VIOLET UV
GIA-S09VIOUV | GIA-S12VIOUV
GIA-S18VIOUV | GIA-S24VIOUV
Por favor lea atentamente este manual antes de usar este producto.
Please, read carefully this manual before using the product.
Avant d'utiliser l'équipement, lisez attentivement les instructions.
Por favor leia atentamente este manual antes de usar o equipamento.
Per favore leggere attentamente questo manuale prima di utilizzare questo prodotto.
G r a c i a s | T h a n k y o u | M e r c i | O b r i g a d o | G r a z i e
ES
EN
OWNER'S MANUAL
FR
PT
IT
Advertisement
Table of Contents
Related Manuals for Giatsu VIOLET UV GIA-S09VIOUV
Summary of Contents for Giatsu VIOLET UV GIA-S09VIOUV
- Page 1 OWNER’S MANUAL VIOLET UV GIA-S09VIOUV | GIA-S12VIOUV GIA-S18VIOUV | GIA-S24VIOUV Por favor lea atentamente este manual antes de usar este producto. Please, read carefully this manual before using the product. Avant d’utiliser l’équipement, lisez attentivement les instructions. Por favor leia atentamente este manual antes de usar o equipamento. Per favore leggere attentamente questo manuale prima di utilizzare questo prodotto.
- Page 2 ENGLISH OWNER’S MANUAL VIOLET UV GIA-S09VIOUV | GIA-S12VIOUV GIA-S18VIOUV | GIA-S24VIOUV...
- Page 3 SAFETY PRECAUTIONS WARNING: Following these basic precautions will reduce the risk of fire, electrical shock, injury or death when using your air conditioner. 1. Air conditioner must be connected to proper electrical outlet or breaker with the correct electrical supply. And only the specified power can be used. 2.
-
Page 4: Table Of Contents
USER’S MANUAL CONTENTS 1. SAFETY INSTRUCTIONS................24 Symbol Description…………………………………………………..……….………..…24 Installation Instruction…………………………………………………..…….………..24 Operating Instruction………………………………………………………….………..25 Safety Instruction… …………………………………………………………..………..28 2. PRODUCT INTRODUCTION..............29 Protect Functions………………………………………………….…….….…………..29 3. DESCRIPTION OF COMPONENTS............30 View of Unit……………………………………………………………….……..……….30 Display screen……………………………………………………………….……..….…31 Indicator light………………………………………………………………….……..…32 Remote Controller…………….……………………….……..……………….….…..….33 4. SERVICE AND MAINTENANCE..............35 Clean the Front Panel and Remote Controller………………………….……………..35 Clean Air Filter…………………..………………………………………….…………..…35 No Use for Long Time…………………..…………………………………….………..36 Recommendations for Energy Saving…………..……………………………….……...37... -
Page 5: Safety Instructions
USER’S MANUAL SAFETY INSTRUCTIONS 〖Symbol Description〗 A symbol indicating operation which may cause personnel Warning: casualties or serious damages. A symbol indicating operation which may cause personnel Caution: casualties or property damages. 〖Installation Instruction〗 Warning Never install by yourself. Split type air conditioner will work for you for a long period of time if it is correctly installed. -
Page 6: Operating Instruction
USER’S MANUAL 〖Operating Instruction〗 WARNINGS Following the safety messages is very important. These messages can save you from being injured or killed. Warning symbols alert you to be careful and means danger. Always follow instructions to be safe and reduce chances of injury or death. Warning and danger signs will precede safety messages. - Page 7 USER’S MANUAL Tips Install the unit on the north side, as normally that is the shaded side. This will enhance the operation of your unit. Use correct electric voltage and proper ampere for the unit to run effectively. Only let a certified electrician do any modifications to your electrical outlet or ...
- Page 8 USER’S MANUAL 〖Operating Instruction〗 Only single-phase a.c. power can be used. Use the specified power cord; do not please refer to nameplate for details. change it. Do not put fingers or sticks into the inlet or Do not put anything on the outdoor unit. outlet of air conditioner;...
-
Page 9: Safety Instruction
USER’S MANUAL 〖Safety Instruction〗 The appliance is not intend for use by young children or infirm persons without supervision. Young children should be supervised to ensure that they do not play with the appliance. If the supply cord is damaged, it must be replaced by the Warning manufacturer or its service agent or a similarly qualified person in order to avoid a hazard. -
Page 10: Product Introduction
USER’S MANUAL PRODUCT INTRODUCTION 〖Protect Functions〗 Protect functions can prolong the air conditioner’ s service life and provide more comfortable airflow. Delay-starting protection for the compressor The compressor will restart working at least 3 minutes (5 minutes in heating mode) after being turned off to keep the pressure balance of the cooling system. -
Page 11: Description Of Components
USER’S MANUAL In cooling operation, if the temperature of outdoor heat exchanger is too high, indoor fan speed will be adjusted to a lower gear automatically and compressor may be stopped. Drip proof (only in some models) In cooling and dehumidification operation, louver blades can change the position automatically to prevent from dripping. -
Page 12: Display Screen
USER’S MANUAL 〖Display screen〗 “RUN” indicator：This signal light is on when the unit is is in “RUNNING” status. When in Defrosting or Cooling airflow proof ,the indicator is flashing “TIMER” indicator：This signal light is on when the unit is in Timer. “Compressor”... -
Page 13: Indicator Light
USER’S MANUAL 〖Indicator light〗 ① “PAUSE” indicator This indicator lights red when air conditioner is in defrosting or Cooling airflow proof mode. ② “RUNNING” indicator This indicator lights green when the unit is in “RUNNING” status; air conditioner is in HEAT, COOL, SWEEP, DRY mode. -
Page 14: Remote Controller
USER’S MANUAL 〖Remote Controller〗 Display Screen UVC Button Fo r setting display To start or stop UVC sterilize function. Airflow sweep Button For changing horizontal Airflow sweep Button blades position and vertical For changing (optional) blades position and swing or not. On/Off Button Press this button to start / Mode selection Button... - Page 15 USER’S MANUAL 〖Remote Controller Display〗 Operating Mode Selection Display Turbo Display AUTO It appears when turbo function is set in COOLING or HEAT HEAT Signal Emission Symbol mode, and will flash. COOL It appears when control signal is emitted. SWEEP Wind Speed Selection Setting temp Display Display...
-
Page 16: Service And Maintenance
USER’S MANUAL SERVICE AND MAINTENANCE Careful maintenance and overhaul in advance can prolong the air conditioner’ s service life and save electricity charges. Caution: 1. Stop air conditioner by remote controller and pull off the plug before service and maintenance. 2. -
Page 17: No Use For Long Time
USER’S MANUAL 〖No Use for Long Time〗 1. Swing 3-4 hours to dry the internal 2. Stop operation by remote controller, then air conditioner. cut off the power source of air conditioner. 3. Maintain air filter net. 4. Take out batteries from remote controller. -
Page 18: Recommendations For Energy Saving
USER’S MANUAL 〖Recommendations for Energy Saving 〗 Appropriate Temp Setting Avoid Direct Sunlight When it is cooling, please use curtain or It is harmful to health if the room is too cold. blind to obstruct direct sunlight. Close Doors and Windows Avoid Heat Sources When it is cooling, using other heat sources Incoming outdoor air will affect the cooling... -
Page 19: Troubleshooting
USER’S MANUAL TROUBLE SHOOTING 〖Air Conditioner is in Error〗 Checking before service. Phenomenon Checking Items 1. Check whether the power is disconnected. Air Conditioner 2. Check whether the breaker is switched on or the fuse is burnt. Does Not Operate 3. -
Page 20: Normal Phenomenons
USER’S MANUAL NORMAL PHENOMENONS When it is heating or cooling, plastic f the indoor humidity is too high, water substance may give out a sound because of drops may form on the front grill of indoor the temperature change. unit. This is a normal phenomenon. Walls, carpet, furniture or clothes indoors There may be gentle “rustle”... - Page 21 C/ Industria, 13, Polígono Industrial El Pedregar. 08160 Montmeló. Barcelona (España) Tel (0034) 93 390 42 20 - Fax (0034) 93 390 42 05 info@giatsu.com - www.giatsu.com FRANCE PORTUGAL ITALIA info.fr@giatsu.com info.pt@giatsu.com info.it@giatsu.com L L L I I I T T T H H H U U U A A A N N N I I I A A A info@giatsu.lt...
