  • Page 1 SMART INSTRUCTIONS FOR INSTALLATION, USE AND MAINTENANCE...
  • Page 3 1. The unit may be used by children over 8 years of age and by persons with reduced physical, sensory or mental capacities, or without the required experience or knowledge, provided they are supervised or have been instructed in the safe use of the unit and understand the hazards involved.
  • Page 4 1. La unidad puede ser utilizada por niños mayores de 8 años y por personas con capacidades físicas, sensoriales o mentales reducidas, o carentes de la experiencia y conocimiento necesarios, siempre que lo hagan bajo vigilancia o después de haber recibido instrucciones sobre el uso seguro de la unidad y sobre los peligros inherentes al mismo.
  • Page 5 SMART INSTRUCTIONS FOR INSTALLATION, USE AND MAINTENANCE DIRECTIVES D’INSTALLATION, D’UTILISATION ET D’ENTRETIEN INSTRUCCIONES DE INSTALACIÓN, USO Y MANTENIMIENTO...
  • Page 7 ø8mm min 300 min 12” min 200 min 8”...
  • Page 8 ø6mm...

  • Page 13: Table Of Contents

    3.5.4 - resetting all remote-control functions ...................21 3.5.5 - operating the unit without remote control ..................21 3.6 - enerGY SavinGS reCommenDationS ................21 3.7 - DiaGnoStiC reCommenDation ....................21 3.8 - troUBleSHootinG ........................21 4 - UNIT SPECIFICATIONS ..........................22 US-ENG- 1 MAESTRO SMART...

  • Page 14: Warnings

    This document is confidential pursuant to the law and may not be reproduced or transferred to third parties without the explicit authorization of the olimpia Splendid. the unit may undergo updates and therefore have details different from those represented, without prejudice to the texts contained in this manual.

  • Page 15: General Information

    0.3 - GENERAL INFORMATION 1. OLIMPIA SPLENDID would like to thank you for choosing our product. This product represents the state-of-the-art in-home heating & air-conditioning technology and will provide the end user with many years of indoor comfort.
  • Page 16 4. OLIMPIA SPLENDID reserves the right to modify at any time its models without changing the fundamental characteristics described in this manual. 5. The installation and maintenance of units like this one may be hazardous as they contain a refrigerant gas under pressure as well as mechanical parts.

  • Page 17: Unit

    Send the same information by email to olimPia SPlenDiD (techsupport@olimpiasplendiusa.com). e. No claims for damage will be accepted if made more than 3 days after the delivery of the goods. It is recommended to keep the packaging during the warranty period for any possible delivery of the product to a service center.

  • Page 18: Components Description

    SPlenDiD strongly encourages design practitioners to follow local and national codes for the unit location. We also recommend you apply the guidelines found in aCCa’s manual J for residential load calculations and manual S for proper equipment selection.

  • Page 19: Choosing The Position Of The Unit

    8”(200 mm) holes will ensure the best performance and lowest air noise level. Drill the wall using the proper tools, taking care to prevent excess damage to the wall or surrounding areas. US-ENG- 7 MAESTRO SMART...

  • Page 20: Preparing The Condensate Discharge

    Olimpia Splendid shall not be held liable for any underestimates made in the structural consistency of the wall or the anchoring materials used by the installer.

  • Page 21: Assembly Of The Air Ducts And External Grilles

    Pull the chain, tensioning the spring, couple the chain ring to the pin of the inner flange through which the sleeves pass (fig. 20). Use hand shears to cut off any excess chain links. Olimpia Splendid recommends using the supplied grilles, or grilles with similar char- acteristics that are factory approved to ensure proper unit performance. 2.4.4 - PREPARING THE HOLES ON THE UNIT the unit is designed to operate with 6.4”...

  • Page 22: Electrical Connection

    2.4.6 - ELECTRICAL CONNECTION the unit is supplied with a power cord with plug (Y-type connection). if the socket is in proximity to the unit, simply plug it in. Before connecting the unit, ensure that: • The power supply voltage and frequency values comply with those indicated on the data plate of the unit.

  • Page 23: Top/Bottom Installation Configuration

    • Turn on the unit and ensure it is on stand-by mode (no LED should be illuminated on the console). • Press the reset button positioned underneath the hole to the left side of the console (H), with a pointed object for at least 10 seconds. the beeping sound indicates the troubleshooting function has been ac- tivated. US-ENG- 11 MAESTRO SMART...
  • Page 24 At this point the current configuration of the unit will be displayed for a few moments as shown below: LED A (red) on: the unit is configured as a heat pump; LED B (green) on: the unit is setup for a low wall application(factory default); LED C (yellow) on: the unit is setup for a low wall application; LED D (green) on: reset settings function after an active black-out (factory setting). At this point all of the LEDs on the console will start flashing simultaneously for 10 seconds.

  • Page 25: Evacuating Condensate Water During An Emergency

    Refit the filter rack by inserting the rear edge into the grille (3). i. lower the front edge on the unit. l. Reclose and hook the top supply air grille (3) (fig.37). to deactivate leD a (if on), after having turned on the unit, press the micro button located on the signal console (G) (fig.B) with a pointed object for a few seconds. Afterwhich, the dirty filter signal will reset. US-ENG- 13 MAESTRO SMART...

  • Page 26: Use And Maintenance

    3 - USE AND MAINTENANCE 3.1 - WARNINGS ABOUT EQUIPMENT USE The installation and electrical connection of the unit should be carried out by certified electrician. The installation instructions are contained in the appropriate section of this manual. No structural object (furniture, curtains, plants, leaves, blinds, etc.) should ever obstruct the normal airflow from either the internal or external grilles.

  • Page 27: Using The Remote Control

    Close the spring-latch cover after inserting the batteries. US-ENG- 15 MAESTRO SMART...

  • Page 28: Operating The Remote Control

    3.3.2 - OPERATING THE REMOTE CONTROL REMOTE CONTROL on/off (standby). Sleep Comfort Key (automatic) Sleep mode operating mode selector button fan speed selector button Button for setting timer and programs Button for increasing (+) or decreasing (-) the temperature/time settings Button for activating the free CoolinG air change system (not available in this model) ON/OFF button for oscillating flap adjustment T10 reset button...

  • Page 29: Unit Start Up

    • The unit is equipped with a power switch (10) located below the lower safety guard (9). • To run this power button must be in “I” position. • At this point the unit can be operated by the remote control. In order to transmit commands to the unit, point the front of the remote control toward the unit’s control panel. • The unit emits a beep when it receives a command. • The remote requires direct line of sight with the unit’s receiver with a maximum distance between them being 26 feet (8 m). US-ENG- 17 MAESTRO SMART...

  • Page 30: Operating The Unit

    3.4 - OPERATING THE UNIT 3.4.1 - OPERATIONAL MODES - TURNING THE UNIT ON/OFF • Button T1 is used to switch the unit off (stand-by mode) or to switch the unit back on. an eProm contained in the unit’s control board system settings are memorized when the unit is turned off.

  • Page 31: Airflow Directional Control

    • Ideally night mode is selected just as you go to bed. The heating setpoint is maintained for one hour. • During the next two hours the heating setpoint is gradually lowered while the fan is run low speed. • At this point the cooling setpoint no longer changes. Sleep mode is not available in dehumidification and ventilation mode. When in sleep mode pressing the T3 button again will return the unit to the previous mode and temperature setpoint. US-ENG- 19 MAESTRO SMART...

  • Page 32: Setting The Time

    3.5 - SETTING THE TIME • The unit provides the end user with two operating programming options that can be set to start and stop at specific desired times. for example,you might want the unit to start shortly before returning home. To use these programs, the end user must first set the time on the remote control, then set the time(s) for the program(s) to start. 3.5.1 - TIMER AND CLOCK SETTING (fig.E) to set the time on the remote control follow these instructions Press the B6 button (Set timer) as many times as necessary to display the hour h at position (D10). b.

  • Page 33: Resetting All Remote-Control Functions

    3.8 - Troubleshooting if the unit experiences a problem, use the following table for possible solutions. if the problem still exists after these checks, contact a qualified service technician. US-ENG- 21 MAESTRO SMART...

  • Page 34: Unit Specifications

    If the unit is serviced by unqualified persons this can result in damage to the unit and possibly create unsafe conditions and could result in warranty claims being denied and/or void the unit’s remaining warranty. FAULTS POSSIBLE CAUSES SOLUTIONS Check the main power. if the unit is plugged no power supply into a wall outlet verify voltage is present by plugging in another device, such as a lamp.
  • Page 35 Startup Information Sheet for Maestro Smart Model model #__________________ Serial #_________________ Start Up Date__________ Unit owner___________________ Phone #___________________________ owner address 1________________________ address 2_______________________ City or Province__________________ State______ Zip Code______________ installing Contractor_________________________ Phone # _______________ technician name___________________________ Phone # _______________ Prior to install verify model number to insure proper unit selection...
  • Page 36 LIMITED WARRANTY USA & CANADA thank you for purchasing this olimpia Splendid USa unit. this unit is covered by a limited 7 year compres- sor, a 2 year parts warranty and a 1 year limited unit replacement should the compressor fail within the first 12 months from date of startup. The warranty periods mentioned above are only valid if the unit is...
  • Page 40 Contact Information: olimpia Splendid USa 66 White Street floor 501 new York, nY 10013 USa Phone/fax: (800) 408-5196 email: customerservice@olimpiasplendidusa.com...
