edelkrone SliderPlus PRO V5 User Manual page 4

5. MOUNTING YOUR SLIDERPLUS TO YOUR TRIPOD
1
1. Detach tripod head from your tripod.
2.
Place your SliderPLUS onto your tripod's 3/8"-16 mounting screw.
3. Mount using the mounting wheel.
A detailed video explaining the process can be found at:
http://edel.kr/sld5
6. MOUNTING YOUR CAMERA TO YOUR SLIDERPLUS
3
2
1. SliderPLUS has 3/8"-16 screw for your tripod head hidden inside. You can
access this screw with the help of a coin. Using a coin, turn the screw until it
pops out. To hide the screw back again just press it down and turn it counter
clockwise.
2.
Place your tripod head on the screw and tighten clockwise.
3.
Attach your camera to your tripod head.
A detailed video explaining the mounting process can be found at:
http://edel.kr/sld5
3
2
1
