PAN wheel controls DMX channel 1, TILT wheel controls DMX channel 2.
4. Press and hold the / MODE / button, use the / AUTO / DEL / button to delete the assignment.
5. To save, press the / MODE / and / FINE / buttons simultaneously. To confirm the process, all LEDs on the
controller flash three times.
6. Press and hold the / PROGRAM / button to exit configuration mode.

2.2.5 Invert output values:

The output values of the 512 control channels can be inverted individually. If inversion is activated, the fader
outputs the maximum DMX value when it is pulled down and the value "zero" when it is at the top.
1. Press and hold the / PROGRAM / button until the control LED flashes.
2. Press the / FINE / & / MODE / buttons simultaneously until the / REVERSE / LED lights up.
3. Use the / BANK ▲ / or / BANK ▼ / button to choose between PAN and TILT.
4. Use the / SCANNER / 1-12 buttons to select the device whose DMX channel you want to invert.
5. Use the / TAP / DISPLAY / button to select the 8 or 16 channel range.
6. Hold down the / MODE / button, use the / SCENES / buttons to assign the DMX channel.
7. To save, press the / MODE / and / FINE / buttons simultaneously twice in succession. To confirm the process,
all LEDs on the controller flash three times.
8. Press and hold the / PROGRAM / button to exit the configuration mode.

2.2.6 To delete an inversion:

1. Press and hold the / PROGRAM / button until the control LED flashes.
2. Press the / FINE / & / MODE / buttons simultaneously until the / REVERSE / LED lights up.
3. Use the / FIXTURES / 1-12 buttons to select the device whose DMX channel inversion is to be deleted.
4. Press and hold the / MODE / button, use the / AUTO / DEL / button to delete the assignment.
5. To save, press the / MODE / and / FINE / buttons simultaneously twice in succession. To confirm the process,
all LEDs on the controller flash three times.
6. Press and hold the / PROGRAM / button to exit the configuration mode.

2.2.7 Show DMX channel:

With this function you can display which channel the PAN / TLT movement is assigned to.
1. Press the / Mode / and / FINE / buttons simultaneously until the / ASSIGN / LED lights up.
2. Use the / FIXTURES / 1-12 buttons to select the device whose DMX values are to be read out.
The PAN / TILT value appears on the display. For example:
RES 04 00
X/Y →
8CH
means that the PAN movement is assigned to channel 4 and the TILT movement to channel 5.
ASS 04 05
X/Y →
8CH
means that the PAN movement on channel 4 has been inverted.

2.2.8 Delete all DMX address assignments and channel settings:

If necessary, all DMX address assignments and channel settings can be deleted and reset to the default settings.
1. Turn off the device.
2. Simultaneously hold down the / MUSIC / BANK COPY / and / AUTO / DEL / buttons and switch on the device.
3. After about 2 seconds, all LEDs of the controller light up briefly.
The deletion has taken place and the control channels can be reconfigured.
