACHING THE BELTS & TENSION ADJUSTMENT 1. Attach either the manuel control belt or the motion control belt depending on use. 2. Remove the wheel. Rubber feet Incline 3. Pass the belt through the hole. Built-in foldable legs Mounting wheel for 3/8”-16 mounting port Cleaning kit (x3)
-
Page 3: Leg & Angle Adjustment
3. ATTACHING THE BELTS & TENSION ADJUSTMENT 4. LEG & ANGLE ADJUSTMENT To adjust the legs, 1. Loosen the wheel by turning it counterclockwise. 2. Legs are adjustable at each 15°. Adjust the leg at an appropriate angle. 3. Tighten the wheel by turning it clockwise. - Page 4 5. MOUNTING YOUR SLIDERPLUS TO YOUR TRIPOD 6. MOUNTING YOUR CAMERA TO YOUR SLIDERPLUS SliderPLUS has 3/8”-16 screw for your tripod head hidden inside. You can access this screw with the help of a coin. Using a coin, turn the screw until it pops out.
- Page 5 7. MOUNTING YOUR MAGIC ARM ON SLIDERPLUS 8. INCLINED MOTION 1/4” Mounting Hole To get inclined shots, 1. Place your SliderPLUS onto 3/8”-16 mounting screw of your tripod head. 2. Attach your FlexTILT Head or any camera head onto your SliderPLUS. 3.
-
Page 6: Cleaning Kit
9. CLEANING KIT 10. CAUTIONS AND TIPS Please contact our dedicated customer care team for recommended tripod legs. In order to get perfect results with you SliderPLUS please attach your SliderPLUS directly to tripod legs, not to tripod head. If your tripod has a feature that allows you to extend the height from its neck, we suggest keeping it down and as tight as possible in order to prevent a rainbow effect. - Page 7 DISCLAIMER edelkrone cannot be held responsible for damage caused by improper use or modification Please make sure that your SliderPLUS of the product. withstands within the area of the tripod legs For more information and tips about your SliderPLUS, please watch the user’s to prevent falls and balance issues.
