3.3. Magnet track mounting instructions

DOCUMENT NR 4022.363.4197.1
• milled reference along complete side of a long track (inner radius <
0.2mm), or
• alignment by hand during mounting.
Axial reference for the coil unit (CR) is obtained by
• two dowel pins beside the first and last bolt of the coil unit,
• milled reference along complete side (inner radius < 0.2mm), or
• alignment by hand during mounting.
Note that only when the right references and dimensions are applied
the right dimensioned air gaps (A1 and A2) will be obtained. The
dimensions of the coil units and magnet yokes can be found on the
internet site of Tecnotion: www.tecnotion.com.
Especially the magnet yokes must be handled with care.
They are sensitive to mechanical shocks. Never drop a
magnet yoke or release it in an uncontrolled way!
Be sure that the mounting surfaces are free of
contamination. Particles > 0.1mm can cause inaccurate
placement and consequently damage to your Linear Motor.
It is recommended to start the mounting of the magnet track with the
middle – and preferably the longest – magnet yoke. This middle yoke
can be aligned using the 3mm dowel pins or a milled reference.
Fix the magnet yoke on the mounting surface with bolts using the
prescripted tightening torque.
