Enerpac ACBS22 Instruction Sheet

A UNIT OF APPLIED POWER INC.
L 2243 Rev. A
IMPORTANT RECEIVING INSTRUCTIONS
DESCRIPTION
SPECIFICATIONS
135,0 [5.32]
121,0 [4.76]
Ø 42,0 [1.65]
35,0 [1.38]
ACBS-202
®
06/97
Visually inspect all components for shipping damage. If any shipping damage is
found, notify carrier at once. Shipping damage is NOT covered by warranty. The
carrier is responsible for all repair or replacement costs resulting from damage in
shipment.
The ACBS-22 and ACBS-202 accumulator blocks maintain system pressure after
a fixture has been disconnected from the pump. Accumulator blocks include an
accumulator, relief valve, pressure gauge, shut-off valve and coupler. They can be
mounted directly on a pallet and can be used with both single-acting and double-
acting circuits.
MODEL
NUMBER
ACBS-22
ACBS-202
191,6 [7.54]
60,5 [2.38]
7,0 [0.28]
68,0 [2.68]
67,5 [2.66]
Instruction Sheet
Accumulator Block
Accumulator
Min. Working
Oil Capacity
Pressure
liters
bar
(cu. in.)
(psi)
0,015 110
(0.9) (1,500)
0,13 110
(7.80) (1,500)
35,0 [1.38]
Figure 1
ACBS22 ACBS202
Max. Working
Pressure
bar
(psi)
350
(5,000)
350
(5,000)
191,6 [7.54]
135, 0 [5.32]
121,0 [4.76]
60,5 [2.38]
7,0 [0.28]
84,6 [3.33]
Ø
2.68 [68,0]
WARNING
6,75 [2.66]
ACBS-22
Gas Preload
Pressure
bar
(psi)
100
(1,450)
100
(1,450)
