3.4. Coil unit mounting instructions
DOCUMENT NR 4022.363.4197.1
Be sure that the mounting surfaces are free of
contamination. Particles > 0.1mm can cause inaccurate
placement and consequently damage to your Linear Motor.
The mounting of the coil unit on appropriate and clean mounting
surfaces is very straightforward because no attraction forces are
present between coil unit and magnet yokes.
The coil unit can be placed into the machine by hand carefully, pushed
to the axial reference and fixed with bolts. Tightening torque of the bolts
as prescipted.
For applications which are susceptible to vibrations, the
bolts have to be secured against loosening by means of
rings or (Loctite) thread lock.
In case of high continous forces, apply a heatsink compound
to obtain optimal thermal contact between the coil unit and
the mounting surface.
