Thread Beveling Machine Motor
Model 3840M/VSM-6171
Installation and
Maintenance Information
Save These Instructions

Advertisement

loading
Need help?

Need help?

Do you have a question about the 3840M/VSM-6171 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Ingersoll-Rand 3840M/VSM-6171

  • Page 1 Form P7177 CCN 03540861 Edition 3 December 2005 Thread Beveling Machine Motor Model 3840M/VSM-6171 Installation and Maintenance Information Save These Instructions...
  • Page 2 Do not use this motor for purposes other than those • This motor is not insulated against electric shock. recommended. • This motor is not designed for working in explosive • Use accessories recommended by Ingersoll-Rand. atmospheres. Safety Symbol Identification Wear Hearing Wear Eye Read Manuals Before Wear Respiratory...
  • Page 3: Installation

    For USA - No. C22-04-G00 For International - No. C26-C4-A29 After each forty hours of operation, or as experience indicates, inject 1.5 cc of Ingersoll-Rand No. 28 Grease into Ingersoll-Rand No.50 Ingersoll-Rand No.28 the Grease Fitting (44). Do not grease excessively. Too much grease in the Gear Case will cause heating.
  • Page 4 3840M/VSM-6171 Thread Beveling Assembly Drawing 3840M/VSM-6171 Thread Beveling Parts List Item Part Description Part Number Item Part Description Part Number Throttle Handle VSM-6228 Motor Housing R3800-40 Throttle Connector VSM-780 Rear End Plate R3800-12 Air Strainer 434-61 Rear Rotor Bearing R1-24...
  • Page 5: Parts And Maintenance

    Parts and Maintenance NOTICE The use of other than genuine Ingersoll-Rand replacement parts may result in safety hazards, decreased motor performance, and increased maintenance, and may invalidate all warranties. Ingersoll-Rand is not responsible for customer modification of motors for applications on which Ingersoll-Rand was not consulted.
  • Page 6 Notes 03540861_ed3...
