- Page 1 OWNER’S AND INSTALLATION MANUAL OUTDOOR UNIT SPLIT DIAMANT GIA-S09DIAR32-EXT | GIA-S12DIAR32-EXT Thanks for choosing our product. Please, read carefully this manual before using the product.
-
Page 2: Table Of Contents
Content Operation Notices Precautions ......................1 Parts name ......................6 Malfunction Malfunction analysis ..................7 Installation Notice Safety operation of flammable refrigerant ............8 Installation prepare ..................10 Installation Installation of outdoor unit................14 Check after installation ................... 17 Test operation ....................17 Attachment Configuration of connection pipe.............. -
Page 3: Precautions
Precautions Please read this operating manual carefully before operating the unit. Appliance filled with flammable gas R32. Before use the appliance, read the owner's manual first. Befoer install the appliance,read the installation manual first. Befoer repair the appliance ,read the service manual first. The figures in this manual may be different with the material objects, please refer to the material objects for reference. - Page 4 Precautions WARNING Operation and Maintenance This appliance can be used by children aged of 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
- Page 5 Precautions WARNING Do not block air outlet or air inlet. It may cause malfunction. Do not spill water on the remote controller, otherwise the remote controller may be broken. When below phenomenon occurs, please turn off air conditioner and disconnect power immediately, and then contact the dealer or qualified professionals for service.
- Page 6 Precautions WARNING Including an circuit break with suitable capacity, please note the following table.Air switch should be included magnet buckle and heating buckle function, it can protect the circuit-short and overload. Don't use unqualified power cord. Make sure the power supply matches with the requirement of air conditioner.Unstable power supply or incorrect wiring or malfunction.
- Page 7 Precautions WARNING The appliance must be positioned so that the plug is accessible. All wires of indoor unit and outdoor unit should be connected by a professional. If the length of power connection wire is insufficient, please contact the supplier for a new one. Avoid extending the wire by yourself.
-
Page 8: Parts Name
Parts name Air inlet Handle Air outlet NOTE: Actual product may be different from above graphics,please refer to actual products. -
Page 9: Malfunction Analysis
Malfunction analysis General phenomenon analysis Please check below items before asking for maintenance. If the malfunction still can't be eliminated,please contact local dealer or qualified professionals. Phenomenon Check items Solution Power failure? Wait until power recovery. Is plug loose? Reinsert the plug. Circuit break trips off or fuse is Ask professional to replace circuit burnt out? -
Page 10: Safety Operation Of Flammable Refrigerant
Safety operation of flammable refrigerant Qualification requirement for installation and maintenance man All the work men who are engaging in the refrigeration system should bear the valid certification awarded by the authoritative organization and the qualificationfor dealing with the refrigeration system recognized by this industry. - Page 11 Safety operation of flammable refrigerant Welding If you should cut or weld the refrigerant system pipes in the process of maintaining, please follow the steps as below: 1. Shut down the unit and cut power supply. 2. Eliminate the refrigerant. 3.
-
Page 12: Installation Prepare
Installation prepare Installation drawing Drainage pipe Tools 1 Level meter 2 Screw driver 3 Impact drill 4 Drill head 5 Pipe expander 6 Torque wrench 7 Open-end wrench 8 Pipe cutter 9 Leakage detector 10 Vacuum pump 11 Pressure meter 12 Universal meter 13 Inner hexagon spanner 14 Measuring tape... - Page 13 Installation prepare Outdoor unit 1. Select a location where the noise and out flow air emitted by the outdoor unit will not affect neighborhood. 2. The location should be well ventilated and dry, in which the outdoor unit won't be exposed directly to sunlight or strong wind.
- Page 14 Installation prepare Grounding requirement 1. The air conditioner is the first class electric appliance. It must be properly grounding with specialized grounding device by a professional. Please make sure it is always grounded effectively, otherwise it may cause electric shock. 2.
- Page 15 Installation prepare pressure side (gas valve), immediately stop the unit and disconnect power. Please note that the time for refrigerant recovery should not exceed 1 minute. — If refrigerant recovery takes too much time, air may be sucked in and cause pressure rise or compressor rupture, resulting in injury.
-
Page 16: Installation Of Outdoor Unit
Installation of outdoor unit Step 1: Fix the support of outdoor Select it according to the actual installation situation 1. Select installation location according to the house structure. 2. Fix the support of outdoor unit on the selected location with expansion screws. Note: ●... - Page 17 Installation of outdoor unit Step 4: Connect indoor and outdoor pipe 1. Remove the screw on the right handle of 2. Remove the screw cap of valve and aim outdoor unit and then remove the handle. the pipe joint at the bellmouth of pipe. liquid valve gas valve handle...
- Page 18 Installation of outdoor unit Step 6: Neaten the pipes 1. The pipes should be placed along the wall, bent reasonably and hidden possibly. Min.semidiameter of bending the pipe is 10cm. 2. If the outdoor unit is higher than the wall hole, you must set a U-shaped curve in the pipe before pipe wall goes into the room, in order to prevent rain from...
-
Page 19: Check After Installation
Check after installation Check according to the following requirement after finishing installation. Items to be checked Possible malfunction Has the unit been installed firmly? The unit may drop, shake or emit noise. Have you done the refrigerant leakage It may cause in sufficient cooling (heating) test? capacity. -
Page 20: Configuration Of Connection Pipe
Configuration of connection pipe 1. Standard length of connection pipe ● 5m, 7.5m, 8m. 2. Min length of connection pipe For the unit with standard connection pipe of 5m, there is no limitation for the min length of connection pipe. For the unit with standard connection pipe of 7.5m and 8m, the min length of connection pipe is 3m. -
