- Page 1 WINDSOR SHOWER UNIT CURVED ACRYLIC FEB 2020 IMPORTANT! When you receive your Windsor Curved Shower package please check for any freight damage. 2. If damage has occurred advise your supplier within 8 hours. 3. Do not install any faulty product as this will invalidate later claims.
- Page 2 WINDSOR SHOWER UNIT CURVED – ACRYLIC INSTRUCTIONS WARRANTY • This covers faulty product. Check www.stein.co.nz for full details of warranty. • Any breakage on site will not be covered. • The installation must conform to the instructions for the warranty to apply.
- Page 3 ASSEMBLY DIAGRAM Before commencing installation, please ensure you have the following components in your package to complete installation. [14] REF DESCRIPTION PART NO. QTY REF DESCRIPTION PART NO. Screws M3.5x35 Bump stop caps PAR6848 Wall plug (concrete) Door panels SCREW PACK PAR7296 Screw cap covers Top rollers...
- Page 4 LAYOUT PLAN 13mm IMPORTANT: Position the wall channels at 13mm off the Acrylic tray edge (Diagram A). This will allow for walls out of plumb protruding or curving inwards up to 4mm. Greater variations to plumb will require recalculated reduction of Diagram A. INSTALLATION STEPS PAGE 5 TO 7 MINIMUM AND MAXIMUM TABLE The Minimum and Maximum table is intended for shower installations outside of the package...
- Page 5 INSTALLATION Mark out the positioning of the wall profiles (refer to the Layout Plan on page 4 for measurements). Using a soft pencil or masking tape mark out the outside boundary line on the base and up the walls with a spirit level. Use the wall channel holes to pre-drill a 2mm lead hole in the lining. Prior to wall channel fixing Apply a continuous 7mm bead of silicone on back of channel...
- Page 6 INSTALLATION Fit the frame into the wall channels. VIEW FROM INSIDE Fit the Door assemblies as illustrated. Adjustment NOTE: Use button (Arrow) to depress the bottom roller to enter or remove from bottom rail. Detailing of shower assembly: • A1 and A2: Fit the Door handles •...
- Page 7 INSTALLATION Adjust the sliding doors as shown in the illustration below. ADJUST THE SLIDING DOORS USING THE SCREWS LOCATED ON THE BOTTOM OF TOP ROLLER ASSEMBLIES. ADJUST ROLLERS SO THAT THE SLIDING DOORS ARE PARALLEL TO EACH OTHER. NOTE: DO NOT OVER TIGHTEN TOP ROLLERS AS THIS WILL CAUSE THE BOTTOM ROLLERS TO JAM AND BREAK A.
- Page 8 CONTACT Freephone: 0800 002 299 Phone: 07 928 9990 Fax: 07 928 9999 Email: info@stein.co.nz www.stein.co.nz...
