Ingersoll-Rand 3840M/VSM-6171 Manual

IMPORTANT SAFETY INFORMATION ENCLOSED - - SAVE THESE INSTRUCTIONS
READ AND UNDERSTAND THIS MANUAL BEFORE OPERATING THIS PRODUCT
IT IS YOUR RESPONSIBILITY TO MAKE THIS SAFETY INFORMATION
AVAILABLE TO OTHERS THAT WILL OPERATE THIS PRODUCT
FAILURE TO OBSERVE THE FOLLOWING WARNINGS COULD
Always install, operate, inspect and maintain this
•
product in accordance with all applicable standards
and regulations (local, state, country, federal, etc.).
Always use clean, dry air at 90 psig (6.2 bar/620 kPa)
•
maximum air pressure at the inlet. Higher pressure
may result in hazardous situations including excessive
speed, rupture, or incorrect output torque or force.
Be sure all hoses and fittings are the correct size
•
and are tightly secured. See Dwg. TPD905- - 2 for a
typical piping arrangement.
Ensure an accessible emergency shut off valve has
•
been installed in the air supply line, and make others
aware of its location.
Do not use damaged, frayed or deteriorated air hoses
•
and fittings.
Always wear eye protection when operating or
•
performing maintenance on this motor.
Always wear hearing protection when operating this
•
motor.
Always use Personal Protective Equipment
•
appropriate to the product used and material worked.
This may include dust mask or other breathing
apparatus, safety glasses, ear plugs, gloves, apron,
safety shoes, hard hat and other equipment.
Refer all communications to the nearest Ingersoll- - Rand
Office or Distributor
 Ingersoll- - Rand Company 2003
Printed in U.S.A.
MODEL 3840M/VSM- - 6171
THREAD BEVELING MACHINE MOTOR
RESULT IN INJURY
PLACING MOTOR IN SERVICE
USING THE MOTOR
03540861
Keep clear of whipping air hoses. Shut off the
•
compressed air before approaching a whipping
hose.
Always turn off the air supply and disconnect the air
•
supply hose before installing, removing or adjusting
any accessory on this motor, or before performing any
maintenance on this motor.
Do not lubricate with flammable or volatile liquids
•
such as kerosene, diesel or jet fuel. Use only
recommended lubricants.
Keep work area clean, uncluttered, ventilated and
•
illuminated.
Do not remove any labels. Replace any damaged label.
•
Keep others a safe distance from your work area, or
•
ensure they use appropriate Personal Protective
Equipment.
This motor is not insulated against electric shock.
•
This motor is not designed for working in explosive
•
atmospheres.
Form P7177
Edition 2
March, 2003
