STEIN VIDA Manual

Square shower unit
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
VIDA SQUARE SHOWER
UNIT
JAN 2020
IMPORTANT!
1.
When you receive your Vida Square Shower package please check for any freight damage.
2. If damage has occurred advise your supplier within 8 hours.
3. Do not install any faulty product as this will invalidate later claims.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VIDA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for STEIN VIDA

Summary of Contents for STEIN VIDA

  • Page 1 JAN 2020 IMPORTANT! When you receive your Vida Square Shower package please check for any freight damage. 2. If damage has occurred advise your supplier within 8 hours. 3. Do not install any faulty product as this will invalidate later claims.
  • Page 2 VIDA SHOWER UNIT SQUARE WARRANTY • This covers faulty product for 1 year. Check www.stein.co.nz for full details of warranty. • Any breakage on site will not be covered. • The installation must conform to the instructions for the warranty to apply.
  • Page 3 ASSEMBLY DIAGRAM PARTS LIST Stein Part Nos. Description Size (mm) Unit Wall Plug (Concrete) 6x30 Wall Channel 1830 Wall Channel Screws ST3. 5x35 Screw Cap Frame to Wall Channel Screws ST4x10 Door Panel 1725x780x6 Handle Return Panel 1830x822x5 Door Bottom Seal...
  • Page 4 LAYOUT PLAN A WALL WALL CHANNEL CHANNEL 13mm IMPORTANT! Before you start read through to get the concept. 1. Mark out the wall channels 13mm off acrylic tray edge. 2. If the tray is not level or walls are out of plumb protruding or curving inwards more than 4mm recalculation of this position as required.
  • Page 5 INSTALLATION Install door set and return panels into wall channels. Join the two panels at corner. Fasten outside corner, square up door in frame. Align shower screen to tray and wall channels. Complete fastenings.
  • Page 6 INSTALLATION Fit door parts. Fit back door seal and make final adjustments to door.
  • Page 7 SCREENS THAT ARE SEALED ON THE INSIDE WILL VOID WARRANTY. Seal the join between wall profile and frame. 150mm up from base on both sides. CONTACT Freephone: 0800 002 299 Phone: 07 928 9990 Fax: 07 928 9999 Email: info@stein.co.nz www.stein.co.nz...
