- Page 2 ENGLISH OWNER’S AND INSTALLATION MANUAL INDOOR UNIT MAMBA GIA-S09MAMB-I | GIA-S12MAMB-I GIA-S18MAMB-I | GIA-S24MAMB-I...
-
Page 3: Table Of Contents
Content Operation Notices Precautions ......................33 Parts name ......................38 Maintenance Clean and maintenance ..................39 Malfunction Malfunction analysis ..................41 Safety operation of flammable refrigerant ............44 Installation Notice Installation drawing ..................46 Installation prepare ................... 47 Installation Installation of indoor unit ................. -
Page 4: Precautions
