GEORGIA SHOWER UNIT
CURVED – ACRYLIC INSTRUCTIONS
DECEMBER 2018
IMPORTANT!
1. When you receive your Georgia Curved Shower package please check for any freight damage.
2. If damage has occurred advise your supplier within 8hours.
3. Do not install any faulty product as this will invalidate later claims.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for STEIN Georgia Acrylic
Summary of Contents for STEIN Georgia Acrylic
- Page 1 GEORGIA SHOWER UNIT CURVED – ACRYLIC INSTRUCTIONS DECEMBER 2018 IMPORTANT! 1. When you receive your Georgia Curved Shower package please check for any freight damage. 2. If damage has occurred advise your supplier within 8hours. 3. Do not install any faulty product as this will invalidate later claims.
- Page 2 GEORGIA SHOWER UNIT CURVED – ACRYLIC INSTRUCTIONS WARRANTY • This covers faulty product for 5 years. Check www.stein.co.nz for full details of warranty. • Any breakage on site will not be covered. • The installation must conform to the instructions for the warranty to apply.
- Page 3 ASSEMBLY DIAGRAM Before commencing installation, please ensure you have the following components in your package to complete installation. [14] [10] [11] [12] [13] REF DESCRIPTION PART NO. QTY REF DESCRIPTION PART NO. Screws M3.5x30 Fixed panels Screws M4x35 Screw Pack Screw cap covers Door panels PAR5087...
- Page 4 LAYOUT PLAN Diagram A 13mm IMPORTANT: Position the wall profiles at 13mm off the Acrylic tray edge (Diagram A). This will allow for walls out of plumb protruding or curving inwards up to 4mm. Greater variations to plumb will require recalculated reduction of Diagram A.
- Page 5 INSTALLATION Mark out the positioning of the wall profiles (refer to the Layout Plan on page 5 for measurements). Using a soft pencil or masking tape mark out the outside boundary line on the base and up the walls with a spirit level. Use the wall channel holes to pre-drill a 2mm lead hole in the lining. Prior to wall channel fixing Apply a continuous 7mm bead of silicone on back of channel...
- Page 6 INSTALLATION Fit the frame into the wall channels. Tip: Compressing the frame into the second wall channel can be made easier by the following steps: Fit one side offset to the channel as diagram (1a). Fit other end correctly into the opposite channel (1b). Refit the first side as channel (1c).
- Page 7 INSTALLATION Adjust the sliding doors as shown in the illustration below. Adjust the sliding doors using the screws located on the bottom of top roller assemblies. Adjust rollers so that the sliding doors are parallel to each other. Note: Do not over tighten top rollers as this will cause the bottom rollers to jam and break 1.
- Page 8 CONTACT Freephone: 0800 002 299 Phone: 07 928 9990 Fax: 07 928 9999 Email: info@stein.co.nz www.stein.co.nz...
