3. ATTACHING THE BELTS & TENSION ADJUSTMENT
1. Attach the other head of belt.
2. If belt tension is low, you may increase it by
loosening the side wall screws and pulling out
the side walls until desired tension is achieved.
A detailed video explaining how to attach the belts details can be found at:
http://edel.kr/sld5
1
2
4. LEG & ANGLE ADJUSTMENT
2
A detailed video explaining how to leg adjustment details can be found at:
http://edel.kr/sld5
To adjust the legs,
1. Loosen the wheel by turning it
counterclockwise.
2. Legs are adjustable at each 15°. Adjust
the leg at an appropriate angle.
3. Tighten the wheel by turning it
1
clockwise.
3
