- Page 1 16575276 Edition 2 December 2013 Screwdrivers Series 7 Maintenance Information Save These Instructions...
-
Page 2: Product Safety Information
Product Safety Information WARNING • Failure to observe the following warnings, and to avoid these potentially hazardous situations, could result in death or serious injury. • Read and understand this and all other supplied manuals before installing, operating, repairing, maintaining, changing accessories on, or working near this product. - Page 3 4. Lift off the Rear End Plate (102), Cylinder (106) and Vanes (105). 5. Check the Front Rotor Bearing for damage or roughness. If replacement is necessary, support the Front End Plate (107) between two blocks of wood on the table of an arbor press and press the Rotor from the Front Rotor Bearing. Disassembly of the Lever Throttle Motor Housing 1.
- Page 4 3. For 7P1 Positive Jaw Clutch, remove the Sleeve Spring Retainer (416A). Use a fine blade screwdriver and work the first coil of the Retailing Sleeve Spring (417) over the end of Bit Holder. Thread the remainder of the Spring over the end of the Bit Holder, being careful not to distort the Spring.
- Page 5 Assembly of 7D1 Direct Drive Attachment 1. If the Housing Bushing (302) was removed, press a new Housing Bushing into the Clutch Housing (301) until it is flush with the face of the shoulder at the bottom of the clutch chamber. Smear the inside of the Housing Bushing with grease. 2.
- Page 6 3. Install the Throttle Valve Seat Support (66) by pushing it into place with a 1/2” diameter dowel. Follow this with the Throttle Valve Seat (67). 4. Install the Plunger Bushing (53A) and insert the Throttle Valve Plunger (69), hole end first, into the Plunger Bushing until the hole through the Plunger is aligned with the hole in the Throttle Valve Seat.
- Page 7 15. Insert the Throttle Valve Seat Support (21) into the tapped bore of the handle and push it into place with 1/2” (13 mm) dowel. Follow the Throttle Valve Seat Support with the Throttle Valve Seat (20). 16. If the Trigger (17) was removed from the Trigger Pin (18), press a new Trigger onto the grooved end of the Pin so that it is at right angles to the hole in the opposite end of the Pin.
- Page 8 d. Place a Spindle Planet Gear (118) on each Planet Gear Shaft. e. Work 3 to 6 cc of the recommended grease into the spindle gear train. Place the Gear Head Spacer (125) against the face of the Spindle Planet Gears. Insert the splined hub of the Gear Head (122) through the Gear Head Spacer so that it meshes with the Spindle Planet Gears.
-
Page 9: Troubleshooting Guide
Troubleshooting Guide Trouble Probable Cause Solution Low power Low air pressure Check air supply. For top performance, the air pressure must be 90 psig (6.2 bar/620 kPa) at the inlet. Plugged Air Strainer Screen Clean the air Strainer or screen in a clean, suitable, cleaning solution. If the Inlet Screen Screen cannot be cleaned, replace it. - Page 10 Notes:...
