- Page 1 CM100LTE External Connectivity Module ENGLISH...
- Page 2 BLACKVUE CM100LTE For manuals, customer support and FAQs go to www.blackvue.com...
- Page 3 In the box Check the box for each of the following items before installing the BlackVue device. Connectivity module SIM eject tool Cable Clips (4ea) Double-side tape User guide SIM activation guide Screw Driver CM100LTE...
- Page 4 At a glance The following diagram explains details of the external connectivity module. 10mm SIM slot cover BLACKVUE...
- Page 5 Do not install the product in a location where it can obstruct the driver's field of vision. Turn off the engine. Unscrew the bolt that locks the SIM slot cover on connectivity module. Remove the cover, and unmount the SIM slot using the SIM eject tool. Insert the SIM card into the slot. CM100LTE...
- Page 6 Use the pry tool to lift the edges of the windshield trim/molding and tuck in the connectivity module cable. Turn on the engine. The BlackVue dashcam and connectivity module will power up. Note y For full details on installing the dashcam on your vehicle, refer to the "Quick Start Guide"...
-
Page 7: Product Specifications
Model Name CM100LTE Color/Size/Weight Black / Length 90 mm x Width 60 mm x Height 10 mm / 74g CM100LTE [GL] : Quectel EC25-E CM100LTE [NA] : Quectel EC25-A LTE Module CM100LTE [JP] : Quectel EC25-J CM100LTE [AU] : Quectel EC25-AU... -
Page 8: Appendix - Product Specification
APPENDIX – PRODUCT SPECIFICATION CM100LTE Function Operating Frequency Output Power UMTS FDD 1 1920-1980 MHz 24.00 dBm UMTS FDD 8 880-915 MHz 24.00 dBm E-UTRA FDD 1 1920-1980 MHz 23.00 dBm E-UTRA FDD 3 1710-1785 MHz 23.00 dBm E-UTRA FDD 7 2500-2570 MHz 23.00 dBm... - Page 9 Notes...
- Page 10 Notes...
-
Page 11: Product Warranty
Product Warranty The term of this product warranty is 1 year from the purchase date. (Accessories such as an External Battery/microSD Card: 6 Months) We, PittaSoft Co., Ltd., provide the product warranty according to the Consumer Dispute Settlement Regulations (drawn up by the Fair Trade Commission). - Page 12 FCC ID: YCK-CM100LTE / Contains FCC ID: XMR201605EC25A / Contains IC ID: 10224A-201611EC25A Declaration of Conformity Pittasoft declares that this device complies with the essential requirements and relevant provisions of Directive 2014/53/EU Go to www.blackvue.com/doc to view the Declaration of Conformity.
